Machine Control & SCADA Solution — GE IC755CSS12CDB | QuickPanel+ Series
Where This Product Is Used
The GE IC755CSS12CDB QuickPanel+ 12″ HMI is deployed across a wide range of industrial environments where operators require a reliable, high-resolution touchscreen interface for real-time process visibility and control. Typical application sites include:
- Discrete Manufacturing Lines — automotive assembly, metal stamping, and packaging machinery where operators monitor PLC-driven sequences and respond to alarms in real time.
- Water & Wastewater Treatment Plants — pump station control panels, chemical dosing skids, and filtration systems requiring SCADA-connected HMI nodes.
- Oil & Gas Upstream/Midstream — wellhead control panels, compressor stations, and pipeline SCADA RTU enclosures.
- Food & Beverage Processing — CIP (Clean-In-Place) skids, filling lines, and pasteurization systems with hygienic panel requirements.
- Building Automation & Energy Management — chiller plant control rooms, substation HMI panels, and BMS integration points.
- Pharmaceutical & Life Sciences — batch reactor control, cleanroom HVAC panels, and 21 CFR Part 11-compliant operator stations.
Technical Specifications
- Model: IC755CSS12CDB
- Brand / Series: GE Automation & Controls — QuickPanel+ Series
- Display: 12.1″ TFT Color LCD, 1024 × 768 (XGA) resolution
- Touchscreen: Resistive analog touch, single-touch
- Processor: 1 GHz ARM Cortex-A8
- RAM / Flash: 512 MB RAM / 512 MB internal Flash
- Operating System: Windows Embedded Compact 7
- Communication Ports: 2 × USB 2.0 Host, 1 × USB Device, 2 × RS-232/485 (COM), 1 × 10/100 Ethernet (RJ-45), 1 × CAN Bus
- Expansion Slots: 1 × SD Card slot
- Power Supply: 24 VDC nominal (18–30 VDC range)
- Power Consumption: ≤ 30 W typical
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +70 °C
- Humidity: 5–95% RH, non-condensing
- Protection Rating: IP65 (front panel)
- Panel Cutout: 310 mm × 240 mm (W × H)
- Mounting: Panel-mount, landscape orientation
- Weight: Approx. 2.0 kg
- Software: Proficy Machine Edition / Cimplicity compatible
Why Engineers Specify This Model
- Proven GE Ecosystem Integration — Native compatibility with GE PACSystems RX3i, VersaMax, and Series 90 PLCs eliminates protocol bridging complexity.
- 12″ XGA Display in a Compact Footprint — Delivers high pixel density for detailed P&ID mimics and trend displays without requiring a large panel cutout.
- Windows Embedded CE 7 Stability — Deterministic OS with long-term support lifecycle, preferred for safety-adjacent applications where OS updates must be controlled.
- IP65 Front Panel Sealing — Suitable for wash-down environments and dusty production floors without additional enclosure upgrades.
- Multi-Protocol Connectivity — Supports SRTP, Modbus TCP/RTU, EtherNet/IP, and OPC DA/UA via Proficy ME drivers, enabling integration with third-party PLCs and SCADA hosts.
- CAN Bus Port — Enables direct connection to CANopen or DeviceNet field devices, reducing gateway hardware in machine-level architectures.
Complete System Bill of Materials
For a fully operational QuickPanel+ operator station, engineers typically specify the following alongside the IC755CSS12CDB:
- 24 VDC DIN-rail power supply (e.g., GE PSPS24DC60W or equivalent)
- Panel-mount Ethernet switch for SCADA network segmentation
- USB-to-RS485 programming cable (for legacy PLC commissioning)
- SD card (industrial-grade, Class 10) for project backup and data logging
- Proficy Machine Edition software license (GE part: PME-DEV-001 or current equivalent)
- Panel gasket kit and M4 mounting clamps (included with unit; verify on delivery)
- Surge protection module on 24 VDC supply line (recommended for field installations)
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- UL Listed — UL 508 (Industrial Control Equipment)
- cUL — Canadian equivalent listing
- RoHS Compliant — Directive 2011/65/EU
- IP65 — IEC 60529 front panel ingress protection
- ATEX / IECEx — Not rated for hazardous area use; install in purged/pressurized enclosure if required in Zone 2 applications
Quality Assurance & Sourcing
Konmask.com sources the IC755CSS12CDB exclusively through verified industrial distribution channels and authorized surplus networks. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition
- Power-on functional test confirming display, touch response, and boot sequence
- Firmware version verification and documentation
- Anti-static packaging with humidity indicator card
- Serialized shipment record retained for traceability
Units are supplied as new surplus or factory-refurbished unless explicitly listed as new-in-box. Condition is stated clearly on the order confirmation.
How to Source This Part
- In-stock orders: Add to cart and complete checkout — standard lead time is 1–3 business days for dispatch.
- Bulk / project quantities: Contact support@konmask.com for volume pricing and reserved stock agreements.
- Urgent / emergency procurement: Call or WhatsApp +0086 19859288691 for same-day quotation on critical plant-down situations.
- Export / cross-border: We ship internationally with full commercial invoice and HS code documentation. Contact us for DDP/DAP Incoterms options.
Application-Specific FAQ
Q: Is the IC755CSS12CDB compatible with third-party PLCs such as Siemens S7 or Allen-Bradley ControlLogix?
A: Yes. Via Proficy Machine Edition’s OPC DA/UA and Modbus TCP drivers, the QuickPanel+ can communicate with most major PLC brands. Native GE SRTP is recommended for GE PACSystems.
Q: Can this HMI run as a standalone data logger without a PLC?
A: Yes. The Windows CE 7 OS supports custom applications and the SD card slot enables local data logging. However, Proficy ME is required for structured historian integration.
Q: What is the expected service life in a 24/7 production environment?
A: GE rates the backlight at 50,000 hours MTBF. In continuous operation this equates to approximately 5–6 years before backlight degradation becomes noticeable. Replacement backlight kits are available.
Q: Is the front panel suitable for food-grade wash-down?
A: IP65 provides protection against directed water jets. For full wash-down with cleaning agents, verify chemical compatibility of the front bezel material with your specific cleaning protocol.
Q: Can I upgrade the firmware on a used unit?
A: Firmware updates are managed through GE’s Proficy ME toolchain. Konmask can provide the current firmware version on request prior to purchase.
