Genuine WOODWARD 5136-PFB-VME Profibus Interface Card | VME Series – Verified Source
The WOODWARD 5136-PFB-VME is a critical Profibus DP/FMS communication interface card designed for VME-bus control architectures, widely deployed in turbine control systems, power generation plants, and heavy industrial automation environments. As a legacy yet mission-critical component, the 5136-PFB-VME is no longer in mass production, making genuine units increasingly scarce on the secondary market. This scarcity has driven a surge in counterfeit and refurbished-as-new units — components that may appear functional on arrival but fail under load, causing costly unplanned downtime or catastrophic system faults in safety-critical applications.
At Konmask, every WOODWARD 5136-PFB-VME unit we supply is sourced exclusively through verified industrial surplus channels and authorized distribution networks. We apply a rigorous 4-step quality verification process before any unit ships, and we stand behind every sale with full documentation — including Certificate of Conformance (COC), test reports, and photographic inspection records. When you purchase from Konmask, you receive a genuine, authentic, and verified WOODWARD component backed by transparent sourcing and professional after-sales support.
Technical Specifications
- Part Number: 5136-PFB-VME
- Manufacturer: WOODWARD
- Form Factor: VME-bus (6U VME)
- Communication Protocol: Profibus DP / Profibus FMS
- Baud Rate: Up to 12 Mbit/s
- Profibus Interface: RS-485, 9-pin D-Sub connector
- Bus Interface: VMEbus (IEEE 1014-1987)
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Power Supply: +5V DC via VME backplane
- Power Consumption: ≤ 5W typical
- Dimensions: Standard 6U VME single-slot form factor
- Weight: Approx. 300g
- Firmware: Field-upgradeable via host CPU
- Supported Standards: EN 50170 (Profibus), IEC 61158
Specifications verified against WOODWARD official documentation and product datasheets.
Our 4-Step Quality Verification Process
- Step 1 — Visual & Physical Inspection: Each unit undergoes a thorough visual examination for physical damage, corrosion, counterfeit markings, and component tampering. We verify label authenticity, PCB revision codes, and manufacturer date codes against known-genuine references. High-resolution inspection photographs are archived for every unit.
- Step 2 — Functional Power-On Test: The card is installed in a compatible VME test chassis and powered on. We verify correct initialization, LED status indicators, and firmware boot sequence. Communication handshake with a Profibus master is confirmed at multiple baud rates including 1.5 Mbit/s and 12 Mbit/s.
- Step 3 — Protocol Communication Test: A live Profibus DP network test is conducted using a certified Profibus analyzer. Data exchange integrity, cyclic I/O, and diagnostic messaging are verified per EN 50170 standard requirements. Test logs are retained and available upon request.
- Step 4 — Documentation & Traceability: Upon passing all tests, the unit is assigned a Konmask inspection reference number. We issue a Certificate of Conformance (COC), provide the full test report, packing list, and Country of Origin (COO) declaration. All records are retained for a minimum of 5 years.
Key Features & Benefits
- Full Profibus DP/FMS Dual-Protocol Support: Enables seamless integration into both legacy FMS and modern DP network topologies without hardware changes, reducing retrofit costs in existing VME-based control systems.
- High-Speed 12 Mbit/s Communication: Supports the maximum Profibus baud rate per EN 50170, ensuring deterministic, low-latency data exchange in time-critical turbine and power generation control loops.
- VMEbus IEEE 1014-1987 Compliant: Fully compliant with the VMEbus standard, guaranteeing interoperability with WOODWARD NetCon, MicroNet, and third-party VME host controllers without custom drivers.
- Field-Upgradeable Firmware: Firmware can be updated via the host CPU without card removal, minimizing maintenance downtime in live production environments.
- Robust Industrial-Grade Design: Engineered for continuous 24/7 operation in harsh industrial environments, meeting IEC 61158 fieldbus reliability requirements for process automation.
- Comprehensive Diagnostic Messaging: Onboard diagnostics provide real-time fault detection and status reporting per Profibus DP diagnostic telegram specifications, enabling rapid fault isolation and reduced MTTR.
Typical Applications
- Gas Turbine Control Systems: Profibus DP communication backbone in WOODWARD NetCon/MicroNet turbine governor systems at power generation plants and compressor stations.
- Steam Turbine Automation: Interface card for VME-based DCS integration in steam turbine speed and load control applications at thermal power stations.
- Industrial Compressor Control: Fieldbus communication link between VME controllers and Profibus-enabled variable frequency drives (VFDs) in gas compression facilities.
- Oil & Gas Process Automation: Upstream and midstream SCADA integration where VME-bus controllers communicate with Profibus field instruments including pressure transmitters and control valves.
- Marine Propulsion Control: Deployed in marine diesel engine governor systems requiring deterministic Profibus communication in shipboard VME control architectures.
- Power Plant DCS Retrofit: Replacement and spare card for aging VME-based distributed control systems undergoing life extension programs at coal, gas, and hydro power facilities.
Compatible System Components
- WOODWARD NetCon 5000 Control System
- WOODWARD MicroNet TMR / MicroNet Plus
- WOODWARD 5009 Digital Control
- Standard 6U VME backplanes (3, 6, 9, 21-slot)
- Profibus DP Masters: Siemens CP 342-5, Hilscher CIFX 50-DP
- Profibus-compatible I/O modules and field instruments (EN 50170 compliant)
- Profibus network terminators and repeaters (RS-485 standard)
Global Sourcing & Shipping Capabilities
- Primary Service Regions: China (domestic), Southeast Asia, Middle East, Europe, North America, and Australia — with established logistics routes to over 60 countries.
- Packaging Standard: Anti-static ESD packaging with foam cushioning, moisture barrier bag, and desiccant. Outer carton rated for international air and sea freight. Each unit is individually boxed and labeled with Konmask inspection reference.
- Shipping Options: DHL Express (2–5 business days globally), FedEx International Priority, sea freight consolidation for bulk orders. Export documentation including commercial invoice, packing list, and COO declaration provided as standard.
- Lead Time: In-stock units ship within 1–3 business days of order confirmation. Custom sourcing requests fulfilled within 7–15 business days subject to availability.
Certifications & Compliance Statement
- Profibus DP/FMS: EN 50170 / IEC 61158 compliant
- VMEbus: IEEE 1014-1987 standard
- RoHS: Units sourced and handled in compliance with RoHS Directive 2011/65/EU
- ESD Handling: IEC 61340-5-1 electrostatic discharge protection throughout storage and shipping
- Export Compliance: All shipments processed in accordance with applicable export control regulations (ECCN classification available on request)
Konmask Quality Commitment: We do not sell untested, unverified, or cosmetically refurbished units represented as new. Every WOODWARD 5136-PFB-VME supplied by Konmask has passed our 4-step verification protocol. If a unit fails to perform as specified upon receipt, we provide full replacement or refund within 30 days — no questions asked.
How to Order
- Submit Your Inquiry: Contact us via the product page, email [email protected], or WhatsApp/WeChat at +0086 19859288691 with your required quantity, delivery timeline, and any specific documentation requirements (COC, test report, COO declaration).
- Receive Quotation & Confirmation: Our technical sales team will respond within 24 hours with a formal quotation, stock availability confirmation, and lead time. We can provide pre-shipment inspection photos and test report summaries upon request before payment.
- Order & Ship: Upon order confirmation and payment, your unit is prepared, re-inspected, packed to export standard, and dispatched with full shipping documentation. Tracking information is provided within 24 hours of dispatch.
Sample & Test Report Policy: Test reports are available for all verified units at no additional charge. Pre-shipment inspection photos provided as standard. Physical samples for evaluation available subject to deposit arrangement — contact us to discuss.
Authenticity & Trust FAQ
-
Q: How can I verify that the WOODWARD 5136-PFB-VME I receive is genuine?
A: Every unit shipped by Konmask includes a Certificate of Conformance (COC) with our inspection reference number, high-resolution pre-shipment photos, and a functional test report. You can cross-reference the PCB revision code and date code markings against WOODWARD’s published documentation. If you have any doubt upon receipt, contact us immediately — we will assist with verification or arrange return and replacement. -
Q: What is your warranty policy for the WOODWARD 5136-PFB-VME?
A: Konmask provides a 30-day performance warranty on all verified units. If the card fails to initialize, communicate on Profibus, or exhibits any functional defect within 30 days of receipt under normal operating conditions, we will replace the unit or issue a full refund. Extended warranty arrangements are available for bulk or project orders — please inquire. -
Q: Can you provide a test report and COC before I place an order?
A: Yes. We can provide a sample test report summary and COC template prior to order placement so you can review our documentation standard. Full unit-specific test report and COC are issued upon order confirmation and included with shipment. For high-value or project-critical orders, we also offer live video inspection of the unit before dispatch upon request.
