GE IC695CHS016CA Universal Backplane | Replacement, Equivalent & Selection Guide
The GE IC695CHS016CA is a 16-slot universal backplane designed for the GE PACSystems RX3i PLC platform. It supports both Series 90-30 and RX3i I/O modules, making it one of the most versatile rack options in the GE automation ecosystem. At Konmask.com, we specialize in sourcing, verifying, and supplying original and equivalent automation components for industrial buyers worldwide.
Technical Specifications
- Part Number: IC695CHS016CA
- Series: GE PACSystems RX3i
- Slot Count: 16 slots (universal)
- Backplane Type: Universal (supports RX3i & Series 90-30 I/O modules)
- Power Supply Compatibility: IC695PSA040, IC695PSD040, IC695PSA140
- CPU Compatibility: IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE330, IC695CPE400
- Mounting: DIN rail or panel mount
- Weight: Approx. 1,300 g
- Operating Temperature: 0°C to 60°C
- Certifications: CE, UL, cUL
- Country of Origin: USA
Compatible Replacement & Equivalent Models
If the IC695CHS016CA is unavailable or you are evaluating alternatives, the following models offer compatible or equivalent functionality:
- IC695CHS012CA – GE RX3i 12-slot universal backplane (fewer slots, same platform)
- IC695CHS007CA – GE RX3i 7-slot universal backplane (compact applications)
- IC694CHS392 – GE Series 90-30 10-slot rack (legacy, non-universal)
- IC694CHS398 – GE Series 90-30 5-slot rack (legacy, compact)
- Emerson IC695CHS016CA – Same part, rebranded after GE Automation acquisition by Emerson
Note: Always verify CPU and power supply compatibility before substituting backplane models. Contact support@konmask.com for a free compatibility check.
Why Choose the Original IC695CHS016CA
- Maximum Slot Density: 16 slots provide the highest I/O capacity in the RX3i rack family, minimizing the need for expansion chassis.
- Universal Compatibility: Accepts both RX3i and legacy Series 90-30 I/O modules — protecting your existing module investment during platform migration.
- Proven Reliability: Designed and tested to GE’s industrial-grade standards for 24/7 continuous operation in harsh environments.
- Firmware & Software Support: Fully supported by Proficy Machine Edition and PAC Machine Edition programming environments.
- Long Service Life: Robust backplane bus design reduces signal degradation over extended operational periods.
Typical Applications
- Discrete manufacturing automation (automotive, electronics assembly)
- Process control systems (chemical, oil & gas, water treatment)
- Power generation and distribution control
- Building automation and HVAC control
- Infrastructure and transportation control systems
- Legacy Series 90-30 to RX3i platform migration projects
System Compatibility
The IC695CHS016CA is compatible with the following GE PACSystems RX3i components:
- CPUs: IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE330, IC695CPE400, IC695CPL410
- Power Supplies: IC695PSA040 (40W AC), IC695PSD040 (40W DC), IC695PSA140 (140W AC)
- Communications: IC695ETM001 (Ethernet), IC695PBM300 (PROFIBUS), IC695CMM002 (Serial)
- I/O Modules: All IC694 and IC695 series analog and digital I/O modules
- Programming Software: Proficy Machine Edition 8.x and above, PAC Machine Edition
Selection Guide
Use this guide to select the right RX3i backplane for your application:
- Need maximum I/O in a single rack? → Choose IC695CHS016CA (16 slots)
- Mid-size application, cost-sensitive? → Consider IC695CHS012CA (12 slots)
- Compact panel or limited space? → Consider IC695CHS007CA (7 slots)
- Migrating from Series 90-30? → IC695CHS016CA supports both module families — ideal for phased migration
- Expanding an existing RX3i system? → Use IC695CHS016CA as an expansion rack with IC695CMX128 expansion cable
Not sure which model fits your system? Send your existing rack configuration to support@konmask.com and our engineers will recommend the optimal solution.
Quality Assurance & Sourcing
- Origin Verification: All units are sourced from authorized distributors or directly from GE/Emerson-certified channels.
- Inspection: Each unit undergoes visual inspection, label verification, and functional testing before shipment.
- Authenticity: We do not supply counterfeit, refurbished-as-new, or grey-market parts without explicit disclosure.
- Documentation: Certificate of conformance and test reports available upon request.
- Warranty: 12-month warranty against manufacturing defects on all stocked units.
How to Order
- Add the IC695CHS016CA to your cart and proceed to checkout.
- For bulk orders (5+ units) or urgent requirements, contact us directly for priority pricing and lead time confirmation.
- Provide your shipping address and preferred freight method (DHL, FedEx, sea freight available).
- Payment accepted via T/T bank transfer, PayPal, and major credit cards.
- Tracking number provided within 24 hours of shipment.
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can IC695CHS016CA replace IC694CHS392 (Series 90-30 rack)?
A: Not directly — the physical form factor differs. However, IC695CHS016CA accepts IC694-series I/O modules, so you can migrate your existing modules to the new rack while upgrading the CPU and power supply.
Q: Is IC695CHS016CA the same as the Emerson IC695CHS016CA?
A: Yes. After Emerson acquired GE’s automation business, the part number remained identical. Both are functionally and physically equivalent.
Q: Can I mix RX3i and Series 90-30 modules in the same IC695CHS016CA rack?
A: Yes — this is the key advantage of the universal backplane. Both module families can coexist in the same rack.
Q: What is the maximum number of IC695CHS016CA racks in one RX3i system?
A: Up to 8 expansion racks can be connected to a single RX3i CPU, providing up to 128 additional I/O slots.
Q: Do you ship IC695CHS016CA internationally?
A: Yes. We ship worldwide via DHL, FedEx, and sea freight. Contact us for a shipping quote to your location.
