Honeywell HC-HISTV2-ESD Historical Data Logging Module | Replacement, Equivalent & Selection Guide
The Honeywell HC-HISTV2-ESD is a high-reliability Historical Data Logging Module designed for use within Honeywell’s TDC-3000 / TotalPlant Solution (TPS) Distributed Control System (DCS) architecture. It provides continuous, time-stamped process data acquisition and archiving, enabling operators and engineers to perform trend analysis, compliance reporting, and post-event diagnostics with precision.
At Konmask.com, we specialize in sourcing genuine and compatible industrial automation components — helping you find the right part, the right replacement, or the right equivalent for your control system needs.
Technical Specifications
| Parameter | Details |
|---|---|
| Part Number | HC-HISTV2-ESD |
| Manufacturer | Honeywell Process Solutions |
| Product Series | TDC-3000 / TPS (TotalPlant Solution) |
| Module Type | Historical Data Logging Module |
| Function | Process data acquisition, time-stamped archiving, trend logging |
| Communication Interface | Honeywell LCN (Local Control Network) |
| Power Supply | Per TDC-3000 cabinet specification |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Certifications | CE, UL (refer to Honeywell datasheet for full listing) |
| Form Factor | Card/Module — rack-mounted |
| Condition Available | New, Refurbished, Tested |
Compatible Replacement & Equivalent Models
If the HC-HISTV2-ESD is discontinued, out of stock, or cost-prohibitive, the following models may serve as functional replacements or equivalents depending on your system configuration. Always verify firmware and hardware compatibility before substitution.
| Model | Manufacturer | Compatibility Notes |
|---|---|---|
| HC-HISTV1-ESD | Honeywell | Earlier version; reduced logging capacity; verify LCN firmware |
| HC-HISTV3-ESD | Honeywell | Newer revision; enhanced throughput; backward-compatible in most TPS systems |
| 51304485-100 | Honeywell | Alternative historian card used in TPS environments |
| Custom HMI Historian (3rd party) | Various (OSIsoft PI, Aspentech) | Software-based historian; requires LCN gateway integration |
Contact our technical team at support@konmask.com to confirm cross-compatibility for your specific system revision.
Why Choose the Original HC-HISTV2-ESD
- Native LCN Integration: Designed specifically for Honeywell’s Local Control Network — no gateway or protocol conversion required.
- Proven Reliability: Field-tested in petrochemical, refining, and power generation environments over decades.
- Data Integrity: Hardware-level time-stamping ensures audit-trail accuracy for regulatory compliance (FDA 21 CFR Part 11, ISA-18.2).
- Seamless TPS Compatibility: Plug-and-play within existing TDC-3000 / TPS cabinets without system reconfiguration.
- Long Service Life: Engineered for continuous 24/7 industrial operation with minimal maintenance.
Typical Applications
- Oil & Gas refining and upstream production facilities
- Petrochemical and chemical processing plants
- Power generation (thermal, nuclear, combined-cycle)
- Pulp & paper and water treatment facilities
- Pharmaceutical manufacturing (batch process logging)
- Any site running Honeywell TDC-3000 or TPS DCS platforms
System Compatibility
| DCS Platform | Compatible | Notes |
|---|---|---|
| Honeywell TDC-3000 | ✅ Yes | Primary target platform |
| Honeywell TPS (TotalPlant Solution) | ✅ Yes | Full native support |
| Honeywell Experion PKS | ⚠️ Partial | Requires compatibility bridge; consult Honeywell engineering |
| Third-party DCS (ABB, Emerson, Siemens) | ❌ Not native | Software historian alternatives recommended |
Selection Guide
Use the following criteria to determine whether the HC-HISTV2-ESD is the right module for your application:
- Current DCS Platform: Confirm you are running TDC-3000 or TPS. If migrating to Experion PKS, evaluate Honeywell’s migration path tools.
- Data Volume Requirements: HC-HISTV2-ESD supports standard historian throughput. For high-density tag environments (>10,000 tags), consider HC-HISTV3-ESD or a software historian.
- Redundancy Needs: Determine if your system requires redundant historian modules for failover — pair with a secondary HC-HISTV2-ESD if required.
- Firmware Version: Verify your LCN firmware version is compatible. Contact us with your system revision for confirmation.
- Budget vs. Lifecycle: For systems approaching end-of-life, a software historian migration may offer better long-term ROI than hardware replacement.
Quality Assurance & Sourcing
- All modules sourced through verified industrial supply chains
- Pre-shipment functional testing available on request
- Refurbished units include 90-day warranty; new units carry manufacturer warranty
- Traceability documentation (COC, test reports) available for regulated industries
- Secure anti-static packaging (ESD-safe) for all shipments
How to Order
- Add HC-HISTV2-ESD to cart and proceed to checkout, or
- Email support@konmask.com with your quantity, required condition (new/refurbished), and delivery timeline
- For bulk orders or project procurement, request a formal quotation — we support NET payment terms for qualified buyers
- International shipping available; DDP/DAP Incoterms supported for most destinations
Replacement & Compatibility FAQ
Q: Can HC-HISTV1-ESD replace HC-HISTV2-ESD?
A: In most cases yes, but with reduced logging capacity. Verify your LCN firmware version supports the V1 module before substitution.
Q: Is HC-HISTV2-ESD compatible with Experion PKS?
A: Not natively. Experion PKS uses a different historian architecture. A compatibility bridge or software historian is recommended for Experion environments.
Q: Do you supply refurbished units?
A: Yes. All refurbished HC-HISTV2-ESD modules are tested to functional specification and include a 90-day warranty.
Q: What is the lead time for new units?
A: Typically 3–10 business days depending on stock availability. Contact us for real-time inventory status.
Q: Can I get a datasheet or test report?
A: Yes. Request documentation via support@konmask.com.
