GE IC693CPU341 – Single-Slot CPU Module | Series 90-30 PLC Platform
Engineering Background
The GE IC693CPU341 is a production-proven CPU module designed for the GE Fanuc Series 90-30 programmable logic controller platform — one of the most widely deployed mid-range PLC families in discrete manufacturing, process control, and building automation. Introduced as a cost-optimized single-slot solution, the IC693CPU341 delivers deterministic scan performance and robust I/O capacity for applications where reliability and long service life are non-negotiable requirements.
Product Positioning
Targeted at maintenance engineers, system integrators, and OEM machine builders who require a direct drop-in replacement or expansion CPU for existing Series 90-30 rack infrastructure. The IC693CPU341 eliminates the need for full system migration, protecting capital investment in installed base hardware while restoring full operational capability.
Complete Technical Specifications
| Part Number | IC693CPU341 |
| Manufacturer | GE Fanuc / GE Automation & Controls |
| Platform | Series 90-30 PLC |
| Form Factor | Single-Slot CPU Module |
| User Memory | 6K words (program + data) |
| Maximum I/O Points | 512 discrete I/O (expandable via expansion racks) |
| Communication Port | 1 × RS-232C serial port (SNP/SNPX protocol) |
| Programming Software | Proficy Machine Edition (ME) / Logicmaster 90-30 |
| Scan Time | Deterministic; application-dependent |
| Power Consumption | Supplied via Series 90-30 backplane |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Certifications | UL, CE (platform-level) |
| Weight | Approx. 250 g |
| RoHS Compliance | Consult datasheet for specific revision |
Proven Application Environments
- Discrete manufacturing: assembly lines, conveyor control, machine tool sequencing
- Process industries: pump station control, HVAC automation, water treatment
- Building automation: access control integration, lighting management systems
- OEM machinery: packaging equipment, printing presses, material handling
- Maintenance replacement: direct swap for failed IC693CPU341 units in live production systems
Engineering Advantages
- Single-slot footprint — preserves adjacent rack slots for I/O expansion modules
- SNP/SNPX protocol support — compatible with GE HMI panels, SCADA systems, and programming terminals via RS-232
- Deterministic scan execution — predictable ladder logic performance for time-sensitive control loops
- Backward compatibility — operates within existing Series 90-30 5-slot, 10-slot, and expansion rack configurations
- Proven field longevity — widely documented MTBF in 24/7 industrial environments
System Architecture & Signal Flow
The IC693CPU341 occupies Slot 1 of any Series 90-30 baseplate. The CPU communicates with local I/O modules via the Series 90-30 backplane bus and with remote expansion racks via the Bus Expansion Module (BEM). Program execution follows a standard PLC scan cycle: Input Scan → Program Execution → Output Scan → Communications Service. The RS-232 port supports point-to-point SNP connections to a programming device or HMI, enabling online monitoring, program upload/download, and forced I/O operations without interrupting the control scan.
Sourcing & Quality Verification
- All units sourced through verified industrial surplus and authorized distribution channels
- Pre-shipment inspection: visual examination, firmware version check, functional power-on test where applicable
- Original GE Fanuc labeling and firmware integrity confirmed prior to listing
- Traceability documentation available upon request for regulated industries
- Units shipped in anti-static packaging with protective foam insert
Procurement Process
- Confirm compatibility — verify your existing rack model (IC693CHS391, IC693CHS397, etc.) and power supply rating before ordering
- Place order — add to cart and complete checkout; HKD pricing displayed; multi-currency checkout supported
- Order confirmation — automated confirmation email dispatched within minutes; order reference provided
- Inspection & dispatch — unit inspected, packaged, and dispatched within 1–3 business days
- Shipping — international express freight available; tracking number provided upon shipment
- Technical support — pre- and post-sale engineering support available via email or phone
Technical FAQ
Q: Is the IC693CPU341 compatible with Proficy Machine Edition software?
A: Yes. Proficy ME supports the IC693CPU341 for program development, upload/download, and online diagnostics via the RS-232 SNP connection.
Q: Can this CPU be used in an expansion rack?
A: No. The IC693CPU341 must be installed in Slot 1 of the main (local) baseplate. Expansion racks do not support CPU modules.
Q: What is the maximum I/O capacity with expansion racks?
A: The Series 90-30 platform supports up to 512 discrete I/O points across local and remote expansion racks when using the IC693CPU341.
Q: Is a battery required for program retention?
A: Yes. A lithium backup battery (IC693ACC301 or equivalent) is recommended to retain user program and data memory during power loss.
Q: Do you provide a warranty?
A: All units carry a 90-day functional warranty. Contact support@konmask.com for warranty claims and RMA procedures.
