GE IC695CHS016LT Universal Backplane – PACSystems RX3i 16-Slot Rack
When a PACSystems RX3i backplane fails or is unavailable, the entire control system comes to a halt. Every I/O module, every CPU, every communication card loses its physical and electrical foundation. Production lines stop, process variables go unmonitored, and the cost of downtime escalates by the minute. The GE IC695CHS016LT Universal Backplane is the structural and electrical backbone that keeps your RX3i system running — without it, there is no system.
The IC695CHS016LT is GE’s 16-slot universal backplane within the IC695 series, designed for the PACSystems RX3i platform — one of the most widely deployed mid-to-large-scale PLC architectures in global process and discrete manufacturing. Its “universal” designation means it accepts both legacy Series 90-30 I/O modules and native RX3i modules in the same rack, making it the preferred choice for system expansions and brownfield upgrades across industries worldwide.
Technical Specifications
- Part Number: IC695CHS016LT
- Series: GE PACSystems RX3i (IC695 Series)
- Slot Count: 16 slots (universal)
- Backplane Type: Universal — supports RX3i and Series 90-30 I/O modules
- Power Supply Slots: Dedicated power supply slot (left-side)
- Mounting: DIN rail and panel mount compatible
- Weight: Approx. 6.2 kg
- Manufacturer: GE (General Electric Automation / Emerson)
- Compliance: CE, UL listed (refer to GE datasheet for full certifications)
Note: All specifications are sourced from GE official documentation. Konmask.com does not fabricate or alter technical parameters.
Key Features & Benefits
- 16-Slot Universal Architecture: Maximizes I/O density in a single rack, reducing cabinet footprint and wiring complexity.
- Backward Compatibility: Accepts Series 90-30 I/O modules alongside native RX3i modules — critical for phased migration projects.
- High-Speed Backplane Bus: Supports the RX3i high-speed serial backplane for fast CPU-to-I/O communication.
- Robust Industrial Construction: Designed for 24/7 operation in harsh industrial environments with wide temperature tolerance.
- Scalable System Design: Supports multi-rack expansion via rack interconnect cables, enabling large-scale distributed I/O architectures.
- Hot-Swap Ready: Compatible with hot-swap capable modules for minimal maintenance downtime.
Industry & Equipment Applications
- Oil & Gas: Pipeline SCADA systems, compressor control, wellhead automation
- Power Generation: Turbine control, substation automation, load management
- Water & Wastewater: Pump station control, treatment plant automation
- Automotive Manufacturing: Assembly line control, robotic cell integration
- Food & Beverage: Batch processing, conveyor control, packaging lines
- Chemical & Pharmaceutical: Reactor control, clean-room automation, SIL-rated applications
- Mining & Metals: Crusher control, conveyor systems, smelter automation
System Integration & Compatible Parts
The IC695CHS016LT is designed to work seamlessly within the GE PACSystems RX3i ecosystem. Commonly paired components include:
- CPU Modules: IC695CPU310, IC695CPU315, IC695CPU320
- Power Supplies: IC695PSA040, IC695PSD040, IC695PSA140
- Communication Modules: IC695ETM001, IC695PBM300, IC695CMM002
- I/O Modules: IC694MDL340, IC694MDL754, IC694ALG220 (Series 90-30 compatible)
- Expansion Cables: IC693CBL300, IC693CBL302 for multi-rack configurations
Our Quality Assurance Process
At Konmask.com, every IC695CHS016LT unit undergoes a rigorous multi-stage inspection before shipment:
- Visual inspection for physical damage, bent pins, and connector integrity
- Verification of part number label and firmware revision markings
- Functional bench test where applicable
- Anti-static packaging with humidity indicator cards
- Full traceability documentation provided upon request
We source from authorized distributors and verified industrial surplus channels. Counterfeit parts are never knowingly stocked or shipped.
How to Order
- Submit an inquiry via the “Request a Quote” button on this page
- Provide your required quantity, delivery timeline, and destination country
- Our team responds within 1 business day with pricing, lead time, and shipping options
- Confirm the proforma invoice and arrange payment via T/T, PayPal, or other agreed methods
- We ship via DHL, FedEx, UPS, or sea freight — with full tracking provided
Why Choose Konmask.com?
- ✅ Specialized in GE PACSystems, Siemens, Rockwell, ABB, and Schneider automation components
- ✅ Global B2B supply — serving clients in 50+ countries
- ✅ Fast response: inquiries answered within 24 hours
- ✅ Competitive pricing with volume discount options
- ✅ Secure export packaging and customs documentation support
- ✅ Long-term partnership focus — not just a one-time transaction
Frequently Asked Questions
Q: Is the IC695CHS016LT compatible with Series 90-30 I/O modules?
A: Yes. The “universal” designation means it accepts both native PACSystems RX3i modules and legacy Series 90-30 I/O modules in the same rack.
Q: What is the difference between IC695CHS016 and IC695CHS016LT?
A: The “LT” suffix typically denotes a specific hardware revision or regional variant. Always verify the exact part number against your system’s BOM before ordering.
Q: Can I use this backplane in a multi-rack RX3i system?
A: Yes. The IC695CHS016LT supports multi-rack expansion using GE-approved expansion cables, allowing you to build large distributed I/O architectures.
Q: Do you provide a warranty?
A: Yes. We offer a standard 90-day warranty against defects. Extended warranty options are available — contact us for details.
Q: What is the lead time for IC695CHS016LT?
A: Lead time depends on current stock levels. In-stock units typically ship within 3–5 business days. Contact us for real-time availability.
