GE IS400JPDHG1A – High-Density Power Distribution Board | Mark VI Turbine Control Platform
Engineering Background: The IS400JPDHG1A is a high-density power distribution board engineered by GE as a core infrastructure component within the Mark VI turbine control system. Designed to manage and distribute conditioned DC power across multiple I/O and processor modules, this board ensures stable, noise-isolated power delivery in demanding industrial environments including gas turbines, steam turbines, and combined-cycle power plants.
Product Positioning: As a critical backplane-level power component, the IS400JPDHG1A is specified by plant engineers and DCS integrators who require OEM-grade reliability for long-term operational continuity. Konmask.com supplies this module from verified inventory with full traceability documentation available upon request.
Complete Technical Specifications
- Part Number: IS400JPDHG1A
- Manufacturer: GE (General Electric)
- Series / Platform: Mark VI Turbine Control System
- Module Type: High-Density Power Distribution Board
- Form Factor: PCB board assembly, rack-mountable
- Power Input: Accepts conditioned DC bus from Mark VI power supply modules
- Output Channels: High-density multi-rail distribution to downstream I/O and control modules
- Operating Temperature: 0°C to +60°C (standard industrial range)
- Weight: 640 g (approx.)
- Compliance: Designed to GE Mark VI system specifications; CE-compatible installation environments
- Country of Origin: USA
Proven Application Environments
- GE Frame 5, Frame 6, Frame 7, Frame 9 gas turbine control panels
- Steam turbine governor and protection systems using Mark VI architecture
- Combined-cycle power plant DCS integration racks
- Offshore and onshore oil & gas turbine-driven compressor control systems
- Retrofit and upgrade projects replacing legacy Mark V / Mark IV power distribution boards
Engineering Advantages
- High-density layout: Maximizes power rail density per rack unit, reducing wiring complexity
- Noise isolation: Designed with GE’s signal integrity standards to prevent cross-rail interference
- Drop-in compatibility: Direct replacement within existing Mark VI enclosures — no firmware changes required
- Long service life: Industrial-grade components rated for continuous 24/7 operation
- Traceability: Each unit supplied with part number label and available with inspection report on request
System Architecture & Signal Flow
Within the Mark VI architecture, the IS400JPDHG1A sits between the primary power supply module (e.g., IS420PSAH1A or equivalent) and the downstream I/O terminal boards (TBCI, TBAI, TBDO series). It receives regulated DC input and distributes it across multiple isolated rails to processor cards (VCMI, VCRC) and I/O boards, maintaining voltage stability under variable load conditions. The board’s high-density connector layout supports the Mark VI’s triple-redundant (TMR) and simplex (S) configurations.
Sourcing & Quality Verification
- All units sourced from controlled industrial surplus, OEM overstock, or decommissioned plant inventories
- Pre-shipment inspection: visual check, connector integrity, PCB surface condition
- Part number and revision label verified against GE documentation
- Anti-static packaging with humidity indicator card included
- Full inspection report and photos available upon request before purchase
Procurement Process
- Submit your RFQ or place order directly on Konmask.com
- Receive order confirmation with lead time and shipping estimate within 24 hours
- Pre-shipment inspection report and photos provided on request
- Shipped via DHL / FedEx with full tracking; export documentation available for international orders
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is IS400JPDHG1A compatible with both TMR and simplex Mark VI configurations?
A: Yes. The board is designed for use across Mark VI simplex and TMR rack configurations. Verify your rack slot assignment with your GE system drawing before installation.
Q: Can this board be used as a direct replacement for a failed unit without reconfiguration?
A: In most cases, yes — the IS400JPDHG1A is a passive power distribution board with no firmware. Replacement requires only physical swap and connector re-seating. Always follow GE’s Mark VI maintenance procedures.
Q: Do you provide a warranty?
A: We offer a 90-day functional warranty on all modules. Extended warranty and exchange programs are available — contact us for details.
Q: Can you supply multiple units for a plant-wide spare parts program?
A: Yes. We support bulk procurement and consignment stocking programs. Contact our team for volume pricing.
