GE IC697MDL341 Discrete Output Module | Replacement, Equivalent & Selection Guide
The GE IC697MDL341 is a 32-point discrete output module designed for the GE Series 90-70 PLC platform. It delivers reliable 12/24VDC sourcing output capability for demanding industrial automation environments. Whether you are maintaining an existing 90-70 system, sourcing a replacement, or evaluating compatible alternatives, this guide provides the technical depth and selection clarity you need.
Technical Specifications
- Model: IC697MDL341
- Series: GE Series 90-70
- Module Type: Discrete Output Module
- Output Points: 32
- Output Voltage: 12/24VDC
- Output Type: Sourcing (PNP)
- Output Current: 0.5A per point
- Total Load Current: 4A per group (8 points)
- Isolation: Optical isolation between field and logic
- Backplane Compatibility: GE 90-70 Series racks (IC697CHS750, IC697CHS782, IC697CHS790)
- Operating Temperature: 0°C to 60°C
- Weight: 1620g (approx.)
- Form Factor: Single-slot module
Compatible Replacement & Equivalent Models
When the IC697MDL341 is unavailable or end-of-life, the following models offer functional or drop-in compatibility:
- IC697MDL340 — 32-point 12/24VDC output, sinking (NPN); same form factor, verify output polarity before substitution
- IC697MDL341D — Diagnostic variant with enhanced fault detection; direct functional equivalent with added diagnostics
- IC697MDL350 — 16-point 120VAC output; different voltage class, suitable only if field wiring is redesigned
- IC697MDL753 — 32-point 24VDC output module; verify current rating compatibility per application
- Horner HE693MDL341 — Third-party compatible module for 90-70 racks; confirm firmware revision compatibility
Note: Always verify rack slot compatibility, firmware version, and I/O configuration before substituting any module in a live system.
Why Choose the Original IC697MDL341
- ✅ Proven reliability in continuous 24/7 industrial operations
- ✅ Native GE 90-70 backplane integration — no adapter or configuration workaround required
- ✅ Optical isolation protects PLC logic from field-side voltage transients
- ✅ 32-point density maximizes I/O per rack slot, reducing hardware footprint
- ✅ Sourcing output (PNP) compatible with the majority of industrial sensors and actuators
- ✅ Long service history with extensive field documentation and support resources
Typical Applications
- Conveyor and material handling control systems
- Automotive assembly line automation
- Oil & gas process control panels
- Water treatment and utilities SCADA integration
- Packaging machinery and bottling lines
- Power generation plant auxiliary control
- Chemical plant distributed control systems (DCS interface)
System Compatibility
The IC697MDL341 is designed exclusively for the GE Series 90-70 PLC platform. Confirmed compatible racks and CPUs include:
- Racks: IC697CHS750 (5-slot), IC697CHS782 (9-slot), IC697CHS790 (9-slot VME)
- CPUs: IC697CPU731, IC697CPU771, IC697CPU781, IC697CPU782, IC697CPU788, IC697CPU789
- Power Supplies: IC697PWR710, IC697PWR711, IC697PWR724
- Programming Software: Proficy Machine Edition (ME) Logic Developer-PLC
This module is NOT compatible with GE Series 90-30, 90-20, VersaMax, or PACSystems RX3i/RX7i platforms without hardware redesign.
Selection Guide
Use the following criteria to confirm the IC697MDL341 is the right choice for your application:
- Platform: Must be GE Series 90-70 rack-based system
- Output polarity: Sourcing (PNP) — field devices must accept sourcing signals
- Voltage: 12VDC or 24VDC field supply
- Point count: Requires 32 discrete output points per slot
- Current per point: Load must not exceed 0.5A per output point
- Group current: Total load per 8-point group must not exceed 4A
If your application requires sinking (NPN) outputs, consider the IC697MDL340. If you need AC output capability, evaluate the IC697MDL350 or IC697MDL352.
Quality Assurance & Sourcing
- All units sourced through verified industrial automation supply channels
- Pre-shipment functional inspection and visual QC performed on every module
- Original manufacturer packaging preserved where available
- Traceability documentation available upon request for MRO and OEM customers
- Refurbished units clearly labeled and priced separately from new-surplus stock
Konmask.com specializes in hard-to-find and legacy PLC components for industrial maintenance teams and system integrators worldwide.
How to Order
- Confirm your rack model and available slot position
- Verify field wiring voltage (12VDC or 24VDC) and output polarity (sourcing/PNP)
- Add IC697MDL341 to cart or contact us for bulk/OEM pricing
- Provide your PO number or project reference for B2B invoicing
- Expedited shipping available for urgent MRO requirements
📧 Email: [email protected]
📞 Phone/WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can IC697MDL341 replace IC697MDL340?
A: Both are 32-point 12/24VDC modules but differ in output polarity — MDL341 is sourcing (PNP), MDL340 is sinking (NPN). Substitution requires verifying field device compatibility.
Q: Is IC697MDL341 compatible with PACSystems RX7i?
A: No. The IC697MDL341 is designed for the 90-70 backplane only. PACSystems RX7i uses a different module form factor and I/O bus architecture.
Q: Can I use a refurbished IC697MDL341 in a production environment?
A: Yes, provided the unit passes functional testing and is sourced from a reputable supplier. We recommend requesting test reports and traceability documentation.
Q: What is the lead time for IC697MDL341?
A: In-stock units ship within 1–3 business days. Contact us for current availability and expedited options.
Q: Does Konmask offer a warranty on IC697MDL341?
A: Yes. All units carry a minimum 90-day warranty against defects. Extended warranty options are available for OEM and MRO accounts.
