Process Control Solution – GE IC693PTM101A | Series 90-30 Transducer Input Module
The GE IC693PTM101A is a high-precision transducer input module designed for the GE Series 90-30 PLC platform. It accepts signals from strain gauge and bridge-type transducers, enabling accurate measurement of force, pressure, torque, and weight in demanding industrial environments. Sourced from verified channels and fully tested before shipment.
Where This Product Is Used
- Weighing & Batching Systems — Integrates with load cells on conveyor scales, hopper weighers, and batch blending stations for real-time weight feedback to the PLC.
- Press & Force Monitoring — Captures strain gauge data from hydraulic and mechanical presses to enforce tonnage limits and detect tooling anomalies.
- Torque Measurement — Used in motor test benches and assembly torque verification stations where precise torque feedback is critical.
- Pressure Transducer Inputs — Connects bridge-type pressure sensors in oil & gas, water treatment, and chemical processing pipelines.
- Structural Load Monitoring — Deployed in civil and industrial structural health monitoring systems requiring continuous strain data acquisition.
- Food & Beverage Filling Lines — Provides accurate fill-weight control on bottling and packaging lines with hygienic load cell installations.
Technical Specifications
- Part Number: IC693PTM101A
- Platform: GE Series 90-30 PLC (IC693 family)
- Module Type: Transducer / Bridge Input Module
- Input Signal: Strain gauge / Wheatstone bridge transducers
- Excitation Voltage: 10 V DC (supplied to transducer)
- Input Range: ±15 mV to ±120 mV (bridge output)
- Resolution: 16-bit A/D conversion
- Channels: 1 channel per module
- Backplane Interface: Series 90-30 I/O bus
- Power Consumption: 5 V DC from backplane
- Operating Temperature: 0 °C to 60 °C
- Dimensions: Standard Series 90-30 single-slot module
- Weight: Approx. 200 g
- Firmware: Compatible with GE Proficy Machine Edition / Logicmaster 90
Why Engineers Specify This Model
- Native Series 90-30 Integration — Slots directly into any IC693 rack with no external signal conditioner required, reducing panel footprint and wiring complexity.
- High-Resolution 16-bit ADC — Delivers measurement accuracy suitable for legal-for-trade weighing and precision force control applications.
- Onboard Excitation — Built-in 10 V bridge excitation eliminates the need for a separate transducer power supply.
- Proven Field Reliability — The IC693 platform has a multi-decade installed base in automotive, food processing, and heavy industry worldwide.
- Simple Configuration — Configured via Proficy ME or Logicmaster 90 with no DIP switches; all parameters set in software.
- Drop-in Replacement — Compatible with existing Series 90-30 racks and power supplies; no rack modification required.
Complete System Bill of Materials
- IC693PTM101A — Transducer Input Module (this item)
- IC693CPU374 or compatible — Series 90-30 CPU module
- IC693CHS391 / IC693CHS392 — 5-slot or 10-slot Series 90-30 baseplate
- IC693PWR321 — Series 90-30 24 VDC power supply module
- IC693CBL316 — I/O terminal block cable (if using remote I/O)
- Bridge/strain gauge transducer (customer-supplied, 350 Ω or 700 Ω recommended)
- Shielded 4-wire or 6-wire transducer cable
Compliance & Industry Standards
- CE Marked — Compliant with EU Machinery Directive and EMC Directive
- UL Listed — Recognized for use in industrial control panels (UL 508A)
- RoHS Compliant — Meets EU Directive 2011/65/EU on restriction of hazardous substances
- Compatible with OIML R 76 / NTEP weighing system requirements when used with certified load cells
- Designed to IEC 61131-2 programmable controller hardware standards
Quality Assurance & Sourcing
- Tested Before Shipment — Every unit undergoes functional power-on and I/O verification testing prior to dispatch.
- Authentic Parts Only — Sourced exclusively from authorized distributors and verified surplus channels; no counterfeit or refurbished-as-new units.
- Secure Anti-Static Packaging — Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability — Batch and serial records maintained for quality audit purposes.
- Warranty — 12-month warranty against manufacturing defects; replacement or full refund policy.
How to Source This Part
The IC693PTM101A is available for immediate dispatch from Konmask.com. To place an order or request a formal quotation:
- Add to cart directly on this page for standard orders.
- Email support@konmask.com for bulk pricing, lead-time confirmation, or export documentation.
- Call / WhatsApp: +0086 19859288691 for urgent requirements.
- We support T/T bank transfer, PayPal, and major credit cards. Export invoices and packing lists provided for customs clearance.
Application-Specific FAQ
Q: Can the IC693PTM101A accept 4–20 mA current loop signals?
A: No. This module is designed specifically for bridge/strain gauge transducers (millivolt output). For 4–20 mA inputs, use the GE IC693ALG222 analog input module instead.
Q: How many IC693PTM101A modules can I install in one rack?
A: Multiple modules can be installed in the same rack, limited only by available slots and backplane power budget. Each module occupies one slot.
Q: Is this module compatible with the Series 90-70 or PACSystems RX3i?
A: No. The IC693PTM101A is exclusive to the Series 90-30 (IC693) backplane. It is not compatible with IC697 (Series 90-70) or IC695 (RX3i) racks.
Q: What cable type is recommended for the transducer connection?
A: Use shielded, twisted-pair cable (Belden 9842 or equivalent) with the shield grounded at the module end only to minimize noise pickup.
Q: Can I use a 6-wire load cell for remote sense?
A: Yes. The IC693PTM101A supports 6-wire connections with sense lines to compensate for cable resistance, improving accuracy over long cable runs.
Q: What software is required for configuration?
A: GE Proficy Machine Edition (ME) or the legacy Logicmaster 90-30 programming software. No additional hardware configurator is needed.
