GE IC600FP831K – 16-Point Discrete Input Module | Series Six PLC Platform
Engineering Background
The GE IC600FP831K is a discrete input module designed for the GE Series Six Programmable Logic Controller (PLC) platform — one of GE’s most widely deployed industrial control architectures in process manufacturing, power generation, and heavy industry. The IC600 family established the benchmark for modular, rack-based PLC design in the 1980s and 1990s, and a significant installed base continues to operate in critical infrastructure worldwide.
Product Positioning
This module serves as the primary field-signal interface for discrete (on/off) input signals from sensors, limit switches, pushbuttons, and relay contacts. It is engineered for high-noise industrial environments and integrates directly into the IC600 backplane without additional signal conditioning hardware. Procurement engineers maintaining legacy Series Six systems rely on this module for direct drop-in replacement with zero re-engineering overhead.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number / SKU | IC600FP831K |
| Manufacturer | GE (General Electric Automation) |
| Platform / Series | Series Six PLC – IC600 Family |
| Module Type | Discrete Input Module |
| Input Points | 16 discrete input channels |
| Input Voltage Range | 24 VDC / 120 VAC (field-configurable per channel group) |
| Input Logic Level (ON) | ≥ 15 VDC / ≥ 79 VAC |
| Input Logic Level (OFF) | ≤ 5 VDC / ≤ 20 VAC |
| Isolation | Optical isolation, field-to-backplane |
| Backplane Interface | IC600 Series Six rack-compatible |
| Status Indication | Per-channel LED indicators |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Form Factor | Single-slot IC600 rack module |
| Weight | Approx. 460 g |
| Country of Origin | United States |
| HS Code | 8537.10.91 |
Proven Application Environments
- Power Generation: Turbine control panels, generator protection relay interfaces, and switchgear monitoring in coal, gas, and hydro plants running legacy GE Series Six systems.
- Oil & Gas: Wellhead control, pipeline SCADA integration, and compressor station automation where Series Six PLCs remain the installed standard.
- Chemical & Petrochemical: Reactor interlock systems, emergency shutdown (ESD) input chains, and process vessel level/pressure switch monitoring.
- Automotive Manufacturing: Transfer line control, robotic cell safety interlocks, and conveyor limit-switch feedback in plants with long-running Series Six installations.
- Water & Wastewater: Pump station control, valve position feedback, and alarm input aggregation in municipal infrastructure.
- Pulp & Paper / Steel: High-vibration, high-EMI environments where the IC600FP831K’s optical isolation provides reliable signal integrity.
Engineering Advantages
- Direct Drop-In Replacement: 100% pin-compatible with the IC600 backplane — no firmware changes, no re-wiring, no re-commissioning required.
- Optical Isolation: Full galvanic separation between field wiring and backplane bus eliminates ground-loop interference and protects the CPU from field-side transients.
- Per-Channel LED Diagnostics: Instant visual confirmation of input state during commissioning and fault-finding without requiring a programming terminal.
- Wide Voltage Tolerance: Accepts both 24 VDC and 120 VAC field signals, reducing the need for external signal converters in mixed-voltage plants.
- Proven Long-Term Reliability: Designed to MIL-spec environmental standards; field-proven across 30+ years of continuous industrial service.
- Minimal Spare-Parts Footprint: A single IC600FP831K covers multiple input applications, simplifying spare-parts inventory management.
System Architecture & Signal Flow
Field devices (switches, sensors, relay contacts) connect to the IC600FP831K’s screw-terminal field wiring block. Each input channel passes through an optical isolator that converts the field-side electrical signal into a logic-level signal on the backplane side. The module’s backplane interface communicates input states to the Series Six CPU module via the IC600 I/O bus on every PLC scan cycle. The CPU ladder logic reads these states as discrete boolean coils for use in control logic, interlocks, and alarm processing.
Signal path: Field Device → Terminal Block → Optical Isolator → IC600 Backplane Bus → Series Six CPU → Ladder Logic Execution
Sourcing & Quality Verification
All IC600FP831K units offered by Konmask.com are sourced through verified industrial surplus and authorized distribution channels. Each unit undergoes the following pre-shipment verification protocol:
- Visual inspection: PCB, connector pins, label integrity, and housing condition.
- Functional power-on test: Backplane communication handshake and LED self-test verification.
- Input channel continuity check: All 16 channels verified for correct optical isolator response.
- Firmware/revision label documentation: Revision suffix (K) recorded and matched to customer requirements.
- ESD-safe packaging: Anti-static bag + foam insert + double-wall carton for international shipment.
Procurement Process
- Confirm Revision: Verify that revision suffix K is compatible with your Series Six CPU firmware version. Contact our technical team if unsure.
- Request Quote: Email support@konmask.com with your required quantity and delivery timeline for volume pricing.
- Order & Payment: Secure checkout via Shopify. Wire transfer (T/T) and PayPal accepted for B2B orders.
- Shipping: DHL / FedEx Express worldwide. Typical lead time: 3–7 business days. Expedited options available.
- Documentation: Commercial invoice, packing list, and test report provided with every shipment.
Technical FAQ
- Q: Is the IC600FP831K compatible with the GE Series One or Series Three PLC?
- A: No. This module is designed exclusively for the IC600 Series Six backplane. It is not electrically or mechanically compatible with Series One (IC200) or Series Three (IC300) racks.
- Q: What is the difference between IC600FP831 and IC600FP831K?
- A: The suffix letter denotes the hardware revision. Revision K incorporates component updates for improved EMI immunity. Always match the revision to your system’s validated spare-parts list.
- Q: Can I mix 24 VDC and 120 VAC inputs on the same module?
- A: Input voltage grouping depends on the module’s internal wiring configuration. Consult the GE Series Six Hardware Reference Manual (GEK-25361) for channel group voltage assignments before wiring mixed-voltage inputs.
- Q: Do you provide a warranty?
- A: Yes. Konmask.com provides a 90-day functional warranty on all modules. DOA (Dead on Arrival) units are replaced at no cost within 7 days of delivery.
- Q: Can you source other IC600 series modules?
- A: Yes. Contact us with your full BOM (Bill of Materials) for IC600 CPU, output, analog, and communication modules. We maintain an extensive IC600 inventory.
