Honeywell 900G02-0102 – High-Density Analog Input Module | Experion PKS / TDC 3000 Platform
Engineering Background
The Honeywell 900G02-0102 is a high-density analog input module designed for integration within Honeywell’s Experion PKS (Process Knowledge System) and TDC 3000 distributed control system platforms. Engineered to meet the rigorous demands of continuous process industries, this module delivers precise signal acquisition, robust noise immunity, and seamless compatibility with Honeywell’s C300 controller architecture. It is a critical component in process automation loops where measurement accuracy and system uptime are non-negotiable.
Product Positioning
Targeted at procurement engineers and MRO (Maintenance, Repair & Operations) teams in refining, petrochemical, power generation, and specialty chemical facilities, the 900G02-0102 serves as a direct replacement or expansion module for existing Honeywell DCS installations. Konmask.com maintains verified stock of this module to support both planned capital projects and emergency maintenance scenarios with minimal lead time.
Complete Technical Specifications
| Part Number | 900G02-0102 |
| Manufacturer | Honeywell Process Solutions |
| Module Type | Analog Input Module |
| Compatible Platform | Experion PKS, TDC 3000, Series C |
| Input Signal Types | 4–20 mA, 1–5 VDC, Thermocouple (J, K, T, E, R, S, B), RTD (Pt100, Pt200, Ni120) |
| Channel Count | 16 channels (configurable per application) |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-bus optical isolation |
| Power Supply | 24 VDC (supplied via backplane) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Dimensions (W×H×D) | Refer to Honeywell 900 Series mechanical drawing |
| Weight | Approx. 200 g |
| Certifications | CE, UL, FM (Class I, Div. 2), ATEX (Zone 2) |
| Communication Bus | Honeywell FTE (Fault Tolerant Ethernet) / CEE backplane |
| Firmware | Field-upgradeable via Experion Engineering Tools |
| MTBF | >200,000 hours (per Honeywell reliability data) |
Proven Application Environments
- Oil & Gas Refining – Crude distillation unit temperature and pressure loop monitoring
- Petrochemical Plants – Reactor feed flow measurement and multi-stream analytics
- Power Generation – Boiler drum level and steam header pressure acquisition
- Specialty Chemicals – Batch process temperature profiling with thermocouple inputs
- LNG Terminals – Cryogenic temperature measurement via RTD channels
- Pulp & Paper – Digester pressure and consistency control loops
Engineering Advantages
- Hot-Swap Capability – Module can be replaced under power without process interruption, minimizing unplanned downtime
- Redundancy Support – Compatible with Honeywell’s 1:1 and N+1 redundancy schemes for mission-critical loops
- Universal Input Flexibility – Single module supports mA, voltage, TC, and RTD inputs, reducing spare-parts inventory complexity
- Integrated Diagnostics – On-board self-test and HART pass-through capability for field device health monitoring
- EMI/RFI Immunity – Designed to IEC 61000-4 series standards for industrial electromagnetic environments
- Long-Term Availability – Konmask maintains buffer stock to support 10+ year plant lifecycle requirements
System Architecture & Signal Flow
The 900G02-0102 mounts directly onto the Honeywell Series 900 I/O backplane within the C300 controller cabinet. Field signals enter via the terminal block assembly (ordered separately as 900TBA-0001 or equivalent), pass through the module’s input conditioning circuitry (filtering, scaling, cold-junction compensation for TC inputs), are digitized by the 16-bit ADC, and transmitted over the CEE backplane to the C300 controller. The Experion PKS server polls the module at configurable scan rates (default 100 ms) and makes process values available to control strategies, historians, and operator displays in real time. Redundant power feeds from the backplane ensure continuous operation during single-point power supply failures.
Sourcing & Quality Verification
- Origin: Sourced from authorized Honeywell channel partners and verified MRO distributors
- Inspection Protocol: Each unit undergoes visual inspection, firmware version verification, and functional power-on test prior to shipment
- Traceability: Serial number and date code recorded; documentation package available upon request
- Condition: New (factory-sealed) and refurbished (tested, warranted) options available — specify at time of inquiry
- Counterfeit Mitigation: All modules verified against Honeywell’s published part marking and label standards
Procurement Process
- Submit RFQ – Email support@konmask.com with quantity, required condition (new/refurbished), and delivery timeline
- Receive Quotation – Formal quotation with unit price, lead time, and shipping options issued within 1 business day
- Order Confirmation – Purchase order accepted via email; proforma invoice issued for prepayment or net terms (approved accounts)
- Quality Check & Dispatch – Module inspected, packed in anti-static ESD packaging, and shipped via DHL / FedEx with tracking
- Post-Delivery Support – Technical support available for installation verification and Experion configuration assistance
Technical FAQ
Q: Is the 900G02-0102 compatible with both Experion PKS R500 and earlier TDC 3000 systems?
A: Yes. The module is backward-compatible with TDC 3000 Series C I/O infrastructure and fully supported under Experion PKS R400 through R520. Confirm firmware revision with your Honeywell system engineer for R500+ deployments.
Q: Can this module be used in SIL-rated safety loops?
A: The 900G02-0102 is a standard process I/O module and is not SIL-certified. For safety instrumented systems, Honeywell’s Safety Manager SC or FSC platform with dedicated SIL-rated I/O is required.
Q: What is the lead time for new units?
A: In-stock units ship within 3–5 business days. For large quantities or factory-new sealed units, lead time is 4–8 weeks depending on Honeywell’s production schedule. Contact us for current availability.
Q: Do you provide a warranty?
A: Yes. New units carry a 12-month warranty. Refurbished units carry a 6-month warranty covering functional defects. Warranty claims are processed via RMA with Konmask.
Q: Can Konmask assist with Experion PKS configuration after installation?
A: We provide basic commissioning guidance and can connect you with certified Honeywell system integrators in your region for full engineering support.
