Honeywell CC-TDOB01 / CC-TDIL01 – 16-Channel Digital Output Module | Experion PKS C300 Platform
Engineering Background
The Honeywell Experion PKS (Process Knowledge System) C300 Controller platform is one of the most widely deployed distributed control architectures in refining, petrochemical, power generation, and advanced manufacturing. The CC-TDOB01 and CC-TDIL01 are the certified I/O termination and link modules that form the digital output subsystem within this architecture, enabling deterministic, high-integrity discrete control at the field level.
Product Positioning
Designed for procurement engineers and automation integrators who require OEM-grade, specification-verified digital output modules for Experion PKS C300 systems. These modules are sourced through verified supply channels and are fully compatible with Honeywell’s CHARM-based and traditional I/O architectures. Konmask.com maintains stock of both CC-TDOB01 and CC-TDIL01 to support MRO, capital project, and emergency replacement requirements.
Complete Technical Specifications
| Parameter | CC-TDOB01 | CC-TDIL01 |
|---|---|---|
| Module Type | Digital Output Termination Board | Digital Output Link Module |
| Channel Count | 16 DO channels | 16 DO channels |
| Output Voltage | 24 VDC | 24 VDC |
| Output Current | 0.5 A per channel (max) | 0.5 A per channel (max) |
| Signal Type | Discrete (dry contact / sourcing) | Discrete (dry contact / sourcing) |
| Isolation | Optical isolation, channel-to-bus | Optical isolation, channel-to-bus |
| Operating Temperature | 0°C to +60°C | 0°C to +60°C |
| Humidity | 5% to 95% RH, non-condensing | 5% to 95% RH, non-condensing |
| Power Consumption | ≤ 3.5 W | ≤ 3.5 W |
| Backplane Interface | C300 I/O Link | C300 I/O Link |
| Mounting | DIN rail / C300 I/O chassis | DIN rail / C300 I/O chassis |
| Certifications | CE, UL, FM (Class I Div 2) | CE, UL, FM (Class I Div 2) |
| Weight | ~200 g | ~200 g |
| Part Number | CC-TDOB01 | CC-TDIL01 |
Proven Application Environments
- Oil & Gas Refining – Valve actuator control, pump start/stop, ESD interlock outputs
- Petrochemical Plants – Reactor sequencing, compressor control, safety shutdown systems
- Power Generation – Turbine auxiliary control, breaker control, load shedding logic
- Pulp & Paper / Chemicals – Conveyor control, agitator sequencing, batch process outputs
- Pharmaceutical Manufacturing – Clean-room equipment control, CIP/SIP valve actuation
- Water & Wastewater – Pump station control, dosing system outputs, alarm annunciation
Engineering Advantages
- Native C300 Compatibility – Plug-and-play integration with Honeywell Experion PKS C300 controller without additional configuration hardware
- Optical Isolation – Full channel-to-bus isolation eliminates ground loop interference in noisy industrial environments
- Hot-Swap Capable – Supports online module replacement without process shutdown (with appropriate system configuration)
- Diagnostic Transparency – Per-channel status reporting via Experion Station for rapid fault isolation
- Hazardous Area Rating – FM Class I Division 2 certification supports deployment in Zone 2 / Div 2 classified areas
- Compact Form Factor – High channel density reduces cabinet footprint and wiring complexity
System Architecture & Signal Flow
Within the Experion PKS C300 architecture, the CC-TDOB01 serves as the field-side termination board, providing screw-terminal or connector-based wiring points for field devices. The CC-TDIL01 functions as the I/O link interface module, bridging the C300 controller backplane to the termination board via the proprietary I/O Link bus. Together, they form a complete digital output subsystem:
C300 Controller → I/O Link Bus → CC-TDIL01 (Link Module) → CC-TDOB01 (Termination Board) → Field Devices (Solenoids, Relays, Actuators)
This two-module architecture allows field wiring to remain undisturbed during controller-side maintenance, reducing MTTR and improving system availability.
Sourcing & Quality Verification
- OEM Origin – All units sourced from Honeywell-authorized distribution or verified MRO channels
- Pre-shipment Inspection – Each module undergoes visual inspection, label verification, and functional continuity check before dispatch
- Traceability – Batch records and supplier documentation available upon request for regulated industries
- Packaging – Anti-static ESD packaging with moisture barrier; original OEM packaging preserved where available
- Warranty – 12-month warranty against manufacturing defects; DOA replacement within 7 business days
Procurement Process
- Inquiry – Submit your BOM or part number via email to [email protected] or WhatsApp +0086 19859288691
- Quote – Receive a formal quotation with lead time, unit price, and shipping options within 24 hours
- Order Confirmation – Purchase order accepted via email; proforma invoice issued for payment
- Quality Check – Pre-shipment inspection report provided upon request
- Shipping – DHL / FedEx / UPS express available; sea freight for bulk orders; export documentation included
- After-Sales – Technical support available for installation and commissioning queries
Technical FAQ
Q: Are CC-TDOB01 and CC-TDIL01 always used together?
A: Yes. In the standard C300 I/O architecture, the CC-TDIL01 link module and CC-TDOB01 termination board are paired. The link module handles backplane communication; the termination board provides field wiring connectivity.
Q: Can these modules be used with Honeywell CHARM I/O?
A: No. CC-TDOB01 and CC-TDIL01 are designed for the traditional C300 I/O Link architecture, not the CHARM (Configurable Hardware Agnostic Redundant Module) system. Verify your system architecture before ordering.
Q: What is the maximum cable length from CC-TDOB01 to field devices?
A: Honeywell recommends a maximum field wiring distance of 300 m (1000 ft) for 24 VDC discrete outputs, subject to cable gauge and load current. Consult the Experion PKS I/O Installation Guide for detailed wiring specifications.
Q: Is firmware upgrade required after replacement?
A: Typically no. The C300 system downloads configuration automatically upon module insertion. Confirm firmware compatibility with your site’s Experion PKS version before installation.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC and inspection reports are available upon request for orders destined for regulated industries (oil & gas, nuclear, pharmaceutical).
