GE IC695CPK330-ACAS – High-Performance RX3i CPU Processor Module | PACSystems RX3i Platform
Engineering Background: The IC695CPK330-ACAS is a flagship CPU module within GE’s PACSystems RX3i control platform — a unified, scalable architecture designed for demanding industrial automation environments. Built on GE’s legacy of process control excellence, the RX3i platform bridges legacy Series 90-30/70 compatibility with modern IEC 61131-3 programming and high-speed Ethernet connectivity.
Product Positioning: Targeted at procurement engineers and system integrators managing continuous process, discrete manufacturing, and hybrid control applications, the IC695CPK330-ACAS delivers enterprise-grade processing power in a modular backplane form factor. It is the preferred choice for brownfield upgrades and greenfield installations requiring deterministic scan times, redundancy-ready architecture, and long-term GE Vernova support.
Complete Technical Specifications
- Part Number: IC695CPK330-ACAS
- Platform: PACSystems RX3i
- Processor Speed: 1.1 GHz Intel Celeron M
- User Memory (RAM): 64 MB
- Flash Storage: 256 MB internal flash
- Ethernet Ports: 2 × 10/100 Mbps RJ-45 (embedded dual Ethernet)
- Serial Ports: 1 × RS-232 (front panel), 1 × RS-485 (optional)
- USB Port: 1 × USB 2.0 (front panel, for programming/firmware)
- Backplane Bus: RX3i universal backplane (IC695CHS series)
- Supported Protocols: SRTP, Modbus TCP, EGD (Ethernet Global Data), OPC DA
- Programming Standards: IEC 61131-3 (LD, FBD, ST, IL, SFC)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% non-condensing
- Power Consumption: Approx. 13 W (from backplane)
- Dimensions (H × W × D): 230 mm × 70 mm × 130 mm (approx.)
- Weight: ~1,250 g
- Certifications: CE, UL, cUL, RoHS compliant
- Firmware: Supports RX3i firmware v8.x and above
- Redundancy: Compatible with IC695RMX128 redundancy module
- Software: Proficy Machine Edition (PME) v8.0+
Proven Application Environments
- Oil & Gas: Pipeline SCADA, compressor control, wellhead automation
- Power Generation: Turbine control, substation automation, load management
- Water & Wastewater: Pump station control, SCADA integration, remote telemetry
- Chemical & Petrochemical: Batch process control, reactor management, safety interlocks
- Automotive Manufacturing: Assembly line sequencing, robotic cell coordination
- Food & Beverage: CIP/SIP process control, packaging line automation
- Discrete Manufacturing: High-speed motion coordination, multi-axis synchronization
Engineering Advantages
- Dual Embedded Ethernet: Eliminates the need for a separate Ethernet module, reducing slot consumption and BOM cost
- Hot-Swap Capable: Supports online replacement in redundant configurations without process interruption
- Legacy Compatibility: Executes Series 90-30 and 90-70 logic with minimal re-engineering via PACSystems migration tools
- Deterministic Scan Performance: Sub-millisecond scan times achievable for time-critical discrete control loops
- Scalable I/O: Supports up to 32 backplane slots across multiple expansion racks via RX3i bus transmitter modules
- Integrated Diagnostics: Built-in fault table, I/O fault logging, and remote diagnostics via Ethernet
- Long Product Lifecycle: GE Vernova committed support roadmap through 2030+
System Architecture & Signal Flow
The IC695CPK330-ACAS occupies Slot 0 of the RX3i universal backplane (IC695CHS012 / IC695CHS016). The CPU communicates with I/O modules via the high-speed RX3i backplane bus (up to 320 MB/s). Dual Ethernet ports connect directly to plant LAN/SCADA networks for SRTP and EGD communications. The front-panel USB port provides direct connection to a Proficy Machine Edition engineering workstation for program download, online monitoring, and firmware updates. An optional IC695RMX128 redundancy module in an adjacent slot enables CPU-level hot-standby redundancy with automatic bumpless transfer.
Typical Signal Flow: Field I/O → RX3i I/O Modules → Backplane Bus → IC695CPK330-ACAS CPU → Ethernet → SCADA/HMI / Historian
Sourcing & Quality Verification
- Source: Procured from authorized GE Vernova distributors and verified industrial surplus channels
- Inspection: Each unit undergoes visual inspection, label verification, and functional power-on test prior to shipment
- Authenticity: Part number, date code, and firmware version verified against GE Vernova product records
- Condition: New (factory-sealed) or Refurbished (tested, cleaned, re-labeled) — condition specified at order confirmation
- Warranty: 12-month Konmask operational warranty covering manufacturing defects and functional failure
- Traceability: Full documentation package available upon request (test report, CoC, photos)
Procurement Process
- Inquiry: Submit your RFQ via the product page or email support@konmask.com with quantity and required delivery date
- Quotation: Receive a formal quotation within 24 business hours including unit price, lead time, and shipping options
- Order Confirmation: Purchase order accepted via Shopify checkout, bank transfer (T/T), or PayPal
- Quality Check: Pre-shipment inspection completed and documentation issued
- Shipment: Dispatched via DHL / FedEx / UPS with full tracking; export documentation (commercial invoice, packing list) included
- After-Sales: Technical support available post-delivery; warranty claims processed within 5 business days
Technical FAQ
Q: Is the IC695CPK330-ACAS compatible with IC695CHS012 and IC695CHS016 backplanes?
A: Yes. It is compatible with all RX3i universal backplanes including IC695CHS012 (12-slot) and IC695CHS016 (16-slot).
Q: Can this CPU run Series 90-30 programs without modification?
A: In most cases, yes. GE’s PACSystems migration utility converts 90-30 programs with minimal manual intervention. Some hardware-specific instructions may require review.
Q: What version of Proficy Machine Edition is required?
A: PME v8.0 or higher is recommended. PME v9.x provides full feature support including advanced diagnostics and EGD configuration.
Q: Does the IC695CPK330-ACAS support EtherNet/IP?
A: Native EtherNet/IP scanner/adapter functionality requires an IC695ETM001 Ethernet module. The embedded ports support SRTP, EGD, and Modbus TCP natively.
Q: What is the maximum number of I/O points supported?
A: The RX3i platform supports up to 8,192 discrete I/O points and 2,048 analog channels depending on backplane and module configuration.
Q: Is redundancy supported?
A: Yes. CPU redundancy is supported via the IC695RMX128 module with automatic bumpless switchover. I/O redundancy requires compatible RX3i I/O modules.
