Industrial DCS Digital Input Solution – Honeywell 51202304-100 | TDC 3000
Where This Product Is Used
The Honeywell 51202304-100 Digital Input Module is a core I/O component deployed across high-reliability process control environments. Typical application sites include:
- Oil & Gas Refineries – Monitoring valve open/close status, pump run/stop signals, and emergency shutdown (ESD) discrete inputs across distributed control loops.
- Chemical & Petrochemical Plants – Acquiring on/off field device states from limit switches, pressure switches, and flow switches in hazardous-area installations.
- Power Generation Facilities – Integrating discrete signals from turbine protection systems, breaker status, and auxiliary equipment into the TDC 3000 supervisory layer.
- Pulp & Paper Mills – Reading motor starter feedback, conveyor status, and safety interlock signals within continuous process lines.
- Pharmaceutical Manufacturing – Capturing binary process states for batch record integrity and 21 CFR Part 11 audit trails within validated DCS environments.
Technical Specifications
- Part Number: 51202304-100
- Series: Honeywell TDC 3000 / PM I/O
- Module Type: Digital Input (DI)
- Manufacturer: Honeywell Process Solutions
- Form Factor: Card/Module – rack-mounted
- Compatible Platform: Honeywell TDC 3000, Process Manager (PM), Advanced Process Manager (APM)
- Signal Type: Discrete / Digital (dry contact or voltage input)
- Weight: ~700 g
- Condition Available: Refurbished / Tested / New Surplus
Why Engineers Specify This Model
- Platform Continuity: Direct drop-in replacement for existing TDC 3000 PM/APM racks — no firmware changes or re-engineering required.
- Proven Field Reliability: Designed to Honeywell’s industrial-grade standards for 24/7 continuous process operation in demanding environments.
- Reduced Downtime Risk: Stocking a spare 51202304-100 eliminates extended lead times during unplanned outages — critical for plants with no hot-standby redundancy.
- Backward Compatibility: Fully compatible with legacy TDC 3000 configurations, preserving existing I/O channel assignments and loop documentation.
- Tested Before Shipment: Each unit sourced by Konmask undergoes functional verification prior to dispatch.
Complete System Bill of Materials
The 51202304-100 is typically deployed alongside the following Honeywell TDC 3000 components:
- Honeywell 51202329-100 / 51202329-200 – Process Manager I/O Link Module
- Honeywell 51304485-100 – Power Supply Module
- Honeywell 51401469-100 – I/O Termination Assembly
- Honeywell 51109684-100 – Advanced Process Manager (APM) Card File
- Honeywell 51198947-100 – Field Termination Assembly (FTA) for DI
Contact us to source complete rack assemblies or multi-module kits.
Compliance & Industry Standards
- Designed and manufactured under Honeywell’s ISO 9001-certified quality management system.
- Compatible with IEC 61511 (Functional Safety – Safety Instrumented Systems) application architectures.
- Suitable for use in facilities operating under OSHA PSM (29 CFR 1910.119) and EPA RMP requirements.
- Supports 21 CFR Part 11 compliant DCS configurations in pharmaceutical applications.
Quality Assurance & Sourcing
- Source: Procured from verified industrial surplus channels, OEM-authorized distributors, and decommissioned plant inventories.
- Inspection: Visual inspection, board-level cleaning, and functional power-on testing performed on all refurbished units.
- Packaging: Anti-static ESD packaging with foam cushioning; shipped in double-wall corrugated cartons.
- Warranty: 90-day replacement warranty against DOA or functional failure under normal operating conditions.
- Traceability: Serial number and test records available upon request for regulated industries.
How to Source This Part
- Add the 51202304-100 to your cart and proceed to checkout, or
- Contact us directly for volume pricing, multi-unit kits, or urgent same-day quotation.
- Provide your plant’s TDC 3000 rack configuration details for compatibility confirmation if needed.
- We ship globally via DHL Express, FedEx International, and UPS — with export documentation (commercial invoice, packing list, COO) included.
Lead Time: In-stock units ship within 1–3 business days. Contact us for ETA on out-of-stock inquiries.
Application-Specific FAQ
Q: Is the 51202304-100 compatible with both PM and APM card files?
A: Yes. This module is designed for the Honeywell TDC 3000 Process Manager I/O family and is compatible with standard PM and APM rack configurations.
Q: Can this module be used as a hot-swap replacement without shutting down the DCS?
A: Hot-swap capability depends on your specific rack configuration and firmware revision. Consult your Honeywell system documentation or contact our technical team before performing live swaps.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, a CoC and test report can be provided upon request for regulated or audited facilities.
Q: What is the difference between 51202304-100 and other suffix variants?
A: The -100 suffix denotes the standard revision of this module. Different suffixes may indicate hardware revisions or regional configurations. Contact us to confirm cross-compatibility.
Q: Can you supply multiple units for a plant turnaround or shutdown project?
A: Yes. We maintain multi-unit inventory and can fulfill bulk orders. Request a formal quotation via support@konmask.com.
