Honeywell 51304632-100C – Cabinet Mount Tab Assembly | TDC 3000 DCS Platform
Engineering Background
The Honeywell 51304632-100C is a precision-engineered cabinet mount tab assembly designed for use within Honeywell’s TDC 3000 Distributed Control System (DCS) architecture. As a structural mounting component, it provides the mechanical interface between DCS controller modules and the process control cabinet enclosure, ensuring rigid, vibration-resistant installation in demanding industrial environments.
Product Positioning
This OEM-grade assembly is the preferred choice for maintenance engineers and system integrators performing cabinet upgrades, module replacements, or greenfield DCS installations. Sourced directly from verified Honeywell supply channels, the 51304632-100C guarantees dimensional accuracy and material compliance with original factory specifications.
Complete Technical Specifications
- Part Number: 51304632-100C
- Manufacturer: Honeywell Process Solutions
- Series / Platform: TDC 3000 DCS
- Component Type: Cabinet Mount Tab Assembly
- Function: Structural mounting interface for DCS modules within control cabinet enclosures
- Weight: 920 g
- Country of Origin: USA (Honeywell OEM)
- Condition: New / Refurbished (specify at inquiry)
- Compliance: Honeywell OEM specification; compatible with TDC 3000 cabinet standards
- HS Code: 8538.90 (parts for electrical apparatus for switching/protecting electrical circuits)
Proven Application Environments
- Petroleum refining and petrochemical process plants
- Power generation facilities (coal, gas, nuclear auxiliary systems)
- Pulp and paper manufacturing DCS control rooms
- Chemical and specialty chemical batch processing
- Water treatment and municipal utility automation
- Offshore oil & gas platform control systems
Engineering Advantages
- OEM Dimensional Accuracy: Manufactured to Honeywell’s original tooling specifications — no field modification required for drop-in replacement.
- Vibration Resistance: Designed to maintain module alignment under continuous industrial vibration per Honeywell cabinet standards.
- Material Integrity: Industrial-grade materials resist corrosion and thermal cycling in control room environments.
- System Compatibility: Verified fit for TDC 3000 cabinet configurations; eliminates integration risk during maintenance windows.
- Reduced Downtime: Ready-to-install assembly minimizes cabinet reconfiguration time during planned or emergency maintenance.
System Architecture & Signal Flow
Within the TDC 3000 architecture, the 51304632-100C tab assembly serves as the mechanical backbone securing controller and I/O modules to the cabinet backplane rail system. Proper installation ensures:
- Correct module seating against backplane connectors for uninterrupted signal continuity
- Grounding path integrity between module chassis and cabinet earth rail
- Thermal management alignment — modules remain positioned for optimal airflow across heat-generating components
- Physical security against accidental module dislodgement during adjacent maintenance activities
Sourcing & Quality Verification
- Source: Authorized Honeywell distribution network and verified surplus channels
- Inspection: Each unit inspected for dimensional conformance, surface integrity, and hardware completeness prior to shipment
- Documentation: Certificate of conformance and packing list provided with every order
- Traceability: Lot and batch records available upon request for regulated industries
- Anti-Counterfeit: All parts verified against Honeywell OEM markings and part number labeling standards
Procurement Process
- Submit your RFQ via the product page or email support@konmask.com
- Receive stock confirmation and lead time within 24 business hours
- Review proforma invoice and approve payment terms
- Order processed and dispatched with full shipping documentation (commercial invoice, packing list, CoC)
- Post-delivery technical support available for installation queries
Technical FAQ
Q: Is the 51304632-100C compatible with all TDC 3000 cabinet variants?
A: It is designed for standard TDC 3000 cabinet configurations. Please confirm your cabinet revision with our technical team if you are working with a non-standard enclosure.
Q: Can this part be used as a direct replacement without cabinet modification?
A: Yes. The 51304632-100C is an OEM assembly manufactured to original specifications, enabling direct drop-in replacement without field modification.
Q: Do you supply documentation for regulated plant environments?
A: Yes. Certificate of conformance, material traceability records, and inspection reports are available upon request.
Q: What is the typical lead time?
A: In-stock orders ship within 3–5 business days. For out-of-stock items, lead time is confirmed at the time of RFQ.
Q: Do you accept purchase orders from industrial facilities?
A: Yes. We accept PO-based procurement for qualified industrial buyers. Contact us to establish account terms.
