GE IC693ALG391 – Mixed Analog I/O Module | GE Fanuc Series 90-30 Platform
Engineering Background
The IC693ALG391 is a mixed analog input/output module designed for the GE Fanuc Series 90-30 PLC platform — one of the most widely deployed mid-range control architectures in discrete and process manufacturing. Engineered to bridge field-level analog signals with the Series 90-30 CPU backplane, this module delivers reliable, high-resolution signal conditioning for both sensing and actuation loops in a single slot footprint.
Product Positioning
Targeting procurement engineers and controls integrators who require a verified, drop-in replacement or expansion module for existing Series 90-30 installations, the IC693ALG391 eliminates the need for external signal converters by combining analog inputs and outputs in one compact module. It is the preferred choice for OEM machine builders and plant maintenance teams managing legacy GE Fanuc control systems.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number / SKU | IC693ALG391 |
| Manufacturer | GE Fanuc Automation (GE) |
| Platform | Series 90-30 PLC |
| Module Type | Mixed Analog I/O (Input + Output) |
| Analog Inputs | 4 channels (current/voltage selectable) |
| Analog Outputs | 2 channels (current/voltage selectable) |
| Input Signal Range | 4–20 mA / 0–10 VDC / ±10 VDC |
| Output Signal Range | 4–20 mA / 0–10 VDC |
| Resolution | 12-bit (1 in 4096) |
| Accuracy | ±0.1% of full scale (typical) |
| Isolation | Field-to-backplane optical isolation |
| Backplane Bus | Series 90-30 standard I/O bus |
| Power Consumption | Supplied via backplane (5 VDC) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | Standard Series 90-30 single-slot module |
| Weight | Approx. 100 g |
| Certifications | UL Listed, CE Marked |
| Compatible CPUs | IC693CPU311, IC693CPU313, IC693CPU321, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU364, IC693CPU374 |
| Compatible Bases | IC693CHS391, IC693CHS392, IC693CHS393, IC693CHS398, IC693CHS399 |
Proven Application Environments
- Process Manufacturing: Temperature, pressure, and flow loop control via 4–20 mA transmitters and control valves
- Discrete Manufacturing: Analog position feedback from linear transducers and servo drives
- Water & Wastewater: Level sensing and pump speed reference output in SCADA-integrated systems
- Oil & Gas: Field instrument signal aggregation in hazardous-area panel builds (with appropriate barriers)
- Building Automation: HVAC damper control and sensor monitoring in legacy BAS retrofits
- OEM Machine Builders: Tension control, web guiding, and analog recipe management
Engineering Advantages
- Mixed I/O in One Slot: Combines 4 analog inputs and 2 analog outputs, reducing slot consumption and wiring complexity versus discrete analog modules
- 12-Bit Resolution: Provides 4096-count precision suitable for closed-loop PID control without external signal conditioning
- Optical Isolation: Field-to-backplane isolation protects the CPU from ground loops and transient surges common in industrial environments
- Flexible Signal Ranges: Jumper-selectable current and voltage ranges accommodate diverse field instruments without additional hardware
- Hot-Swap Compatible: Supports module replacement without full system shutdown when used with appropriate Series 90-30 chassis configurations
- Proven Longevity: Designed for 24/7 continuous operation in harsh industrial environments with extended MTBF
System Architecture & Signal Flow
The IC693ALG391 occupies a single slot in any Series 90-30 5-slot, 10-slot, or expansion chassis. Field wiring connects to the module’s removable terminal block. Analog input signals are sampled, converted by the 12-bit ADC, and written to the CPU’s %AI reference table each scan. Analog output values are read from the CPU’s %AQ reference table and converted by the 12-bit DAC to drive field actuators. The optical isolation barrier separates field commons from the backplane 5 VDC logic supply, ensuring signal integrity across mixed-ground industrial installations.
Signal path: Field Instrument → Terminal Block → Input Conditioning → 12-bit ADC → Backplane Bus → CPU %AI Table
Output path: CPU %AQ Table → Backplane Bus → 12-bit DAC → Output Driver → Terminal Block → Field Actuator
Sourcing & Quality Verification
- All IC693ALG391 units sourced through authorized distribution channels or verified surplus with full traceability documentation
- Each module undergoes functional power-on verification and visual inspection prior to shipment
- Original GE Fanuc firmware and hardware — no counterfeit or refurbished-without-disclosure units
- Packaging: Anti-static bag, foam-lined carton, with part number label and inspection record
- Certificate of conformance available upon request for regulated industries
Procurement Process
- Confirm Compatibility: Verify your Series 90-30 chassis model and CPU firmware revision against the compatible CPU list above
- Request Quote: Contact support@konmask.com for volume pricing, lead time, and availability confirmation
- Place Order: Purchase directly via this listing or submit a PO for NET terms (qualified accounts)
- Shipping: DHL / FedEx / UPS international express available; EXW Xiamen or CIF destination port options
- Documentation: Commercial invoice, packing list, and CoC provided with every shipment
Technical FAQ
Q: Is the IC693ALG391 compatible with the IC693CPU374 (Ethernet CPU)?
A: Yes. The IC693ALG391 is compatible with all Series 90-30 CPUs including the IC693CPU374, as analog I/O modules communicate via the backplane bus independent of the CPU’s communication interface.
Q: Can I mix current and voltage inputs on the same module?
A: Yes. Each input channel is independently configurable via jumper for either current (4–20 mA) or voltage (0–10 V / ±10 V) input ranges.
Q: What is the scan time impact of adding this module?
A: Analog I/O modules in the Series 90-30 are scanned asynchronously from the CPU logic scan. The IC693ALG391 updates its I/O values each backplane scan cycle, typically adding less than 1 ms to overall system scan time.
Q: Is a replacement terminal block available separately?
A: Yes. The removable terminal block for the IC693ALG391 is field-replaceable. Contact us for spare terminal block availability.
Q: Do you provide a warranty?
A: Yes. All modules sold through Konmask.com carry a 90-day functional warranty. Extended warranty options are available — contact us for details.
