Honeywell STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000 Gauge Pressure Transmitter | Replacement, Equivalent & Selection Guide
The Honeywell STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000 is a high-performance gauge pressure transmitter from Honeywell’s SmartLine STG700 Series. Engineered for demanding industrial process environments, it delivers exceptional accuracy, long-term stability, and seamless integration with HART and fieldbus communication protocols. This page provides full technical specifications, compatible replacement models, a selection guide, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Model: STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000
- Series: Honeywell SmartLine STG700
- Measurement Type: Gauge Pressure
- Pressure Range: Up to 400 inH₂O / 1 kPa–1 MPa (configurable per model code)
- Output Signal: 4–20 mA HART (2-wire)
- Communication Protocol: HART 7
- Accuracy: ±0.065% of span (reference conditions)
- Stability: ±0.1% URL per 5 years
- Process Connection: Per model code suffix (AHB = 1/2″ NPT female)
- Wetted Materials: 316L Stainless Steel diaphragm
- Housing: Aluminum alloy, dual-compartment
- Ingress Protection: IP66 / IP67 / NEMA 4X
- Ambient Temperature: –40°C to +85°C
- Process Temperature: –40°C to +121°C
- Power Supply: 10.5–42.4 VDC
- Approvals: ATEX, IECEx, FM, CSA (per configuration)
- Weight: Approx. 1.5 kg
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000. Always verify process conditions, output signal, and connection dimensions before substitution.
- Honeywell STG74L (alternate configurations) – Same series, different range or output options; drop-in replacement with reconfiguration
- Honeywell STG77L – Higher-range SmartLine gauge transmitter; suitable when elevated pressure range is required
- Emerson Rosemount 3051CG – Industry-standard HART gauge pressure transmitter; functionally equivalent, requires process connection adapter
- Yokogawa EJA430E – High-accuracy gauge pressure transmitter with HART/BRAIN protocol; compatible in most 4–20 mA loops
- ABB 266GSH – Gauge pressure transmitter with HART; similar accuracy class and process compatibility
- Endress+Hauser Cerabar M PMC51 – Ceramic/metallic sensor gauge transmitter; suitable for corrosive media applications
- Siemens SITRANS P320 – HART-compatible gauge transmitter; equivalent performance tier
Note: Konmask.com recommends consulting the original datasheet and process requirements before finalizing any replacement selection.
Why Choose the Original Model
- Proven SmartLine Platform: The STG700 series is a globally deployed, field-proven platform with millions of installed units across refining, chemical, and power industries.
- Superior Long-Term Stability: ±0.1% URL over 5 years reduces recalibration frequency and lifecycle costs.
- Advanced HART 7 Diagnostics: Built-in self-diagnostics and remote configuration minimize unplanned downtime.
- Broad Approvals Portfolio: ATEX, IECEx, FM, and CSA certifications support global hazardous-area installations.
- Seamless DCS Integration: Native compatibility with Honeywell Experion PKS and third-party DCS/SCADA systems via HART.
Typical Applications
- Oil & gas upstream/midstream/downstream pressure monitoring
- Chemical and petrochemical process control
- Power generation (boiler, steam, and turbine pressure measurement)
- Pharmaceutical and food & beverage hygienic processes
- Water and wastewater treatment facilities
- Pulp and paper manufacturing
- HVAC and building automation systems
System Compatibility
- DCS: Honeywell Experion PKS, Emerson DeltaV, ABB System 800xA, Yokogawa CENTUM VP, Siemens PCS 7
- SCADA: Compatible with all major SCADA platforms via HART multiplexer or HART-IP gateway
- Asset Management: Honeywell Field Device Manager (FDM), Emerson AMS Device Manager, PACTware with DTM
- Communication: HART 7 (primary); optional FOUNDATION Fieldbus or Profibus PA per model variant
Selection Guide
Use the STG74L model code structure to configure the correct transmitter for your application:
- STG74L – SmartLine Gauge Pressure Transmitter, Low-side range
- E1 – Output: 4–20 mA HART
- G000 – Range code (consult Honeywell datasheet for exact range)
- 1 – Wetted material: 316L SS diaphragm
- A – Fill fluid: Silicone oil
- AHB – Process connection: 1/2″ NPT female, SS
- 11S – Housing: Aluminum, dual-compartment, conduit entry
- A – Electrical connection: 1/2″ NPT conduit
- 00A0-00-0000 – Standard options (no special options)
For custom ranges, hazardous-area certifications, or special materials, contact support@konmask.com for a tailored configuration.
Quality Assurance & Sourcing
- All units sourced through authorized distribution channels or verified surplus with full traceability documentation.
- Each unit undergoes incoming inspection including visual check, label verification, and functional test where applicable.
- Calibration certificates and factory test reports available upon request.
- Counterfeit-prevention policy: Konmask.com only supplies units with verifiable manufacturer markings and documentation.
- Lead time: In-stock units ship within 3–5 business days; special orders 4–8 weeks depending on manufacturer availability.
How to Order
- Online: Add to cart directly on this page and complete checkout.
- Email: Send your PO or inquiry to support@konmask.com with model number, quantity, and required delivery date.
- Phone/WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Bulk / OEM orders: Contact us for volume pricing and blanket order arrangements.
- Please provide your full model number (STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000) when ordering to ensure exact configuration match.
Replacement & Compatibility FAQ
Q: Can the Emerson Rosemount 3051CG directly replace the STG74L?
A: Functionally yes — both are 4–20 mA HART gauge transmitters with similar accuracy. However, process connection dimensions and mounting may differ. Verify flange/thread compatibility before installation.
Q: Is the STG74L compatible with non-Honeywell DCS systems?
A: Yes. The HART 7 output is universally compatible with any DCS or SCADA system that supports HART communication, including Emerson DeltaV, ABB, Yokogawa, and Siemens platforms.
Q: What is the difference between STG74L and STG77L?
A: The STG74L covers lower pressure ranges, while the STG77L is designed for higher-range gauge pressure measurement. Both share the same SmartLine platform and communication architecture.
Q: Can I reconfigure the range after installation?
A: Yes. The STG74L supports remote range configuration via HART communicator or asset management software without removing the transmitter from the process.
Q: Do you supply calibration certificates?
A: Yes. Factory calibration certificates and test reports are available upon request at time of order.
