Industrial Automation Solution – GE IC695CHS012-BA | PACSystems RX3i Universal Backplane
Where This Product Is Used
The GE IC695CHS012-BA is a 12-slot universal backplane designed for the GE PACSystems RX3i control platform. It is deployed across a wide range of demanding industrial environments where high-density I/O and modular scalability are critical:
- Automotive Manufacturing – Body-in-white welding lines, paint shop conveyors, and assembly transfer systems requiring deterministic scan times and hot-swap I/O capability.
- Oil & Gas Processing – Wellhead control panels, compressor skids, and pipeline SCADA nodes where the universal backplane accommodates both standard and high-speed serial communication modules in a single rack.
- Power Generation & Utilities – Turbine governor systems, substation automation, and load-shedding controllers that leverage the RX3i’s IEC 61131-3 programming environment.
- Water & Wastewater Treatment – Pump station PLCs, SCADA-integrated remote I/O racks, and chemical dosing systems requiring UL 508A panel compliance.
- Food & Beverage – CIP (Clean-In-Place) control panels, filling line PLCs, and batch management systems where the 12-slot density reduces panel footprint.
- Discrete Manufacturing – Machine tool controllers, robotic cell integration, and material handling systems using PROFINET or EtherNet/IP communication modules installed in the same backplane.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | IC695CHS012-BA |
| Series | GE PACSystems RX3i |
| Slot Count | 12 universal slots |
| Backplane Type | Universal (CPU + I/O + Communications) |
| Bus Architecture | RX3i high-speed backplane bus (PCI-based) |
| Power Supply Slots | Dedicated power supply slot (left-side) |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | Approx. 300 g |
| Revision | -BA |
| Compatibility | All IC695 / IC694 series modules |
Why Engineers Specify This Model
- Universal Slot Architecture – Any slot accepts CPU, I/O, or communication modules, eliminating fixed-slot constraints found in legacy Series 90-30 racks and simplifying panel layout changes.
- High-Speed PCI Backplane Bus – Delivers significantly higher throughput than the legacy VME bus, enabling faster scan times for motion and high-speed counter applications.
- Backward Compatibility – Accepts IC694 (Series 90-30) I/O modules via the universal bus, protecting existing I/O investments during platform migrations.
- Scalable Density – 12 slots provide maximum on-rack density; expansion racks (IC695CHS016) can be daisy-chained for larger systems.
- -BA Revision – Latest production revision incorporating PCB and connector improvements for enhanced long-term reliability in harsh environments.
- Hot-Swap Ready – Supports module insertion and removal under power when used with compatible RX3i CPUs, minimizing unplanned downtime.
Complete System Bill of Materials
A typical PACSystems RX3i control system built around the IC695CHS012-BA includes:
- CPU Module – IC695CPU320 / IC695CPE330 / IC695CPE400 (Ethernet-enabled)
- Power Supply – IC695PSA040 (120/240 VAC, 40 W) or IC695PSD040 (24 VDC)
- Digital Input Module – IC695MDL654 (32-ch, 24 VDC)
- Digital Output Module – IC695MDL764 (32-ch, 24 VDC, 0.5 A)
- Analog Input Module – IC695ALG608 (8-ch, 4–20 mA / 0–10 V)
- Analog Output Module – IC695ALG704 (4-ch, 4–20 mA)
- EtherNet/IP Comm Module – IC695ETM001
- PROFINET Controller – IC695PNC001
- Backplane (this unit) – IC695CHS012-BA
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- IEC 61131-2 – Programmable Controllers: Equipment Requirements & Tests
- RoHS Compliant – Restriction of Hazardous Substances
- ATEX / Class I Div 2 – Suitable for use in systems installed in non-incendive locations (verify with system integrator)
- ODVA EtherNet/IP Conformance – When paired with IC695ETM001
Quality Assurance & Sourcing
Every IC695CHS012-BA unit offered by Konmask.com undergoes a structured verification process before dispatch:
- Visual inspection of PCB, backplane connectors, and mounting hardware
- Revision marking verification (-BA confirmed)
- Functional power-up test where applicable
- Anti-static packaging with humidity indicator card
- Traceable documentation available upon request (test reports, CoC)
We source from authorized distribution channels and verified industrial surplus with full traceability. Counterfeit-free guarantee backed by our sourcing policy.
How to Source This Part
- In Stock: Add to cart and check out directly — most orders ship within 1–3 business days.
- Bulk / Project Quantity: Contact us for volume pricing and lead-time commitment on BOM fulfillment.
- Urgent Requirement: Email support@konmask.com or call +0086 19859288691 for same-day quotation.
- Global Shipping: We ship worldwide via DHL, FedEx, and UPS with full export documentation (commercial invoice, packing list, COO).
Application-Specific FAQ
Q: Can I mix IC694 and IC695 modules in the IC695CHS012-BA?
A: Yes. The universal backplane supports both IC694 (Series 90-30) and IC695 (RX3i) I/O modules. However, IC694 CPU modules are not compatible — only IC695 CPUs are supported.
Q: How many IC695CHS012-BA expansion racks can I connect to one CPU?
A: The RX3i system supports up to 7 expansion racks (IC695CHS016 or IC695CHS012) connected via the RX3i expansion bus, for a maximum of 512 I/O points per rack.
Q: Is the -BA revision backward compatible with earlier -AA revision systems?
A: Yes. The -BA revision is a drop-in replacement for -AA units. No firmware or configuration changes are required.
Q: What power supply is required for a fully loaded 12-slot rack?
A: A fully loaded rack with high-current output modules may require the IC695PSA040 (40 W). Always perform a power budget calculation using GE’s PACSystems RX3i System Manual (GFK-2314).
Q: Does Konmask.com provide a warranty on this part?
A: Yes. We offer a 90-day functional warranty on all units. Extended warranty and repair services are available — contact us for details.
