Industrial I/O Expansion Solution – GE IC200CHS022K | VersaMax Series
Where This Product Is Used
The GE IC200CHS022K is a 10-slot I/O carrier module from the GE VersaMax series, engineered for distributed control architectures in demanding industrial environments. Engineers specify this module across a wide range of applications:
- Automotive Assembly Lines – Expanding discrete I/O points for robotic welding cells, conveyor interlocks, and safety relay monitoring.
- Water & Wastewater Treatment Plants – Mounting analog input modules for flow meters, pressure transmitters, and level sensors in remote panel enclosures.
- Oil & Gas Wellhead Control Panels – Providing a rugged, DIN-rail-mountable base for mixed I/O modules in hazardous-area junction boxes.
- Food & Beverage Processing – Supporting high-density I/O expansion for temperature, speed, and valve control in hygienic production lines.
- Building Automation & HVAC – Hosting I/O modules for BACnet-integrated air handling units, chiller plants, and energy metering systems.
- Discrete Manufacturing (MES Integration) – Serving as the physical I/O backbone for VersaMax remote drop nodes connected to a GE PACSystems RX3i or RX7i CPU via Ethernet or Genius bus.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | IC200CHS022K |
| Series | GE VersaMax |
| Module Type | I/O Carrier / Base Module |
| Slot Count | 10 I/O Module Slots |
| Mounting | DIN Rail (35 mm) or Panel Mount |
| Bus Interface | VersaMax Local I/O Bus |
| Power Supply | Supplied via NIU or CPU carrier power bus |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | Approx. 1,100 g |
| Dimensions (W × H × D) | Per GE VersaMax mechanical spec |
| Certifications | UL, CE, cUL |
Why Engineers Specify This Model
- High-Density Expansion – 10 slots accommodate a full mix of discrete, analog, and specialty I/O modules in a single carrier, minimizing panel footprint.
- Plug-and-Play Compatibility – Accepts all IC200 series I/O modules without additional wiring adapters or firmware changes.
- Rugged Industrial Design – Rated for continuous operation in high-vibration, high-humidity environments typical of process and discrete manufacturing.
- Flexible Mounting – DIN rail or panel-mount options simplify integration into existing enclosure designs.
- Scalable Architecture – Multiple IC200CHS022K carriers can be daisy-chained to expand I/O capacity as system requirements grow.
- Long Product Lifecycle – GE VersaMax remains an actively supported platform with available spare parts and firmware updates.
Complete System Bill of Materials
For a fully operational VersaMax remote I/O drop using the IC200CHS022K, the following components are typically required:
- IC200CHS022K – 10-Slot I/O Carrier (this item)
- IC200PNS001 / IC200PNS002 – PROFINET or Ethernet Network Interface Unit (NIU)
- IC200MDL640 / IC200MDL740 – Discrete Input / Output Modules (as required)
- IC200ALG260 / IC200ALG432 – Analog Input / Output Modules (as required)
- IC200PWR002 – 24 VDC Power Supply Module
- IC200CHS002 – Expansion Carrier (if additional slots needed)
- 35 mm DIN Rail, terminal blocks, and enclosure hardware
Compliance & Industry Standards
- UL Listed (Industrial Control Equipment)
- CE Marked – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- cUL (Canadian UL equivalent)
- RoHS Compliant
- IEC 61131-2 (Programmable Controllers – Equipment Requirements)
- NEMA ICS 2 (Industrial Control Devices)
Quality Assurance & Sourcing
Every GE IC200CHS022K unit shipped by Konmask undergoes a structured quality process:
- Visual Inspection – Connector pins, PCB, and housing checked for physical damage or corrosion.
- Functional Verification – Module seated in a live VersaMax test rack and bus communication confirmed prior to shipment.
- Authenticity Check – Part markings, date codes, and label formats verified against GE factory specifications.
- Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning inside double-wall cartons.
- Traceability – Each unit logged with serial number and inspection record for full supply-chain traceability.
How to Source This Part
- Click Add to Cart or Buy Now on this page.
- For volume orders (5+ units), contact support@konmask.com for a bulk pricing quote.
- Lead time: In-stock units ship within 1–3 business days. Out-of-stock units: 7–21 business days depending on sourcing.
- Export orders (outside China): Please confirm your country’s import regulations for industrial automation components before ordering.
- Need a datasheet or test report? Request via email with your order number.
Application-Specific FAQ
Q: Can the IC200CHS022K be used with a GE PACSystems RX3i CPU?
A: Yes. When paired with a compatible NIU (e.g., IC200PNS001), the IC200CHS022K operates as a remote I/O drop on an Ethernet/IP or PROFINET network controlled by a PACSystems RX3i or RX7i CPU.
Q: How many IC200CHS022K carriers can be connected in a single remote drop?
A: Up to 8 carriers (80 I/O module slots) can be connected in a single VersaMax remote drop, depending on the NIU model and power budget.
Q: Is this module compatible with GE Series 90-30 I/O modules?
A: No. The IC200CHS022K is designed exclusively for the IC200 (VersaMax) module family and is not backward-compatible with Series 90-30 (IC693) modules.
Q: What power supply is required?
A: The carrier itself does not require a separate power connection — it draws power from the NIU or CPU carrier power bus. Field-side I/O power (typically 24 VDC) is supplied via the I/O modules installed in the carrier.
Q: Can I mix discrete and analog modules in the same IC200CHS022K carrier?
A: Yes. Any combination of IC200 series discrete, analog, and specialty modules can be installed in the 10 slots, subject to the NIU’s total I/O point and power limits.
