Process Control Solution – Honeywell 10001/R/I | TDC 3000 Analog Input Module
Where This Product Is Used
The Honeywell 10001/R/I is an Analog Input Module designed for the Honeywell TDC 3000 Distributed Control System (DCS). It is widely deployed across mission-critical industrial environments where precise, continuous process variable measurement is essential:
- Oil & Gas Refineries – Monitoring pressure, temperature, and flow in distillation columns, heat exchangers, and separator units.
- Petrochemical Plants – Continuous analog signal acquisition from field transmitters in reactor and fractionation control loops.
- Power Generation Facilities – Boiler drum level, turbine inlet pressure, and feedwater flow measurement in DCS-controlled power plants.
- Chemical Processing – pH, conductivity, and differential pressure monitoring in batch and continuous process environments.
- Pulp & Paper Mills – Digester pressure and temperature control integrated into legacy TDC 3000 architectures.
- Water & Wastewater Treatment – Analog signal collection from level transmitters and flow meters in SCADA/DCS hybrid systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 10001/R/I |
| Manufacturer | Honeywell |
| Series / Platform | TDC 3000 DCS |
| Module Type | Analog Input Module |
| Signal Type | 4–20 mA / 1–5 V DC (field configurable) |
| Input Channels | Multi-channel analog input |
| Communication Bus | Honeywell Local Control Network (LCN) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Power Supply | Supplied via TDC 3000 backplane |
| Weight | 140 g |
| Form Factor | Card / Plug-in Module |
| Compliance | CE, UL Listed (refer to Honeywell documentation) |
Why Engineers Specify This Model
- Platform Compatibility – Designed exclusively for the Honeywell TDC 3000 architecture; ensures seamless integration without gateway adapters or signal converters.
- Proven Field Reliability – Deployed in continuous-process industries for decades; well-documented mean time between failures (MTBF) in harsh environments.
- Direct Replacement – Serves as a drop-in replacement for aging or failed modules in existing TDC 3000 cabinets, minimizing downtime and re-engineering costs.
- Precision Signal Acquisition – High-resolution analog-to-digital conversion ensures accurate process variable readings critical for closed-loop control.
- Reduced Spare Parts Complexity – Standardized module form factor simplifies inventory management across multi-unit plant sites.
Complete System Bill of Materials
For a fully operational TDC 3000 analog input subsystem, the following components are typically required alongside the 10001/R/I:
- Honeywell TDC 3000 Universal Station (US) or Enhanced Universal Station (EUS)
- Honeywell Local Control Network (LCN) Cable and Terminators
- Honeywell High-Performance Process Manager (HPM) or Basic Process Manager (BPM)
- Field Termination Assembly (FTA) compatible with 10001/R/I
- 24 VDC Field Transmitters (4–20 mA HART-compatible recommended)
- Honeywell TDC 3000 Power Supply Module
Contact support@konmask.com for assistance sourcing complete system BOM components.
Compliance & Industry Standards
- CE Marking – Compliant with EU directives for industrial electronic equipment.
- UL Listed – Recognized for use in North American industrial control panel applications.
- IEC 61511 / ISA-84 – Suitable for integration into Safety Instrumented Systems (SIS) when applied per functional safety engineering guidelines.
- RoHS Consideration – Legacy hardware; consult Honeywell product documentation for RoHS status applicable to your jurisdiction.
Quality Assurance & Sourcing
All Honeywell 10001/R/I modules supplied by Konmask.com undergo the following quality process:
- ✅ Visual Inspection – PCB, connectors, and housing checked for physical damage, corrosion, or counterfeit indicators.
- ✅ Functional Bench Test – Module powered and verified for correct analog signal acquisition prior to shipment.
- ✅ Traceability Documentation – Serial number and test records provided upon request.
- ✅ Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- ✅ 90-Day Warranty – All modules carry a 90-day replacement warranty against defects in materials and workmanship.
How to Source This Part
- Add to Cart – Click the purchase button above to place an order directly through Konmask.com.
- Request a Quote – For bulk orders (3+ units) or urgent requirements, email support@konmask.com for priority pricing.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock items: estimated 7–21 business days depending on sourcing channel.
- Export & Customs – We support international shipments with full commercial invoice and HS code documentation for customs clearance.
- Payment – Accepts T/T bank transfer, PayPal, and major credit cards. Net-30 terms available for verified industrial accounts.
Application-Specific FAQ
Q: Is the Honeywell 10001/R/I compatible with TDC 2000 systems?
A: No. The 10001/R/I is designed specifically for the TDC 3000 platform. TDC 2000 systems use a different backplane and module form factor. Contact us to identify the correct part for your legacy system.
Q: Can this module be used with HART field devices?
A: The module accepts standard 4–20 mA signals. HART communication capability depends on the specific firmware revision and FTA configuration. Consult your TDC 3000 system documentation or contact our technical team.
Q: What is the difference between 10001/R/I and similar Honeywell analog input modules?
A: The “/R/I” suffix denotes a specific hardware revision and input configuration. Always verify the exact part number against your TDC 3000 I/O list before ordering to ensure slot and FTA compatibility.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC and functional test report are available upon request for all modules. Please specify this requirement at the time of order.
Q: Can Konmask.com source multiple units for a plant turnaround?
A: Yes. We specialize in sourcing critical spare parts for planned and emergency shutdowns. Contact us with your full BOM and required delivery date for a dedicated quote.
