WOODWARD PCU1000 PCI Serial Network Interface Card – NetCon Series
When a turbine control system loses its serial communication backbone, the consequences are immediate and severe: the HMI goes blind, the supervisory SCADA layer loses telemetry, and operators are forced into manual override procedures that no modern plant is staffed to sustain. The PCU1000 is the component that prevents this scenario. Designed as the dedicated PCI-bus serial network interface for WOODWARD’s NetCon control architecture, it is the physical and logical bridge between the controller backplane and the plant communication network — a role that no generic off-the-shelf card can replicate without extensive re-engineering of the firmware stack.
Within the NetCon product family, the PCU1000 occupies the communication-layer tier, sitting above the I/O modules and below the supervisory software. WOODWARD’s NetCon controllers are deployed across gas turbines, steam turbines, hydro governors, and compressor trains on every inhabited continent. The PCU1000 is the serial interface of record for this installed base, which means that for any plant running legacy NetCon hardware, this card is not a preference — it is a requirement. Sourcing a verified, tested unit is the only path to restoring full system functionality without a full controller replacement.
Technical Specifications
Electrical
- Interface Bus: PCI (Peripheral Component Interconnect), 32-bit
- Communication Protocol: Serial network interface (proprietary WOODWARD NetCon serial bus)
- Power Supply: Derived from PCI bus (3.3 V / 5 V)
Mechanical
- Form Factor: Standard PCI add-in card
- Weight: 300 g (bare card)
- Connector Type: Per WOODWARD NetCon backplane specification
Environmental
- Operating Temperature: Per WOODWARD NetCon system specification (typically 0 °C to +60 °C)
- Storage Temperature: −40 °C to +85 °C (standard industrial component range)
- Humidity: 5 % to 95 % RH, non-condensing
Certifications & Standards
- Designed and manufactured to WOODWARD quality management standards
- Compatible with IEC 61511 functional safety framework (as part of the NetCon system)
- Note: Confirm exact agency certifications (CE, UL, CSA) against the WOODWARD PCU1000 product datasheet for your specific revision level.
Key Features & Benefits
- Native NetCon Serial Bus Integration — Firmware is factory-matched to the WOODWARD NetCon protocol stack, eliminating the driver development and validation work that a generic PCI serial card would require; typical integration time is reduced from weeks to hours.
- Deterministic Serial Communication — The card’s hardware arbitration ensures cycle-consistent data delivery to the controller CPU, a prerequisite for closed-loop turbine speed and load control where latency jitter above 1 ms can trigger protective trips.
- Drop-in Replacement Compatibility — Mechanically and electrically identical to the original factory-fitted card; no backplane modification, no firmware update to the host controller, and no recalibration of connected I/O is required upon swap.
- Extended Service Life Support — Enables plants to extend the operational life of existing NetCon controllers by 5–10 years without a full DCS migration, deferring capital expenditure that can exceed USD 500,000 per turbine train.
- Compliant with IEC 61511 Safety Instrumented System Frameworks — When used as part of a validated NetCon system, the PCU1000 supports the communication integrity requirements of safety-layer architectures in oil & gas and power generation.
- Traceable Component Sourcing — Every unit supplied by Konmask.com is accompanied by documentation supporting traceability back to the original manufacturer or authorized distribution channel, satisfying the audit requirements of ISO 55001 asset management programs.
Industry & Equipment Applications
- Gas Turbine Power Generation — NetCon-controlled gas turbine generators at combined-cycle and simple-cycle plants; the PCU1000 carries speed reference, load setpoint, and alarm data between the turbine controller and the plant DCS.
- Steam Turbine Control — Extraction and back-pressure steam turbines in cogeneration facilities; serial communication via PCU1000 enables coordinated steam extraction control with the process plant.
- Hydro Governor Systems — Run-of-river and reservoir hydro units using WOODWARD NetCon governors; the card transmits gate position feedback and frequency regulation commands to the SCADA layer.
- Gas Compression Stations — Pipeline compressor trains driven by gas turbines or electric motors with NetCon-based anti-surge and performance control; the PCU1000 interfaces the controller to the station automation system.
- Industrial Process Plants — Refineries and petrochemical facilities where WOODWARD NetCon controllers manage rotating equipment; serial network integrity is critical for continuous process monitoring.
- Marine Propulsion & Auxiliary Systems — Vessels equipped with WOODWARD governor systems for main engine and auxiliary generator control, where the PCU1000 provides the communication link to the vessel management system.
System Integration & Compatible Parts
Upstream / Host Controllers (PCU1000 installs into):
- WOODWARD NetCon 5000 series controllers
- WOODWARD NetCon 10 / NetCon 20 controller platforms
Downstream / Network Devices (PCU1000 communicates with):
- WOODWARD NetCon I/O expansion modules
- Plant SCADA / DCS via serial gateway or protocol converter
- WOODWARD Watch Window / ToolKit engineering workstations
Related Spare Parts:
- WOODWARD NetCon CPU boards (confirm compatibility by NetCon platform revision)
- WOODWARD NetCon power supply modules
- WOODWARD NetCon analog and digital I/O cards
Substitution Note: No direct third-party equivalent exists for the PCU1000. Generic PCI serial cards cannot substitute without custom firmware development and full system re-validation. Contact Konmask.com to confirm availability of the exact revision required for your NetCon platform.
Our Quality Assurance Process
Every WOODWARD PCU1000 unit supplied by Konmask.com passes through a four-stage verification process before shipment:
- Visual & Physical Inspection — Board-level inspection for component damage, corrosion, solder joint integrity, and connector condition. Units with any physical anomaly are quarantined and not offered for sale.
- Functional Bench Test — Where test equipment is available, the card is powered and its serial interface is exercised to confirm basic communication function prior to packaging.
- Documentation Review — Part number, revision label, and serial number are recorded and cross-referenced against the order to ensure the correct revision is shipped.
- Secure Anti-Static Packaging — Cards are packed in ESD-safe bags with desiccant, placed in rigid foam-lined cartons rated for international air and sea freight.
Available Documentation (upon request): Inspection report, part number confirmation letter, packing list, commercial invoice, and certificate of conformance.
How to Order
- Submit Your Inquiry — Email support@konmask.com or use the contact form on this page. Include your NetCon platform model, required PCU1000 revision (if known), and required quantity.
- Receive Quotation — Our technical team will confirm availability, revision compatibility, lead time, and pricing within 24 hours on business days.
- Confirm & Ship — Upon order confirmation and payment, the unit is prepared, documented, and dispatched via your preferred freight method with full tracking.
Why Choose Konmask.com?
- Specialist Focus on Industrial Automation Spares — We source and supply PLC, DCS, and turbine control components exclusively, which means our team understands the technical context of every part we sell.
- Global Sourcing Network — Access to surplus, refurbished, and new-old-stock WOODWARD components through a vetted international supplier network, enabling us to locate hard-to-find parts that standard distributors no longer stock.
- Technical Pre-Sales Support — Before you commit to a purchase, our engineers will review your system configuration and confirm that the PCU1000 revision we have in stock is compatible with your specific NetCon platform.
- Documented Traceability — Every shipment includes documentation sufficient for plant maintenance records and ISO 55001 / IEC 61511 audit trails.
- Responsive Communication — 24-hour inquiry response commitment, with direct access to technical staff — not a call center — for follow-up questions during the procurement process.
Frequently Asked Questions
Q: Is the WOODWARD PCU1000 compatible with all NetCon controller revisions, or do I need to match the revision level?
A: The PCU1000 was produced in multiple hardware revisions over the NetCon product lifecycle. While the form factor and bus interface are consistent, firmware behavior and connector pinout details may vary between revisions. We strongly recommend providing your NetCon controller model and existing card revision number when inquiring, so we can confirm an exact match before shipment.
Q: Can I use a generic PCI serial card as a WOODWARD PCU1000 replacement to reduce cost?
A: This is not a viable path for most plants. The PCU1000 runs WOODWARD-proprietary firmware that implements the NetCon serial protocol at the hardware level. A generic PCI serial card would require custom driver and firmware development, followed by full system re-validation — a process that typically costs more and takes longer than sourcing an original PCU1000. For plants operating under IEC 61511 or similar safety frameworks, re-validation is a regulatory requirement, not optional.
Q: What is the lead time for a WOODWARD PCU1000 PCI serial network interface card, and do you hold stock?
A: Stock levels for legacy turbine control components fluctuate. Submit an inquiry to support@konmask.com and we will confirm current availability and lead time within 24 hours. For urgent plant shutdowns, please indicate your required delivery date and we will prioritize sourcing accordingly.
