Honeywell MC-TAMR03 (51309218-175) Low Level Analog Mux Module | Replacement, Equivalent & Selection Guide
The Honeywell MC-TAMR03 (part number 51309218-175) is a Low Level Analog Multiplexer (Mux) Module designed for use within Honeywell’s TotalPlant Solution (TPS) and PlantScape distributed control systems. It conditions and multiplexes low-level analog signals — such as thermocouple and RTD inputs — before routing them to the system’s process controllers, enabling high-density, accurate field signal acquisition in demanding industrial environments.
Selection Background
When sourcing a replacement for the MC-TAMR03, buyers frequently search for equivalent modules that match its signal conditioning range, channel count, and backplane interface. Whether you are performing a like-for-like swap after a hardware failure, planning a system upgrade, or evaluating substitute options during a DCS migration, understanding the compatibility boundaries of each alternative is critical to maintaining process integrity. This guide consolidates that information to support your selection decision.
Technical Specifications
| Part Number | MC-TAMR03 / 51309218-175 |
| Manufacturer | Honeywell Process Solutions |
| Module Type | Low Level Analog Mux Module |
| Compatible System | Honeywell TPS / PlantScape DCS |
| Signal Type | Low-level analog (thermocouple, RTD, mV) |
| Input Channels | Multi-channel multiplexed analog inputs |
| Signal Conditioning | Integrated cold junction compensation (CJC) for TC inputs |
| Backplane Interface | TPS/PlantScape proprietary card bus |
| Power Supply | Supplied via system backplane |
| Operating Temperature | 0 °C to 60 °C |
| Weight | 750 g (approx.) |
| Certifications | CE, UL (per system-level approval) |
| ⚠ Key Replacement Parameters | Channel count, signal type (TC/RTD/mV), backplane slot compatibility, firmware revision |
Compatible Replacement & Equivalent Models
1. Direct Drop-in Replacements
The following Honeywell part numbers are confirmed or commonly cited as direct substitutes for the MC-TAMR03 within the same TPS/PlantScape chassis:
- 51309218-175 — OEM part number; functionally identical, same firmware baseline
- MC-TAMR03 (Rev B/C) — Later hardware revisions; verify firmware compatibility with your controller version before installation
Prerequisite: Same backplane slot type; no configuration change required for identical revision.
2. Functional Equivalents
Modules that perform the same low-level analog mux function within the Honeywell ecosystem but may require configuration or firmware updates:
- MC-TAIH02 / MC-TAIH04 — High-level analog input modules; suitable if field signals can be re-ranged to 4–20 mA or 1–5 V; requires I/O reconfiguration in the builder
- MC-PAIH03 — Process Analog Input module; functional equivalent for standard analog ranges; verify channel density requirements
Note: Signal wiring and loop power configuration must be reviewed before substitution.
3. Cross-Brand Alternatives
For system migrations or when OEM parts are unavailable, the following third-party or alternative-platform modules offer comparable low-level analog mux functionality:
- Emerson DeltaV AI Card (MD Plus) — Supports TC/RTD inputs; requires full DCS migration; not a slot-compatible substitute
- ABB S800 AI810 / AI820 — Analog input modules with similar channel density; applicable in greenfield or hybrid architectures only
- Yokogawa AAI141-S — Multi-channel analog input; cross-brand alternative for system-level redesign projects
⚠ Cross-brand alternatives are NOT plug-compatible. Full engineering review, rewiring, and software reconfiguration are required.
Why Choose the Original MC-TAMR03
- Measurement Precision: Factory-calibrated for low-level signals (mV range); maintains accuracy across thermocouple and RTD types without external signal conditioning
- System Certification: Tested and approved as part of the Honeywell TPS/PlantScape system; maintains overall system SIL and safety integrity ratings
- Backplane Compatibility: Guaranteed slot-level compatibility with TPS chassis; no mechanical or electrical adaptation required
- Firmware Alignment: Matched to TPS controller firmware versions; eliminates version mismatch risks that can cause diagnostic faults
- OEM Technical Support: Eligible for Honeywell lifecycle support, firmware updates, and field service agreements
- Warranty & Traceability: Sourced with full documentation trail; supports plant audit and insurance compliance requirements
Typical Applications
- Oil & Gas: Thermocouple temperature monitoring on distillation columns and heat exchangers in refinery DCS loops
- Petrochemical: RTD-based temperature acquisition for reactor vessel control in continuous process plants
- Power Generation: Low-level signal multiplexing for boiler and turbine temperature arrays in TPS-controlled power stations
- Pulp & Paper: Multi-point temperature profiling across drying sections using existing TPS infrastructure
- Pharmaceuticals: Validated temperature measurement in GMP-compliant batch processes requiring audit-ready I/O modules
- Chemical Processing: High-density analog input acquisition for exothermic reaction monitoring in PlantScape-controlled facilities
System Compatibility
The MC-TAMR03 is designed for use within the following Honeywell system components:
- TPS High-Performance Process Manager (HPM) — Primary controller; hosts MC-TAMR03 in I/O link chassis
- PlantScape Process Manager (PM) — Compatible controller platform for PlantScape R400+ environments
- MC-TAIH02 / MC-TAIH04 — High-level analog input modules; co-installed in same chassis for mixed signal architectures
- MC-PDIY22 / MC-PDOY22 — Digital I/O modules; share backplane in multi-function I/O assemblies
- TPS I/O Link Cable Assembly — Backplane interconnect; must match chassis generation
- Honeywell Universal Control Network (UCN) — Network backbone connecting HPM controllers to operator stations
Selection Guide
Use the following three questions to confirm the MC-TAMR03 is the right module for your application — or to identify the most appropriate replacement:
- What signal types are connected? — If your field devices output thermocouple (TC), RTD, or millivolt (mV) signals, the MC-TAMR03 is the correct low-level mux module. If signals are 4–20 mA or 1–5 V, a high-level analog input module (e.g., MC-TAIH02) may be more appropriate.
- Is your chassis a TPS or PlantScape backplane? — The MC-TAMR03 is slot-compatible only with TPS and PlantScape I/O chassis. If you are operating an Experion PKS or newer platform, a different I/O family is required.
- What is your controller firmware version? — Hardware revision mismatches between the MC-TAMR03 and the HPM/PM controller can trigger diagnostic faults. Confirm your firmware baseline before ordering a replacement revision.
Not sure which module fits your system? Contact Konmask at support@konmask.com with your chassis model, controller version, and signal list — we will confirm compatibility before you order.
Quality Assurance & Sourcing
Konmask sources the MC-TAMR03 through verified industrial supply channels, including authorized distributors, certified refurbishers, and controlled surplus inventories. Every unit undergoes a 4-step inspection process before shipment:
- Visual Inspection: PCB condition, connector integrity, label legibility, and absence of physical damage or corrosion
- Part Number Verification: Cross-check of OEM label, silkscreen markings, and firmware version against Honeywell documentation
- Functional Bench Test: Power-on test and channel response verification using compatible test equipment
- Documentation Package: Preparation of shipping manifest, test record, and available certification documents
Available documentation upon request: Certificate of Conformance (CoC), test report, OEM datasheet, and export compliance records.
How to Order
- Submit Your Inquiry: Email support@konmask.com or call +0086 19859288691 with your part number, required quantity, and delivery timeline
- Receive Confirmation: Konmask will confirm stock availability, pricing, lead time, and compatible alternatives within 24 hours
- Place Order & Ship: Confirm your order and receive tracking information with full documentation package included
Replacement & Compatibility FAQ
Q1: Can the MC-TAMR03 be used as a direct replacement for the 51309218-175?
Yes. MC-TAMR03 and 51309218-175 are the same module — the latter is the OEM part number used in Honeywell’s ordering system. They are interchangeable as a direct drop-in replacement with no configuration changes required, provided the hardware revision matches your controller firmware version.
Q2: Is the MC-TAIH02 a compatible equivalent to the MC-TAMR03?
Partially. The MC-TAIH02 is a high-level analog input module and is not a direct equivalent for low-level signal applications. It can serve as a functional substitute only if field signals are re-ranged to 4–20 mA or 1–5 V at the transmitter level. Signal wiring and I/O builder configuration must be updated accordingly.
Q3: Are there cross-brand substitutes compatible with the TPS backplane?
No third-party module is slot-compatible with the Honeywell TPS/PlantScape backplane. Cross-brand alternatives such as Emerson DeltaV or ABB S800 modules require a full platform migration and cannot be used as plug-in substitutes. For like-for-like replacement within the existing TPS system, only Honeywell OEM or certified equivalent modules should be used.
