Combustion Control Configuration Solution – Honeywell GA-USB1-IR | ControLinks BW Series
Where This Product Is Used
The Honeywell GA-USB1-IR BW Connectivity Kit is the essential PC-to-burner interface used by combustion engineers, OEM panel builders, and field service technicians working with Honeywell’s ControLinks™ Burner Management and Fuel-Air Ratio Control systems. Typical deployment environments include:
- Industrial boiler rooms – commissioning and tuning RM7800 series flame safeguard controls
- Process heaters & furnaces – configuring fuel-air ratio curves on R7999 controllers
- Thermal oxidizers – diagnostics and fault-log retrieval via laptop on-site
- OEM burner skids – factory pre-configuration before shipment
- Utility & power generation – periodic maintenance audits and parameter archiving
Wherever a ControLinks BW-series device requires setup, the GA-USB1-IR is the mandated communication adapter.
Technical Specifications
| Part Number | GA-USB1-IR |
| Series | ControLinks™ BW Connectivity Kit |
| Manufacturer | Honeywell Process Solutions |
| Interface Type | USB (Type-A) to Infrared (IR) optical port |
| Compatible Devices | Honeywell ControLinks BW-series burner controls (R7999, RM7800L, RM7840, etc.) |
| Host Connection | USB 2.0 Full-Speed, backward compatible with USB 1.1 |
| Communication Protocol | Proprietary Honeywell IR optical protocol |
| Software Required | Honeywell ControLinks Configuration Tool (supplied or downloadable) |
| Operating System | Windows 7 / 10 / 11 (32-bit & 64-bit) |
| Cable Length | Approx. 1.5 m (4.9 ft) |
| Operating Temperature | 0 °C to +50 °C (32 °F to 122 °F) |
| Weight | 250 g (kit including adapter and cable) |
| Approvals | CE, RoHS compliant |
Why Engineers Specify This Model
- OEM-mandated interface – the GA-USB1-IR is the only Honeywell-approved adapter for BW-series optical configuration ports; third-party adapters are not supported.
- Plug-and-play driver – Windows HID-class driver installs automatically; no IT administrator rights required in most enterprise environments.
- Non-intrusive optical coupling – IR communication requires no physical wiring into the control circuit, eliminating risk of accidental parameter corruption during live commissioning.
- Full parameter access – read/write all fuel-air ratio curves, ignition timing, modulation ranges, and safety lockout thresholds from a laptop.
- Fault log download – retrieve timestamped lockout history for root-cause analysis and maintenance records.
- Compact field kit – lightweight dongle format fits in a technician’s tool bag alongside a laptop.
Complete System Bill of Materials
For a complete ControLinks configuration workstation, engineers typically source:
- Honeywell GA-USB1-IR BW Connectivity Kit (this item)
- Honeywell ControLinks Configuration Software (download from Honeywell Building Technologies portal)
- Windows laptop with USB-A port or USB-A hub adapter
- Compatible BW-series controller: R7999A, RM7800L, RM7840G, or equivalent
- Honeywell S7999D1024 Display Module (optional, for local HMI)
Compliance & Industry Standards
- CE Marking – complies with EU EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU
- RoHS – compliant with EU Directive 2011/65/EU (restriction of hazardous substances)
- NFPA 85 / NFPA 86 – supports commissioning of burner management systems designed to these standards
- EN 298 / EN 230 – compatible with ControLinks controllers certified to European burner safety standards
Quality Assurance & Sourcing
Konmask.com sources the GA-USB1-IR exclusively through authorized Honeywell distribution channels. Every unit is:
- Supplied in original Honeywell OEM packaging with full documentation
- Traceable to Honeywell’s manufacturing lot records
- Inspected for physical integrity and label authenticity before dispatch
- Covered by Honeywell’s standard product warranty
We do not supply grey-market, refurbished, or counterfeit components. All part numbers are cross-referenced against Honeywell’s current product catalog prior to shipment.
How to Source This Part
To place an order or request a formal quotation for the Honeywell GA-USB1-IR:
- Online: Add to cart directly on this page
- Email RFQ: support@konmask.com – include quantity, required delivery date, and project name
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead time: In-stock units ship within 1–3 business days; ex-stock orders confirmed at time of quotation
- Export: We support DDP, DAP, and EXW Incoterms for international buyers
Application-Specific FAQ
Q: Is the GA-USB1-IR compatible with all Honeywell ControLinks controllers?
A: It is designed for BW-series ControLinks devices. Confirm compatibility with your specific model number against Honeywell’s GA-USB1-IR product bulletin before ordering.
Q: Does the kit include the configuration software?
A: The kit includes the USB-IR hardware adapter. The ControLinks Configuration Tool software is available as a free download from the Honeywell Building Technologies support portal, or may be included on a CD depending on kit revision.
Q: Can I use this adapter with a USB-C laptop?
A: Yes, via a standard USB-A to USB-C adapter (not included). The adapter presents as a USB HID device and is not affected by the physical connector type.
Q: What if the driver does not install automatically?
A: Download the latest driver from the Honeywell support portal or contact Konmask technical support for assistance.
Q: Do you offer volume pricing for OEM panel builders?
A: Yes. Contact us at support@konmask.com with your annual volume estimate for a tiered pricing agreement.
