Honeywell CC-CBDD01 – C300 Controller Backplane Data Distribution Card | Experion PKS DCS Platform
Engineering Background: The Honeywell CC-CBDD01 is a critical backplane-level data distribution card designed for the C300 Controller chassis within Honeywell’s Experion PKS (Process Knowledge System) distributed control architecture. It serves as the internal communication backbone between the controller module and I/O link interfaces, enabling deterministic, high-integrity data exchange across the control node.
Product Positioning: Targeted at process industries requiring continuous, fault-tolerant control — including refining, petrochemical, power generation, and advanced manufacturing — the CC-CBDD01 is an OEM-specified replacement and expansion component. Procurement engineers sourcing spares or building redundant controller nodes will find this module essential for maintaining system integrity and minimizing unplanned downtime.
Complete Technical Specifications
- Part Number: CC-CBDD01
- Manufacturer: Honeywell Process Solutions
- Platform: Experion PKS — C300 Controller Series
- Module Type: Backplane Data Distribution Card
- Form Factor: Backplane-mounted card, C300 chassis compatible
- Communication Role: Internal data bus distribution between C300 controller and I/O link modules
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Humidity: 5% to 95% non-condensing
- Power Supply: Supplied via backplane (chassis-powered)
- Weight: Approx. 1,060 g
- Compliance: CE, UL, RoHS-compatible (verify with current Honeywell datasheet)
- Country of Origin: United States
Proven Application Environments
- Oil & Gas — upstream/downstream process control nodes
- Petrochemical and refinery DCS backbone infrastructure
- Power generation plant automation (coal, gas, nuclear auxiliary systems)
- Pharmaceutical batch and continuous process control
- Pulp & paper and specialty chemical manufacturing
- Water treatment and municipal utility SCADA/DCS hybrid systems
Engineering Advantages
- Deterministic Data Distribution: Ensures time-critical process data reaches controller logic without latency variance, supporting tight loop control.
- Chassis-Native Integration: Designed exclusively for C300 backplane geometry — no adapter or signal conditioning required.
- Redundancy Support: Compatible with redundant C300 controller configurations, enabling hot-standby architectures.
- OEM Specification Compliance: Meets Honeywell’s original design tolerances for signal integrity and EMI immunity within the Experion PKS environment.
- Long Service Life: Industrial-grade components rated for continuous 24/7 operation in harsh process environments.
System Architecture & Signal Flow
Within the Experion PKS C300 node, the CC-CBDD01 occupies the backplane slot designated for data distribution. It interfaces directly with the C300 Controller Module (e.g., CC-PCNT01) on one side and the Series C I/O Link modules on the other. Data from field instruments travels via I/O modules → I/O Link → CC-CBDD01 backplane bus → C300 Controller for real-time processing. Control outputs follow the reverse path. This architecture isolates field-side noise from controller logic, maintaining signal fidelity across the entire control loop.
Sourcing & Quality Verification
- Source: Konmask.com sources CC-CBDD01 units from decommissioned plant upgrades, certified surplus channels, and authorized distributor networks.
- Inspection: Each unit undergoes visual inspection, connector integrity check, and label/firmware verification prior to listing.
- Condition Options: New surplus (sealed), refurbished (tested), and used-tested — condition specified at time of inquiry.
- Documentation: Original Honeywell part labels, revision markings, and available test records provided upon request.
- Warranty: 90-day functional warranty standard; extended warranty available by arrangement.
Procurement Process
- Confirm part number CC-CBDD01 and required quantity with your engineering team.
- Submit inquiry via Konmask.com product page or email support@konmask.com with your PO requirements.
- Receive stock confirmation, condition report, and formal quotation within 1 business day.
- Issue PO — payment via T/T, PayPal, or trade terms for qualified accounts.
- Shipping via DHL / FedEx / UPS Express with full tracking; export documentation (commercial invoice, packing list, COO) included.
- Post-delivery technical support available for integration and commissioning queries.
Technical FAQ
Q: Is CC-CBDD01 compatible with all C300 chassis revisions?
A: The CC-CBDD01 is designed for standard C300 controller chassis. Compatibility with specific chassis revisions should be verified against your Experion PKS system documentation or Honeywell’s compatibility matrix.
Q: Can this card be used in a redundant controller configuration?
A: Yes. The CC-CBDD01 supports redundant C300 controller node architectures when paired with the appropriate redundancy modules per Honeywell’s system design guidelines.
Q: What is the lead time for CC-CBDD01?
A: In-stock units ship within 1–3 business days. For out-of-stock scenarios, sourcing lead time is typically 2–4 weeks. Contact us for real-time availability.
Q: Do you provide a certificate of conformance?
A: Yes, a certificate of conformance and available inspection records are provided upon request for all units.
Q: Is this a genuine Honeywell part?
A: All units listed are OEM Honeywell components. We do not sell counterfeit or third-party replica parts. Part authenticity can be verified via Honeywell’s part marking and revision codes.
