Honeywell CC-PAIX02 | CC-PAIH02 | CC-PAIH01 Experion High Level Analog Input Module | Replacement, Equivalent & Selection Guide
The Honeywell CC-PAIX02 (also referenced as CC-PAIH02 and CC-PAIH01) is a high-level analog input module designed for the Honeywell Experion PKS distributed control system (DCS). This module provides reliable, high-accuracy analog signal acquisition for process automation environments. At Konmask.com, we specialize in sourcing, cross-referencing, and supplying original and compatible replacement modules for industrial automation systems.
Technical Specifications
- Part Numbers: CC-PAIX02 / CC-PAIH02 / CC-PAIH01
- Brand: Honeywell
- Series: Experion PKS (Process Knowledge System)
- Module Type: High Level Analog Input Module
- Signal Type: High-level analog input (voltage/current)
- Channels: Multi-channel analog input
- Communication: C300 Controller backplane compatible
- Mounting: DIN rail / chassis mount (Experion I/O chassis)
- Operating Temperature: 0°C to 60°C
- Weight: ~160 g
- Condition: New / Refurbished available
Compatible Replacement & Equivalent Models
The following models are commonly cross-referenced as functional equivalents or drop-in replacements for the CC-PAIX02 within the Experion PKS platform:
- CC-PAIH02 — Direct variant; same functional class, verify firmware revision compatibility
- CC-PAIH01 — Earlier revision; compatible in most Experion PKS configurations
- CC-PAIM01 — Mixed analog I/O module; suitable for applications requiring combined I/O
- CC-PAIX01 — Previous generation high-level analog input; confirm channel count requirements
- 51304485-150 / 51304485-175 — Legacy TDC/TPS analog input cards; requires I/O link adapter for Experion integration
Always verify hardware revision, firmware version, and chassis slot compatibility before substitution. Contact support@konmask.com for a free compatibility check.
Why Choose the Original CC-PAIX02
- Factory-validated for Honeywell Experion PKS C300 controller architecture
- Guaranteed signal integrity and calibration accuracy out of the box
- Full Honeywell technical support and firmware update eligibility
- Minimizes integration risk in safety-critical process environments
- Backed by Honeywell’s global spare parts and lifecycle management program
Typical Applications
- Oil & gas refinery process control (temperature, pressure, flow measurement)
- Chemical and petrochemical plant DCS integration
- Power generation and utilities automation
- Pharmaceutical batch process monitoring
- Pulp & paper and water treatment plant control systems
System Compatibility
- Controller: Honeywell C300 Process Controller
- Platform: Experion PKS R310 and above (verify for specific revision)
- I/O Chassis: Honeywell IOTA / Series C I/O chassis
- Software: Honeywell Control Builder, Experion Station
- Redundancy: Supports redundant I/O configurations with appropriate IOTA
Selection Guide
Use the table below to select the correct analog input module for your Experion PKS system:
| Model | Signal Type | Channels | Revision | Best For |
|---|---|---|---|---|
| CC-PAIX02 | High-level analog input | Multi | Latest | New installations & upgrades |
| CC-PAIH02 | High-level analog input | Multi | Mid | Direct swap in existing systems |
| CC-PAIH01 | High-level analog input | Multi | Early | Legacy system maintenance |
| CC-PAIM01 | Mixed analog I/O | Multi | — | Combined I/O requirements |
Not sure which model fits your system? Send us your system revision and chassis configuration at support@konmask.com and we’ll confirm compatibility within 24 hours.
Quality Assurance & Sourcing
- All modules sourced from authorized distributors or verified surplus channels
- Pre-shipment functional testing available on request
- Authenticity verification — no counterfeit or grey-market parts
- Traceability documentation provided for critical process industries
- ISO-aligned quality inspection process at Konmask.com warehouse
How to Order
- Add the CC-PAIX02 (or your required equivalent) to cart
- Proceed to checkout — we accept T/T, PayPal, and major credit cards
- For bulk orders (>5 units) or urgent requirements, contact us directly for priority pricing
- Lead time: In-stock items ship within 1–3 business days; sourced items 5–15 business days
- Global shipping available — DHL, FedEx, UPS express options
Replacement & Compatibility FAQ
Q: Can CC-PAIH01 replace CC-PAIX02 directly?
A: In most Experion PKS configurations yes, but firmware revision and IOTA compatibility must be verified. Contact us for a free check.
Q: Is the CC-PAIX02 compatible with Experion PKS R400+?
A: Compatibility depends on the specific R-release and C300 firmware. We recommend confirming with your system revision documentation or contacting our technical team.
Q: Do you supply refurbished CC-PAIX02 modules?
A: Yes. Refurbished units are available with full functional testing reports. Specify your preference at checkout or via email.
Q: What is the lead time for CC-PAIX02?
A: In-stock units ship within 1–3 business days. For sourced or refurbished units, allow 5–15 business days.
Q: Can I return a module if it’s incompatible?
A: Yes, we offer a 30-day return policy for unused modules in original packaging. See our returns policy for details.
