HONEYWELL 10024/F/F – Enhanced Module | TDC 3000 / TotalPlant Series
Engineering Background
The Honeywell TDC 3000 (Total Distributed Control) platform has been the backbone of process automation in refineries, chemical plants, and power generation facilities for decades. Designed for mission-critical continuous process control, the TDC 3000 architecture relies on a modular card-based infrastructure where each module performs a precisely defined function within the control loop hierarchy. The 10024/F/F Enhanced Module is a key functional card within this ecosystem, engineered to deliver reliable signal processing and control execution in demanding industrial environments.
Product Positioning
The HONEYWELL 10024/F/F is an Enhanced Module designed for integration into TDC 3000 and TotalPlant Series distributed control systems. It is specified by process control engineers who require a proven, OEM-grade replacement or expansion card that maintains full backward compatibility with existing Honeywell DCS infrastructure. This module is sourced through verified industrial supply channels and is suitable for both maintenance replacement and system expansion projects.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 10024/F/F |
| Manufacturer | Honeywell Process Solutions |
| Module Type | Enhanced Module |
| Compatible Platform | TDC 3000 / TotalPlant Series DCS |
| Form Factor | Card / PCB Module (rack-mount) |
| Operating Temperature | 0°C to +60°C (standard industrial range) |
| Storage Temperature | -40°C to +85°C |
| Power Supply | Supplied via TDC 3000 backplane bus |
| Communication Interface | Honeywell Local Control Network (LCN) / UCN (platform-dependent) |
| Mounting | Honeywell TDC 3000 compatible card cage / chassis |
| Approvals | CE, UL (platform-level certification) |
| Weight | Approx. 100 g (card only) |
| Condition Available | New / Refurbished / Tested surplus |
Note: Confirm exact electrical ratings and firmware revision with your Honeywell system documentation or contact our technical team before installation.
Proven Application Environments
- Oil & Gas Refining: Crude distillation unit (CDU) control, hydrocracker automation, and flare management systems running on TDC 3000 platforms.
- Petrochemical Plants: Ethylene cracker control, polymerization reactor management, and utility distribution automation.
- Power Generation: Boiler management systems (BMS), turbine control, and load dispatch automation in coal, gas, and combined-cycle plants.
- Pulp & Paper: Digester control, recovery boiler automation, and paper machine drive coordination.
- Pharmaceutical Manufacturing: Batch reactor control and clean-in-place (CIP) sequence management under FDA 21 CFR Part 11 environments.
- Water & Wastewater Treatment: SCADA-integrated process control for large municipal treatment facilities.
Engineering Advantages
- Full TDC 3000 Compatibility: Drop-in replacement for existing 10024/F/F slots — no firmware reconfiguration required in standard deployments.
- Enhanced Processing Architecture: The “Enhanced” designation indicates upgraded processing capability over legacy base modules, supporting faster scan rates and improved diagnostic reporting.
- Hot-Swap Ready: Designed for insertion and removal within the TDC 3000 card cage with minimal process disruption (subject to system configuration).
- Long Service Life: Honeywell TDC 3000 modules are engineered for 15–25 year operational lifespans in controlled environments.
- Diagnostic Transparency: Integrated self-diagnostics report fault conditions to the Honeywell Universal Station (US) operator interface for rapid fault isolation.
- Spare Parts Availability: Konmask.com maintains sourcing relationships for TDC 3000 legacy modules, ensuring availability even for end-of-life Honeywell part numbers.
System Architecture & Signal Flow
Within the TDC 3000 architecture, the 10024/F/F Enhanced Module resides in the Local Control Network (LCN) or Universal Control Network (UCN) layer, depending on system generation. The module interfaces with:
- Upstream: Honeywell Network Interface Module (NIM) or Highway Gateway Module (HGM) for supervisory data exchange.
- Peer Level: Other process modules (AM, PM, HPM) sharing the LCN/UCN data highway.
- Downstream: Field Termination Assemblies (FTAs) and I/O marshalling panels connected via the card cage backplane.
- Operator Interface: Data presented at Honeywell Universal Stations (US) or Global User Stations (GUS) via the LCN highway.
Signal flow: Field sensor → FTA → Card cage backplane → 10024/F/F Enhanced Module → LCN data highway → Operator station / Historian.
Sourcing & Quality Verification
- Source Traceability: All Honeywell modules supplied by Konmask.com are sourced from verified industrial decommissioning projects, authorized distributors, or OEM surplus channels.
- Pre-Shipment Testing: Each module undergoes functional power-on verification and visual inspection for PCB damage, corrosion, and component integrity.
- Anti-Counterfeit Screening: Modules are inspected against known Honeywell OEM markings, label formats, and board revision identifiers.
- Packaging: Shipped in ESD-safe anti-static bags with foam cushioning and moisture barrier packaging for international transit.
- Documentation: Certificate of conformance and test report available upon request for critical plant applications.
Procurement Process
- Confirm Part Number: Verify 10024/F/F against your TDC 3000 system drawing or existing module label.
- Request a Quote: Contact [email protected] with your required quantity, delivery timeline, and any firmware revision requirements.
- Technical Review: Our engineering team will confirm compatibility with your specific TDC 3000 system generation.
- Order Confirmation: Purchase order accepted via email. Payment terms available for qualified industrial buyers.
- Shipping: DHL / FedEx international express with full tracking. Export documentation (commercial invoice, packing list, COO) provided.
- After-Sales Support: 30-day return window for DOA (dead on arrival) units. Technical support available via email and phone.
Technical FAQ
Q: Is the 10024/F/F compatible with both TDC 3000 and TotalPlant Alcont systems?
A: The 10024/F/F is primarily designed for the TDC 3000 platform. Compatibility with TotalPlant Alcont variants depends on the specific system generation and card cage configuration. Contact our team with your system details for confirmation.
Q: Can this module be used as a direct replacement without reconfiguring the Honeywell database?
A: In most standard replacement scenarios, yes. The module inherits the configuration stored in the TDC 3000 system database. However, firmware revision mismatches may require a database reload — consult your Honeywell system engineer.
Q: Do you supply the matching Field Termination Assembly (FTA) for this module?
A: Yes. Konmask.com can source compatible FTAs and other TDC 3000 ancillary components. Specify your requirements when requesting a quote.
Q: What is the lead time for this part?
A: Standard lead time is 3–7 business days for in-stock units. For sourced or refurbished units, lead time is 2–4 weeks. Contact us for current stock status.
Q: Is a warranty provided?
A: All modules are covered by a 90-day functional warranty against manufacturing defects and DOA conditions. Extended warranty options are available for large-volume orders.
