Honeywell 900RTC-BA50 – 8-Channel Analog Output RTP Cable | Experion PKS C300 Platform
Engineering Background: The Honeywell 900RTC-BA50 is a factory-engineered Remote Termination Panel (RTP) cable designed specifically for the Experion PKS C300 Distributed Control System architecture. It provides a reliable, shielded signal path between the C300 controller I/O modules and field-side analog output termination panels, eliminating the need for custom field wiring at the marshalling cabinet level.
Product Positioning: Targeted at process automation engineers and MRO procurement teams managing Honeywell Experion PKS installations in refining, petrochemical, power generation, and advanced manufacturing environments. The 900RTC-BA50 is a direct OEM replacement cable that ensures signal integrity and system compliance without re-engineering.
Complete Technical Specifications
| Part Number | 900RTC-BA50 |
| Manufacturer | Honeywell Process Solutions |
| Series / Platform | Experion PKS – C300 Controller Series |
| Function | Analog Output Remote Termination Panel Cable |
| Cable Length | 50 cm (0.5 m) |
| Channel Count | 8-Channel Analog Output |
| Signal Type | 4–20 mA current loop (AO) |
| Connector Type | Proprietary Honeywell RTP plug – both ends |
| Shielding | Overall foil shield with drain wire |
| Operating Temperature | 0°C to +60°C |
| Weight | Approx. 350 g |
| Country of Origin | United States |
| Compliance | CE, RoHS |
| Compatible I/O Module | Honeywell 900 Series AO I/O modules |
| Compatible RTP | Honeywell 900RTP-BA series termination panels |
Proven Application Environments
- Oil & Gas Refining: Analog valve positioner control loops in distillation and separation units
- Petrochemical Plants: Flow control and pressure regulation via 4–20 mA AO signals
- Power Generation: Turbine governor and boiler control systems on Experion PKS platforms
- Pharmaceutical Manufacturing: GMP-compliant process control with validated I/O wiring
- Pulp & Paper / Mining: Harsh-environment DCS installations requiring robust termination solutions
- MRO / Spare Parts Programs: Direct OEM replacement for aging Experion PKS C300 installations
Engineering Advantages
- OEM Precision Fit: Factory-terminated connectors guarantee correct pin-out — no field crimping errors
- Signal Integrity: Foil shielding suppresses EMI/RFI interference in high-noise industrial cabinets
- Zero Re-Engineering: Drop-in replacement; no modification to marshalling or I/O module required
- Reduced Commissioning Time: Pre-tested cable assembly eliminates continuity testing at installation
- System Compliance: Maintains Honeywell system warranty and FAT/SAT documentation integrity
- Compact 50 cm Length: Optimized for standard cabinet depth; minimizes cable management complexity
System Architecture & Signal Flow
In the Experion PKS C300 architecture, the 900RTC-BA50 connects the C300 AO I/O module backplane to the 900RTP-BA Remote Termination Panel mounted on the DIN rail within the same or adjacent cabinet. The signal flow is:
C300 Controller → AO I/O Module → [900RTC-BA50 Cable] → 900RTP-BA Termination Panel → Field Instrument (Valve / Actuator)
This architecture eliminates individual wire terminations at the I/O module, centralizing field wiring at the RTP for faster loop checkout and reduced wiring errors during commissioning and maintenance.
Sourcing & Quality Verification
- All units sourced from authorized Honeywell distributors or verified OEM surplus channels
- Each cable inspected for connector integrity, shielding continuity, and label accuracy prior to shipment
- Original Honeywell part labeling and date codes preserved — no remarking or repackaging
- Traceability documentation available upon request for regulated industries
- Packaging: anti-static bag + protective outer carton; ESD-safe handling throughout
Procurement Process
- Confirm Compatibility: Verify your C300 AO I/O module part number and RTP model against the 900RTC-BA50 compatibility matrix
- Request Quote: Contact us via email or phone for volume pricing, lead time, and availability confirmation
- Place Order: Purchase directly through Konmask.com or via purchase order for B2B accounts
- Shipment: Ships within 1–3 business days; DHL / FedEx international express available
- Documentation: Commercial invoice, packing list, and optional COC/traceability report included
Technical FAQ
Q: Is the 900RTC-BA50 compatible with the C200 or C300E controller?
A: The 900RTC-BA50 is designed for the C300 platform. Compatibility with C200 or C300E variants depends on the specific I/O module — please confirm your module part number before ordering.
Q: Can this cable be used for Analog Input (AI) channels?
A: No. The 900RTC-BA50 is specifically designed for Analog Output (AO) termination. For AI applications, refer to the 900RTC-HA series.
Q: What is the maximum cable run distance?
A: This is an intra-cabinet RTP cable (50 cm). It is not designed for long-distance field runs. Field wiring connects at the RTP terminal blocks.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all components. Extended warranty and exchange programs available for volume buyers.
Q: Can I get a datasheet or wiring diagram?
A: Yes — contact support@konmask.com with your project details and we will provide the relevant Honeywell technical documentation.
