GE IC693CPU331 – Single-Slot CPU Module | Series 90-30 PLC Platform
Engineering Background
The IC693CPU331 is a mid-range central processing unit designed for GE Fanuc’s Series 90-30 modular PLC platform — one of the most widely deployed control architectures in North American discrete and process manufacturing. Introduced as a cost-optimized alternative to higher-tier CPUs in the 90-30 family, the CPU331 delivers deterministic scan performance and robust I/O handling in a compact single-slot form factor, making it the preferred choice for machine-level control and distributed automation cells.
Product Positioning
Targeted at procurement engineers managing MRO replacement, line-for-line upgrades, and spare-parts inventory for legacy Series 90-30 installations, the IC693CPU331 provides a direct drop-in solution without requiring program migration or rack reconfiguration. Konmask.com maintains verified stock sourced from authorized channels, supporting both single-unit emergency procurement and bulk MRO orders.
Complete Technical Specifications
| Part Number | IC693CPU331 |
| Manufacturer | GE Fanuc / General Electric |
| Platform | Series 90-30 (90-30 PLC) |
| Form Factor | Single-slot CPU module |
| Logic (Program) Memory | 6K words |
| Data Memory | 12K words |
| Scan Speed | 0.6 ms / 1K boolean instructions |
| I/O Points Supported | Up to 512 discrete I/O (local + remote) |
| Communication Ports | 1 × RS-232 serial (programming port) |
| Programming Software | Proficy Machine Edition (ME) / Logicmaster 90-30 |
| Rack Compatibility | IC693CHS391, IC693CHS392, IC693CHS393, IC693CHS398, IC693CHS399 |
| Power Supply Compatibility | IC693PWR321, IC693PWR322, IC693PWR330, IC693PWR331 |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Supply Voltage | +5 VDC (rack-supplied) |
| Weight | 280 g (approx.) |
| Certifications | UL Listed, CE Marked, CSA |
Proven Application Environments
- Discrete Manufacturing: Assembly lines, conveyor control, press automation, and robotic cell coordination requiring deterministic scan cycles.
- Packaging Machinery: Form-fill-seal machines, labelers, and palletizers where compact CPU footprint and reliable I/O throughput are critical.
- HVAC & Building Automation: Chiller plant control, air handling unit sequencing, and BMS integration via serial communication.
- Water & Wastewater Treatment: Pump station control, dosing systems, and remote I/O expansion in distributed plant architectures.
- Food & Beverage Processing: Batch control, CIP sequencing, and line monitoring in environments requiring UL/CE compliance.
- MRO / Spare Parts: Direct replacement for failed CPU331 units in existing Series 90-30 installations without rack or wiring changes.
Engineering Advantages
- Single-Slot Efficiency: Occupies only one rack slot, preserving valuable backplane positions for I/O and specialty modules in space-constrained enclosures.
- Deterministic Scan Performance: 0.6 ms/K boolean scan speed ensures predictable cycle times for time-sensitive machine control applications.
- Backward Program Compatibility: Executes ladder logic developed under Logicmaster 90-30 and Proficy ME without code conversion, minimizing downtime during replacement.
- Broad Rack Compatibility: Supports all standard Series 90-30 baseplate configurations (5-slot through 10-slot), enabling flexible system expansion.
- Proven Field Reliability: Deployed across tens of thousands of installations globally; well-documented failure modes and established repair/replacement procedures.
- Low Total Cost of Ownership: Competitive acquisition cost relative to higher-tier 90-30 CPUs, with widely available programming tools and technical documentation.
System Architecture & Signal Flow
The IC693CPU331 occupies Slot 1 of any Series 90-30 rack. On power-up, the CPU performs a self-diagnostic sweep, initializes the I/O table, and enters the standard PLC scan cycle:
- Input Scan: Reads all discrete and analog input module states into the CPU’s input image table.
- Program Execution: Executes the user ladder logic program sequentially, updating the output image table based on logic results.
- Output Scan: Writes the output image table values to all discrete and analog output modules in the rack and on remote I/O drops.
- Communications: Services the RS-232 programming port for online monitoring, program upload/download, and fault diagnostics via Proficy ME or Logicmaster.
Remote I/O expansion is supported via the IC693BEM331 Bus Expansion Module, extending the system to additional racks without additional CPU resources.
Sourcing & Quality Verification
- Source Traceability: All IC693CPU331 units offered by Konmask.com are sourced from authorized distributors, OEM decommissions, or verified MRO channels — never counterfeit or refurbished-without-disclosure.
- Pre-Shipment Inspection: Each unit undergoes visual inspection for physical damage, label integrity, firmware version verification, and connector condition assessment prior to dispatch.
- Condition Disclosure: Product condition (New, Surplus New, Refurbished) is explicitly stated on each listing. Contact support for condition-specific availability.
- Documentation: Original GE Fanuc datasheets and installation guides available upon request. Certificate of conformance provided for bulk orders.
Procurement Process
- Confirm Part Number: Verify IC693CPU331 against your existing rack label, system drawing, or GE Fanuc BOM. Cross-reference with IC693CPU331-EJ (enhanced EPROM variant) if applicable.
- Specify Quantity & Condition: Contact Konmask.com for bulk pricing, lead time, and condition availability (New / Surplus / Refurbished).
- Request Quotation: Email support@konmask.com or call +0086 19859288691 with your PO requirements, delivery address, and any compliance documentation needs.
- Order Confirmation: Orders confirmed within 1 business day. Expedited processing available for emergency MRO requirements.
- Shipping & Logistics: Global shipping via DHL, FedEx, or UPS. ESD-safe packaging standard. Export documentation (commercial invoice, packing list, COO) included.
- Post-Delivery Support: 30-day return window for DOA units. Technical support available for installation and commissioning queries.
Technical FAQ
Q: Is the IC693CPU331 compatible with Proficy Machine Edition software?
A: Yes. Proficy ME fully supports the CPU331 for online programming, monitoring, and diagnostics. Legacy Logicmaster 90-30 programs can be imported and converted within ME.
Q: Can the CPU331 communicate with SCADA systems?
A: The CPU331’s RS-232 port supports SNP and SNP-X protocols natively. For Ethernet/SRTP or Modbus TCP connectivity, an IC693CMM321 or IC693CMM311 communications module must be added to the rack.
Q: What is the maximum I/O capacity of a CPU331-based system?
A: Up to 512 discrete I/O points (local and remote combined). Analog I/O capacity depends on the specific analog modules installed and their channel counts.
Q: Is the CPU331 a direct replacement for the IC693CPU323 or IC693CPU340?
A: The CPU331 is not pin-for-pin equivalent to higher-tier CPUs (CPU340/341/350/360/374). Program memory and feature sets differ. Consult GE Fanuc’s CPU comparison matrix (GFK-0356) before substituting across CPU tiers.
Q: Does Konmask.com provide warranty on this module?
A: Yes. All units carry a minimum 90-day functional warranty. Extended warranty options are available for bulk procurement contracts. Contact support for details.
Q: What firmware version is installed?
A: Firmware version varies by production lot. Konmask.com can specify firmware version upon request for compatibility-critical applications. Firmware upgrades are performed via the RS-232 programming port using GE-supplied utilities.
