Industrial Power Distribution Solution – GE IC698PSA100 | PACSystems RX7i
Where This Product Is Used
The GE IC698PSA100 is a core power supply module designed for the PACSystems RX7i rack-based control platform. It is widely deployed across demanding industrial environments where stable, regulated DC power is critical to system uptime:
- Automotive Manufacturing: Powers RX7i racks controlling robotic welding cells, conveyor sequencing, and body-in-white assembly lines where voltage fluctuation cannot be tolerated.
- Oil & Gas Processing: Installed in remote terminal units (RTUs) and compressor station control panels operating on 120/240VAC utility feeds.
- Water & Wastewater Treatment: Supplies regulated power to RX7i CPUs managing pump stations, SCADA I/O, and chemical dosing systems.
- Power Generation & Utilities: Used in substation automation racks where IEC-compliant power conditioning is mandatory.
- Food & Beverage Processing: Supports hygienic-area control panels requiring reliable 40W continuous output for multi-module RX7i configurations.
- Discrete Manufacturing & Machine Tool: Integrated into CNC machine control cabinets and multi-axis motion control systems built on the RX7i platform.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (SKU) | IC698PSA100 |
| Platform | GE PACSystems RX7i |
| Input Voltage | 120/240VAC, 47–63 Hz |
| Output Power | 40W continuous |
| Output Voltage | +5VDC, +24VDC (backplane) |
| Form Factor | Single-slot RX7i rack module |
| Operating Temperature | 0°C to 60°C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | ~800 g |
| Certifications | UL, CE, cUL |
| Manufacturer | GE (General Electric) / GE Fanuc Automation |
Why Engineers Specify This Model
- Dual-voltage AC input (120/240VAC auto-ranging) eliminates the need for external step-down transformers in global deployments.
- 40W output headroom supports fully populated RX7i racks with CPU, communications, and mixed I/O modules without derating.
- Hot-swap compatible within redundant power configurations — minimizes planned downtime during maintenance windows.
- Integrated diagnostics report power fault status directly to the RX7i CPU via the backplane, enabling predictive maintenance routines in Proficy Machine Edition.
- Proven field reliability across 15+ years of installed base in process and discrete industries worldwide.
Complete System Bill of Materials
The IC698PSA100 is typically specified alongside the following RX7i components:
- IC698CRE020 / IC698CPE020 — RX7i CPU modules (Standard / Enhanced)
- IC698CHS009 / IC698CHS017 — RX7i 9-slot / 17-slot rack chassis
- IC698MRM001 — RX7i Redundancy Memory Module (for redundant CPU configurations)
- IC698ETM001 — RX7i Ethernet Interface Module
- IC694MDL340 / IC694MDL654 — Discrete I/O modules (compatible via expansion)
- IC698PSA100E — Enhanced variant with extended diagnostics (drop-in replacement)
Compliance & Industry Standards
- UL 508 — Industrial Control Equipment
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- cUL — Canadian Standards (CSA equivalent)
- RoHS compliant (per GE Fanuc product documentation)
- IEC 61131-2 — Programmable Controllers, Equipment Requirements & Tests
Quality Assurance & Sourcing
All GE IC698PSA100 units sourced through Konmask.com undergo a structured inspection protocol before dispatch:
- Visual inspection for physical damage, corrosion, and counterfeit indicators
- Firmware/label verification against GE Fanuc original part markings
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Certificate of conformance available upon request
We source from authorized distributors, OEM surplus channels, and verified industrial resellers. Traceability documentation is available for critical infrastructure projects.
How to Source This Part
- In Stock: Add to cart and proceed to checkout — most orders ship within 1–3 business days.
- Bulk / Project Quantity: Contact us for volume pricing and lead-time commitment on quantities of 5+ units.
- Urgent Requirement: Email support@konmask.com or call +0086 19859288691 for expedited sourcing.
- Cross-reference / Substitution: If IC698PSA100 is unavailable, we can advise on compatible alternatives such as IC698PSA100E.
Application-Specific FAQ
Q: Is the IC698PSA100 compatible with both 9-slot and 17-slot RX7i racks?
A: Yes. The IC698PSA100 installs in the dedicated power supply slot of any standard RX7i rack chassis (IC698CHS009 or IC698CHS017).
Q: Can two IC698PSA100 modules be used in a redundant power configuration?
A: Yes. The RX7i rack supports dual power supply slots for N+1 redundancy. Both modules share the load and provide automatic failover.
Q: What is the difference between IC698PSA100 and IC698PSA100E?
A: The IC698PSA100E is an enhanced revision with improved diagnostic reporting. Both are electrically and mechanically interchangeable as drop-in replacements.
Q: Does this module require any firmware configuration in Proficy Machine Edition?
A: No. The IC698PSA100 is auto-detected by the RX7i CPU upon rack power-up. No software configuration is required for basic operation.
Q: What warranty is provided?
A: Konmask provides a 90-day functional warranty on all tested units. Extended warranty options are available — contact us for details.
