Process Control & DCS Solution — Honeywell 51304260-200 | TDC 3000 / TotalPlant Series
Where This Product Is Used
The Honeywell 51304260-200 Analog Input Module is a core signal acquisition component deployed across high-reliability distributed control systems (DCS) in demanding industrial environments. Typical deployment sites include:
- Oil & Gas Refineries — continuous process monitoring of temperature, pressure, and flow via 4–20 mA field transmitters
- Petrochemical & Chemical Plants — multi-loop analog signal aggregation in safety-critical control cabinets
- Power Generation Facilities — turbine and boiler control loops requiring high-resolution analog acquisition
- Pulp & Paper Mills — process variable monitoring integrated into TDC 3000 / TotalPlant architectures
- Pharmaceutical Manufacturing — GMP-compliant process data acquisition with validated DCS infrastructure
- Water & Wastewater Treatment — SCADA-integrated analog input for flow and level control
Technical Specifications
- Part Number: 51304260-200
- Manufacturer: Honeywell Process Solutions
- Module Type: Analog Input (AI)
- Compatible Platform: Honeywell TDC 3000 / TotalPlant Solution (TPS) DCS
- Signal Type: 4–20 mA / 1–5 V analog field signals
- Resolution: High-resolution A/D conversion
- Isolation: Channel-to-channel and channel-to-bus isolation
- Mounting: Card cage / backplane slot mount
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Certifications: CE, UL listed (refer to Honeywell datasheet for full compliance)
- Condition Available: New surplus / Refurbished / Used tested
Why Engineers Specify This Model
- Drop-in Replacement: Direct form-fit-function replacement for existing TDC 3000 / TPS installations — no re-engineering required
- Proven Field Reliability: Deployed in mission-critical processes where unplanned downtime costs exceed six figures per hour
- Long Service Life: Honeywell’s TDC 3000 platform has a multi-decade installed base; spare modules are essential for lifecycle extension
- Diagnostic Transparency: Onboard fault detection and status LEDs enable rapid field troubleshooting
- Backward Compatibility: Fully compatible with existing TDC 3000 card cages, power supplies, and UCN/LCN network infrastructure
Complete System Bill of Materials
For a complete TDC 3000 analog input subsystem, engineers typically specify the following alongside the 51304260-200:
- Honeywell TDC 3000 Card Cage / Chassis
- Honeywell Power Supply Module (e.g., 51304453-100)
- Honeywell Universal Control Network (UCN) Interface Card
- Field Termination Assembly (FTA) — matched to AI module type
- Shielded twisted-pair field wiring (per Honeywell wiring guidelines)
- Honeywell TotalPlant Alcont / HPM Controller Module
Compliance & Industry Standards
- IEC 61511 — Functional Safety for Process Industry Sectors (SIS integration reference)
- IEC 61131 — Programmable Controllers standard family
- ISA-5.1 — Instrumentation Symbols and Identification
- CE Marking — European conformity for electrical equipment
- RoHS — Restriction of Hazardous Substances (verify revision with Honeywell datasheet)
- UL Listed — Underwriters Laboratories industrial control equipment
Quality Assurance & Sourcing
Every Honeywell 51304260-200 module supplied by Konmask undergoes the following quality process:
- ✅ Visual inspection for physical damage, corrosion, and component integrity
- ✅ Functional power-on test and I/O channel verification
- ✅ Firmware / revision label verification against Honeywell documentation
- ✅ Anti-static packaging with humidity indicator card
- ✅ Traceable sourcing from OEM-authorized distributors or decommissioned plant inventories
- ✅ 90-day replacement warranty on all tested units
How to Source This Part
Ready to procure the Honeywell 51304260-200? Here’s how to get started:
- Add to Cart — for immediate online checkout with secure payment
- Request a Quote — for bulk orders, project BOMs, or freight-inclusive pricing
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; sourced units within 7–14 business days
- Export: We ship globally with full export documentation (commercial invoice, packing list, COO)
Application-Specific FAQ
Q: Is the 51304260-200 compatible with both TDC 3000 and TPS (TotalPlant Solution) systems?
A: Yes. The module is designed for the Honeywell TDC 3000 platform, which evolved into the TotalPlant Solution (TPS). It is slot-compatible with standard TDC 3000 card cages used in both architectures.
Q: Can this module be used as a hot-standby redundant input?
A: Redundancy configuration depends on the specific HPM or PM controller setup. Consult your Honeywell system engineer or contact Konmask for application-specific guidance.
Q: What is the difference between 51304260-100 and 51304260-200?
A: The suffix (-100, -200) typically denotes a hardware revision or configuration variant. Always verify the exact revision required by your system’s I/O assignment documentation before ordering.
Q: Do you provide a test report with the module?
A: Yes. A functional test report is available upon request for refurbished and used-tested units.
Q: Can Konmask source other Honeywell TDC 3000 spare parts?
A: Absolutely. We specialize in legacy DCS and PLC spare parts. Contact us with your full BOM for a consolidated quote.
