Industrial Automation Solution – IEI TANK-801-BTI-J1/2G/3B-R11 | TANK-800 Series
The IEI TANK-801-BTI-J1/2G/3B-R11 is a rugged, fanless embedded computer engineered for demanding industrial environments. Built on the Intel® Atom™ E3845 quad-core processor, it delivers reliable, low-power computing for automation, machine vision, kiosk, and edge-intelligence applications where silent, continuous operation is non-negotiable.
Where This Product Is Used
- Factory Automation & PLC Gateway: Acts as an intelligent edge node connecting legacy PLCs (Siemens, Mitsubishi, Allen-Bradley) to SCADA/MES systems via serial and Ethernet ports.
- HMI & Operator Workstation: Drives touchscreen panels in production lines, packaging machines, and CNC control cabinets — fanless design eliminates dust ingress risk.
- Machine Vision & Quality Inspection: Processes camera feeds for defect detection on assembly lines; dual GbE ports support isolated vision and plant networks.
- Digital Signage & Self-Service Kiosk: Powers 24/7 unattended kiosks in retail, transportation, and hospitality with silent, compact form factor.
- Building Automation & Energy Management: Deployed as a BACnet/Modbus gateway for HVAC, lighting, and power monitoring systems.
- Transportation & In-Vehicle Computing: Wide-temperature tolerance and vibration resistance suit railway, bus, and logistics vehicle installations.
Technical Specifications
- SKU / Part Number: TANK-801-BTI-J1/2G/3B-R11
- Processor: Intel® Atom™ E3845 Quad-Core, 1.91 GHz (Bay Trail-I)
- Memory: 2 GB DDR3L SO-DIMM (expandable to 8 GB)
- Storage: 32 GB mSATA SSD
- OS Support: Windows 10 IoT Enterprise, WES7, Linux
- Display: VGA + HDMI (dual independent)
- Networking: 2× Intel® GbE LAN (RJ-45)
- Serial Ports: 4× RS-232/422/485 (software-selectable)
- USB: 4× USB 3.0 + 2× USB 2.0
- Expansion: 1× Mini PCIe (full-size) + SIM slot
- Power Input: 9–36V DC wide-range
- Operating Temperature: -20°C to 60°C
- Dimensions: 210 × 148 × 55 mm
- Weight: 560 g
- Certifications: CE, FCC Class A, RoHS
Why Engineers Specify This Model
- Zero-Fan Reliability: No moving parts — MTBF exceeds 100,000 hours for 24/7 production environments.
- Wide DC Input (9–36V): Compatible with 12V and 24V industrial power rails without converters.
- Rich Serial I/O: Four RS-232/422/485 ports natively support Modbus RTU, PROFIBUS adapters, and legacy devices.
- Compact DIN-Rail / Panel-Mount Ready: Fits inside standard control cabinets without dedicated rack space.
- Dual GbE Network Isolation: Separates OT and IT networks on a single device — key for IEC 62443 segmentation.
- Long Product Lifecycle: IEI industrial-grade components guarantee 5+ year availability.
Complete System Bill of Materials
- IEI TANK-801-BTI-J1/2G/3B-R11 — Fanless Embedded Computer (this unit)
- IEI 32G-MSATA-SLC — Industrial mSATA SSD (optional upgrade)
- IEI CBL-RS232-100 — RS-232 cable set
- IEI PWR-DC-12V-60W — 12V/60W DIN-rail power supply
- Compatible HMI Panel (7–21 inch, VGA/HDMI)
- Managed GbE Switch (for dual-network topology)
- DIN-rail mounting kit (sold separately)
Compliance & Industry Standards
- CE Mark (EMC Directive 2014/30/EU)
- FCC Part 15 Class A
- RoHS 2 Compliant (2011/65/EU)
- IEC 60068-2 Vibration & Shock Tested
- Suitable for IEC 62443 OT/IT network segmentation architectures
Quality Assurance & Sourcing
Konmask.com sources IEI products exclusively through authorized distribution channels. Every unit undergoes incoming inspection including power-on testing, port verification, and firmware version confirmation before dispatch. Original manufacturer packaging, warranty documentation, and CE/FCC declarations of conformity are included with each shipment.
How to Source This Part
Stock availability is updated in real time. For volume orders (5+ units), OEM configurations, or lead-time inquiries, contact our industrial sales team:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Response Time: Within 1 business day (Mon–Fri, UTC+8)
- Request a formal quotation with HS code documentation for customs clearance support.
Application-Specific FAQ
Q: Can the TANK-801-BTI-J1/2G/3B-R11 run as a Modbus TCP/RTU gateway?
A: Yes. With dual GbE and four RS-232/422/485 ports, it is widely deployed as a Modbus gateway using Kepware KEPServerEX or open-source solutions like OpenPLC Runtime.
Q: Is this unit suitable for outdoor or harsh-environment enclosures?
A: The unit is rated -20°C to 60°C. For outdoor deployment, pair it with an IP65/IP67-rated enclosure. The fanless design eliminates the need for ventilation cutouts.
Q: What is the maximum RAM?
A: Up to 8 GB DDR3L via a single SO-DIMM slot. This SKU ships with 2 GB installed.
Q: Can I add a 4G/LTE modem?
A: Yes. The full-size Mini PCIe slot plus onboard SIM slot supports industrial 4G LTE modules (e.g., Sierra Wireless, Quectel EC25).
Q: What warranty is provided?
A: IEI provides a standard 2-year manufacturer warranty. Konmask.com offers pre-shipment testing and post-sale technical support.
