Flow Metering & Pulse Counting Solution — Honeywell CC-PAIN01 51410069-176 | C300 Series
Where This Product Is Used
The Honeywell CC-PAIN01 (Part No. 51410069-176) is a dedicated Pulse Input module engineered for the Experion PKS C300 Controller platform. It is deployed across high-demand industrial environments where accurate pulse-based signal acquisition is critical:
- Oil & Gas: Turbine flow meter integration on wellheads, pipelines, and custody-transfer skids
- Petrochemical & Refining: Reactor feed-rate monitoring via pulse-output flow transmitters
- Power Generation: Steam flow and fuel-gas metering in combined-cycle and cogeneration plants
- Water & Wastewater: Electromagnetic and vortex flow meter pulse counting for SCADA-linked treatment plants
- Pharmaceutical & Food Processing: Batch ingredient dosing with high-resolution pulse accumulation
- Mining & Minerals: Slurry and reagent flow measurement in flotation and leaching circuits
Technical Specifications
| Manufacturer | Honeywell Process Solutions |
| Part Number | CC-PAIN01 |
| Reference Number | 51410069-176 |
| Module Type | Pulse Input (PAIN) |
| Series / Platform | C300 / Experion PKS |
| Form Factor | Series C I/O Module (plug-in card) |
| Input Channels | Pulse / frequency signal inputs |
| Signal Compatibility | Dry contact, NPN/PNP, voltage pulse |
| Communication | FTE (Fault Tolerant Ethernet) via C300 backplane |
| Operating Temperature | 0 °C to 60 °C |
| Weight | 300 g (approx.) |
| Certifications | CE, UL, FM (refer to Honeywell datasheet for full listing) |
Why Engineers Specify This Model
- Native C300 Integration: Plug-and-play compatibility with Experion PKS eliminates custom signal conditioning hardware
- High-Frequency Pulse Accuracy: Captures high-speed pulse trains from turbine and vortex meters without signal loss
- Redundancy-Ready Architecture: Supports CHARM-based and traditional I/O redundancy configurations
- Reduced Wiring Complexity: Backplane-mounted design minimizes field wiring and cabinet footprint
- Proven Reliability: Honeywell’s Series C I/O modules are field-proven in thousands of Experion PKS installations globally
- Long Product Lifecycle: Honeywell’s extended support commitment protects capital investment in existing DCS infrastructure
Complete System Bill of Materials
For a fully operational Pulse Input node on Experion PKS C300, engineers typically specify:
- CC-PAIN01 (51410069-176) — Pulse Input Module (this item)
- CC-TCNT01 / CC-TCNT11 — Series C I/O Termination Assembly
- CC-PWRR01 / CC-PWRS01 — Series C Power Supply Module
- C300 Controller (CC-PCF901 or equivalent)
- ENET-2 or FTE Switch for network redundancy
- Experion PKS R500+ Server (for configuration and historian)
Compliance & Industry Standards
- IEC 61511 — Functional Safety for Process Industry Sectors
- IEC 61131-2 — Programmable Controllers Hardware Requirements
- ISA-5.1 — Instrumentation Symbols and Identification
- CE Marking (EU EMC & Low Voltage Directives)
- UL Listed / FM Approved (verify current certificate with Honeywell)
- RoHS Compliant
Quality Assurance & Sourcing
Konmask.com specializes in genuine, traceable industrial automation components for DCS, PLC, and SCADA systems. Every CC-PAIN01 unit we supply:
- Is sourced from authorized distributors or verified surplus channels
- Undergoes visual inspection and functional verification prior to dispatch
- Ships with original packaging and documentation where available
- Carries a 12-month warranty against manufacturing defects
- Is traceable via serial number and batch records
How to Source This Part
Ready to order or need a formal quotation? Contact our technical sales team:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://konmask.com
- We respond to RFQs within 24 business hours and can provide datasheets, certificates of conformance, and lead-time commitments on request.
Application-Specific FAQ
- Q: Is CC-PAIN01 compatible with Experion PKS R400 and earlier?
- A: The CC-PAIN01 is designed for the C300 platform. Compatibility with R400 and earlier releases should be verified against Honeywell’s compatibility matrix. Contact us for guidance.
- Q: Can this module accept signals from a Coriolis flow meter?
- A: Yes, provided the Coriolis transmitter outputs a standard pulse/frequency signal (dry contact or voltage pulse). Verify signal voltage levels against the module’s input specifications.
- Q: What is the maximum pulse frequency the CC-PAIN01 can handle?
- A: Refer to Honeywell’s official datasheet (Doc. 51-52-25-107) for the rated maximum input frequency. Contact our team for a copy.
- Q: Do you offer exchange or repair services for faulty CC-PAIN01 modules?
- A: Yes. We offer board-level repair and exchange programs. Contact support@konmask.com with your module’s serial number for a repair quote.
- Q: Is this module available for immediate shipment?
- A: Stock availability changes frequently. Contact us directly for real-time inventory status and lead times.
