Honeywell FC-TDOL-0724P FC-TERM-0002 FC-TERM-0001 Analog Input Module – Experion PKS Series
When a critical analog input module fails on the plant floor, the consequences are immediate and severe: process variables go blind, control loops open, and safety interlocks may trip — forcing costly unplanned shutdowns. In high-stakes environments such as oil & gas refineries, chemical plants, and power generation facilities, every minute of downtime translates directly into lost revenue and potential safety hazards. The Honeywell FC-TDOL-0724P, paired with termination assemblies FC-TERM-0002 and FC-TERM-0001, is the precision-engineered solution that keeps your process visibility intact and your control system running without interruption.
The FC-TDOL-0724P is a dedicated analog input module within Honeywell’s Experion PKS (Process Knowledge System) platform — one of the most widely deployed distributed control systems in the global process industry. Designed for the Series C I/O architecture, this module delivers high-density, high-accuracy analog signal acquisition with the reliability and redundancy features that mission-critical applications demand. Its companion termination assemblies, FC-TERM-0002 and FC-TERM-0001, provide the field-wiring interface that ensures clean, noise-immune signal transmission from field instruments to the controller.
Technical Specifications
- Part Numbers: FC-TDOL-0724P / FC-TERM-0002 / FC-TERM-0001
- Manufacturer: Honeywell Process Solutions
- Series: Experion PKS — Series C I/O
- Module Type: Analog Input Module
- Signal Types: 4–20 mA, 1–5 V (field-configurable per channel)
- Channel Count: 8 channels (FC-TDOL-0724P)
- Resolution: 16-bit A/D conversion
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication: FTE (Fault Tolerant Ethernet) backplane bus
- Power Supply: Supplied via I/O Link from controller cabinet
- Operating Temperature: 0°C to 60°C
- Certifications: CE, UL, FM (refer to Honeywell datasheet for full listing)
- Termination: FC-TERM-0002 (standard) / FC-TERM-0001 (redundant)
Key Features & Benefits
- High-Accuracy Signal Acquisition: 16-bit resolution ensures precise measurement of process variables such as flow, pressure, temperature, and level.
- Redundancy Support: FC-TERM-0001 enables redundant module configurations, eliminating single points of failure in safety-critical loops.
- Hot-Swap Capability: Modules can be replaced under power without disrupting the control system, minimizing maintenance downtime.
- HART Pass-Through: Supports HART protocol communication for advanced field device diagnostics and asset management.
- Comprehensive Diagnostics: Built-in self-diagnostics detect open-circuit, short-circuit, and out-of-range conditions, enabling predictive maintenance.
- Noise Immunity: Galvanic isolation and shielded termination assemblies suppress EMI/RFI interference common in industrial environments.
- Seamless Experion Integration: Native compatibility with Experion PKS R400 and above; plug-and-play configuration via Control Builder.
Industry & Equipment Applications
- Oil & Gas: Upstream wellhead monitoring, midstream pipeline control, downstream refinery process loops
- Petrochemical & Chemical: Reactor temperature/pressure monitoring, distillation column control
- Power Generation: Boiler drum level, turbine inlet pressure, generator output monitoring
- Pulp & Paper: Digester pressure control, bleach plant flow measurement
- Pharmaceuticals: Batch reactor monitoring, clean-room HVAC control
- Water & Wastewater: Pump station flow/pressure monitoring, treatment process control
System Integration & Compatible Parts
The FC-TDOL-0724P integrates directly into the Honeywell Experion PKS Series C I/O subsystem. Compatible and commonly paired components include:
- FC-TERM-0002 — Standard termination assembly for FC-TDOL-0724P
- FC-TERM-0001 — Redundant termination assembly
- FC-SDIL-0824 — Digital Input Module (same Series C chassis)
- FC-SDOL-0824 — Digital Output Module
- FC-TAIM-0002 — Analog Input Module (alternative channel count)
- CC-PAIX01 / CC-PAOX01 — C300 Controller I/O Link modules
- Experion PKS C300 Controller — Primary process controller
Our Quality Assurance Process
At Konmask.com, every Honeywell module undergoes a rigorous multi-stage inspection before shipment:
- Authenticity Verification: Part numbers, date codes, and firmware labels cross-checked against Honeywell’s official documentation.
- Visual Inspection: Connectors, PCB surfaces, and housing examined for damage, corrosion, or counterfeit indicators.
- Functional Testing: Where applicable, modules are bench-tested to confirm power-up and communication integrity.
- Secure Packaging: ESD-safe bags, foam inserts, and double-wall cartons protect modules during international transit.
- Documentation: Certificate of conformity and inspection report available upon request.
How to Order
- Submit your inquiry via the Contact Us form or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Receive a formal quotation within 24 business hours.
- Confirm order and arrange payment via T/T, L/C, or other agreed terms.
- Shipment dispatched with full tracking and export documentation.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation: Focused exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- ✅ Global Export Experience: Serving buyers in 50+ countries with compliant export documentation and reliable logistics partners.
- ✅ Competitive Lead Times: Extensive inventory network enables fast sourcing of both current and legacy Honeywell parts.
- ✅ Technical Support: Our team includes experienced automation engineers who can assist with compatibility and integration questions.
- ✅ Transparent Sourcing: We disclose product condition (new, surplus, refurbished) clearly on every quotation.
Frequently Asked Questions
- Q: Is the FC-TDOL-0724P compatible with Experion PKS R500 and later releases?
- A: The FC-TDOL-0724P is designed for the Series C I/O architecture. Compatibility with specific Experion PKS software releases should be confirmed against Honeywell’s release notes. Please contact us with your system version for a definitive answer.
- Q: What is the difference between FC-TERM-0001 and FC-TERM-0002?
- A: FC-TERM-0002 is the standard (simplex) termination assembly, while FC-TERM-0001 supports redundant module configurations. If your application requires module redundancy for high-availability loops, FC-TERM-0001 is required.
- Q: Do you supply new or surplus units?
- A: We supply both new (factory-sealed) and tested surplus units. Product condition is clearly stated in every quotation. All surplus units pass our quality inspection process before shipment.
- Q: Can you provide an export certificate or country of origin documentation?
- A: Yes. We provide a Certificate of Origin, commercial invoice, and packing list for all international shipments. Additional documentation (e.g., Form E for ASEAN, EUR.1 for EU) can be arranged upon request.
- Q: What is the minimum order quantity (MOQ)?
- A: There is no strict MOQ. We accommodate single-unit emergency orders as well as bulk procurement. Contact us for volume pricing.
