Horner HE670RLY168C Relay Output PC Board – OCS Series
When a relay output board fails mid-production, the consequences are immediate: conveyor lines halt, assembly robots freeze, and every minute of downtime translates directly into lost revenue and missed delivery commitments. The Horner HE670RLY168C is the relay output PC board that keeps your OCS-based control system running — providing 16 discrete relay output channels with the rugged reliability that industrial environments demand. Without it, your entire OCS controller becomes an expensive paperweight.
The HE670RLY168C occupies a critical position within Horner APG’s OCS (Operator Control Station) Series — an integrated platform that combines PLC logic, HMI display, and I/O in a single compact unit. As the relay output expansion board for the HE670 platform, this module bridges the controller’s logic to real-world actuators, solenoids, motor starters, and indicator lights. Horner APG’s OCS Series is deployed across thousands of industrial installations worldwide, from North American food processing plants to European packaging lines, making genuine replacement parts like the HE670RLY168C essential for maintenance teams globally.
Technical Specifications
- Part Number: HE670RLY168C
- Manufacturer: Horner APG (Horner Electric)
- Series: OCS (Operator Control Station) HE670 Series
- Module Type: Relay Output PC Board
- Output Channels: 16 discrete relay outputs
- Output Type: Relay (dry contact)
- Contact Rating: Typically 2A @ 30VDC / 0.5A @ 125VAC (per relay contact — verify with OEM datasheet)
- Form Factor: Internal PC board for HE670 OCS unit
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Weight: Approx. 980 g (as shipped)
- Compatibility: Horner HE670 OCS platform
Note: Always verify specifications against the official Horner APG HE670RLY168C datasheet before installation. Konmask.com does not modify or alter OEM specifications.
Key Features & Benefits
- 16-Channel Relay Output: Provides ample discrete output capacity for complex machine control sequences without requiring additional expansion hardware.
- Dry Contact Relay Design: Electrically isolates the controller logic from field-side loads, protecting sensitive PLC circuitry from voltage spikes and inductive kickback.
- OCS-Integrated Architecture: Designed as an internal board for the HE670 platform — no external wiring harnesses or adapter brackets required for installation.
- Industrial-Grade Construction: Built to withstand the vibration, temperature cycling, and electrical noise typical of factory floor environments.
- Direct Drop-In Replacement: Genuine OEM board ensures full firmware and hardware compatibility with existing HE670 OCS units — no reconfiguration needed.
- Broad Load Compatibility: Relay contacts can switch AC or DC loads, making this board suitable for a wide range of actuator and indicator types.
Industry & Equipment Applications
- Food & Beverage Processing: Conveyor control, valve actuation, pump sequencing, and CIP (clean-in-place) system control.
- Packaging Machinery: Labeling machine outputs, case sealer control, reject gate actuation.
- HVAC & Building Automation: Fan starter control, damper actuator outputs, alarm relay switching.
- Water & Wastewater Treatment: Pump motor starters, valve control, level alarm outputs.
- Material Handling: Conveyor routing, sortation gate control, indicator stack light outputs.
- OEM Machine Builders: Any custom machine built on the Horner HE670 OCS platform requiring relay output capability.
System Integration & Compatible Parts
The HE670RLY168C is designed for use within the Horner APG HE670 OCS Series. Compatible and related components include:
- Horner HE670 OCS base units (various display and I/O configurations)
- Horner HE670 analog input/output boards
- Horner HE670 DC input boards
- Horner CSCAPE programming software (for logic configuration)
- Horner SmartStack I/O expansion modules (for systems requiring additional I/O beyond the base unit)
If you are unsure whether the HE670RLY168C is the correct board for your specific HE670 variant, please contact our technical team with your full OCS model number and we will confirm compatibility before shipment.
Our Quality Assurance Process
At Konmask.com, every industrial automation component goes through a structured sourcing and verification process before it reaches you:
- Authorized & Verified Supply Chain: We source from authorized distributors and verified industrial surplus channels — no grey-market or counterfeit parts.
- Visual & Functional Inspection: Each board is inspected for physical damage, component integrity, and correct part number labeling prior to dispatch.
- Secure Anti-Static Packaging: All PC boards are shipped in ESD-safe packaging with appropriate cushioning to prevent transit damage.
- Traceability: We maintain sourcing records for every unit, providing full traceability upon request for regulated industries.
- Warranty Support: Contact us for warranty terms applicable to your order — we stand behind every part we ship.
How to Order
- Submit an Inquiry: Use the contact form on this page or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and shipping options tailored to your location.
- Confirm & Pay: We accept T/T (bank transfer), PayPal, and other B2B payment methods. Proforma invoice provided upon request.
- Shipment & Tracking: Parts are dispatched via DHL, FedEx, or UPS with full tracking. Express options available for urgent requirements.
- After-Sales Support: Our technical team remains available post-delivery for installation guidance and compatibility questions.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on industrial control components — PLC modules, DCS parts, HMI boards, and drives. This is our domain.
- Global B2B Shipping: We ship to over 80 countries with experience navigating customs documentation for industrial electronics.
- Hard-to-Find Parts: Discontinued or long-lead-time components are our specialty. If it’s in the Horner catalog, we can source it.
- Technical Pre-Sales Support: Not sure if this is the right part? Our engineers will review your application before you commit to a purchase.
- Competitive Pricing: Direct sourcing relationships allow us to offer competitive pricing without compromising on authenticity.
Frequently Asked Questions
Q: Is the HE670RLY168C a genuine Horner APG part?
A: Yes. Konmask.com sources only genuine OEM components. We do not sell aftermarket or cloned boards.
Q: Can I install this board myself, or do I need a Horner technician?
A: The HE670RLY168C is an internal PC board replacement. Installation requires opening the OCS enclosure and handling ESD-sensitive components. We recommend a qualified automation technician perform the swap. Contact us for installation guidance documentation.
Q: What is the lead time if the part is not in stock?
A: Lead times vary by sourcing channel. Typical lead time for sourced units is 3–10 business days. Express sourcing is available for critical downtime situations — contact us immediately and we will prioritize your order.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. We can provide available Horner APG technical documentation upon request. Contact support@konmask.com with your inquiry.
Q: Can you supply multiple units for a maintenance spare parts program?
A: Absolutely. We support bulk orders and ongoing spare parts programs for maintenance departments and OEM machine builders. Request a volume quote via email.
