Honeywell CC-PUIO31 (51454220-176) – Universal I/O Module | Experion PKS C300 Platform
Engineering Background: The CC-PUIO31 is a field-proven Universal I/O module engineered for Honeywell’s Experion PKS process automation platform. Carrying part number 51454220-176, this module operates within the C300 Controller architecture, delivering flexible, high-density I/O connectivity for mission-critical process control environments across oil & gas, refining, power generation, and chemical processing industries.
Product Positioning: Designed for procurement engineers and automation specialists who require a drop-in replacement or expansion module with guaranteed compatibility within existing Experion PKS infrastructure. Konmask.com supplies this module with full traceability documentation, enabling confident integration without system downtime risk.
Complete Technical Specifications
- Part Number: CC-PUIO31
- Catalog / Order Number: 51454220-176
- Manufacturer: Honeywell Process Solutions
- Platform: Experion PKS – C300 Controller Series
- Module Type: Universal I/O (PUIO)
- I/O Channels: 32 universal channels (configurable AI / AO / DI / DO per channel)
- Signal Types: 4–20 mA, 0–10 V DC, HART, discrete 24 V DC
- HART Support: Yes – per-channel HART pass-through
- Communication Bus: FTE (Fault Tolerant Ethernet) via C300 backplane
- Power Supply: Supplied via module carrier / backplane (no external PSU required)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: –40 °C to +85 °C
- Humidity: 5–95% RH, non-condensing
- Dimensions (W × H × D): Standard Experion PKS module form factor
- Weight: Approx. 2,500 g (packaged)
- Certifications: CE, UL, FM (Class I Div 2), ATEX (consult datasheet)
- Firmware: Compatible with Experion PKS R400 and above
Proven Application Environments
- Oil & Gas upstream / midstream / downstream process control
- Petroleum refinery DCS migration and expansion projects
- Power plant boiler and turbine control systems
- Chemical and petrochemical batch/continuous process automation
- Pulp & paper and water treatment facilities running Experion PKS
- Pharmaceutical manufacturing with validated control architectures
Engineering Advantages
- Universal Channel Flexibility: Each of the 32 channels is software-configurable as AI, AO, DI, or DO — eliminating the need for dedicated module types and reducing spare-parts inventory.
- HART Integration: Native per-channel HART support enables device diagnostics and asset management without additional multiplexers.
- Hot-Swap Capability: Supports live insertion and removal within the C300 carrier, minimizing planned maintenance windows.
- Redundancy Ready: Fully compatible with Honeywell’s redundant I/O architecture for SIL-rated and high-availability loops.
- Reduced Wiring Complexity: Single module replaces multiple dedicated I/O cards, cutting cabinet footprint and field wiring labor.
System Architecture & Signal Flow
The CC-PUIO31 mounts directly onto a C300-compatible I/O Link Extender (IOLIM) carrier. Field signals terminate at the carrier’s field termination assembly (FTA), pass through the PUIO module’s signal conditioning circuitry, and are transmitted over the FTE backplane to the C300 Controller. The C300 executes control strategies in Experion PKS Control Builder and returns output commands to the module in real time. HART digital signals are simultaneously extracted and forwarded to the Experion Asset Management system for device health monitoring.
Sourcing & Quality Verification
- Source: Authorized distributor channels and verified surplus inventory with documented chain of custody
- Inspection: Each unit undergoes visual inspection, label verification (P/N + Rev level), and functional power-on check prior to shipment
- Packaging: ESD-safe anti-static bag + foam-lined carton; original Honeywell packaging preserved where available
- Documentation: Certificate of conformance (CoC) and test report available upon request
- Warranty: 12-month Konmask operational warranty against manufacturing defects
Procurement Process
- Submit your RFQ via [email protected] or the on-site inquiry form
- Receive a formal quotation with lead time, CoC availability, and shipping options within 24 hours
- Confirm PO — payment via T/T, PayPal, or credit card accepted
- Module ships within 1–3 business days; express DHL / FedEx available for urgent requirements
- Post-delivery technical support provided by Konmask engineering team
Technical FAQ
Q: Is CC-PUIO31 compatible with Experion PKS R500 / R501?
A: Yes. The module is backward and forward compatible across Experion PKS R400–R501 releases. Confirm firmware revision with your Honeywell system integrator for specific feature sets.
Q: Can this module replace CC-PAIX01 or CC-PDOB01 dedicated modules?
A: Yes. The Universal I/O architecture allows the CC-PUIO31 to be configured as a direct functional replacement for dedicated analog input, analog output, or discrete I/O modules within the same carrier slot.
Q: What is the lead time for urgent orders?
A: In-stock units ship within 1 business day. Express courier delivery to most destinations within 3–5 business days.
Q: Do you provide a test report or CoC?
A: Yes. Certificate of conformance and inspection report are available for all units. Request at time of order.
Q: Is this module suitable for SIL 2 safety loops?
A: The CC-PUIO31 supports Honeywell’s Safety Manager integration when configured within a validated safety architecture. Consult your functional safety engineer for SIL loop assessment.
