Siemens IPC627D 6BK1000-6AA00-0XX0 Industrial PC | Replacement, Equivalent & Selection Guide
The Siemens SIMATIC IPC627D (6BK1000-6AA00-0XX0) is a high-performance rack-mount industrial PC designed for demanding automation and process control environments. As an authorized sourcing partner, Konmask.com supplies genuine units, certified refurbished equivalents, and compatible replacement models to keep your systems running without interruption.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Siemens AG |
| Series | SIMATIC IPC627D |
| Order Number (MLFB) | 6BK1000-6AA00-0XX0 |
| Form Factor | 19″ Rack-Mount (4U) |
| Processor | Intel Core i7 / i5 (6th Gen, Skylake) |
| Memory | Up to 32 GB DDR4 ECC RAM |
| Storage | SSD / HDD (configurable) |
| Operating System | Windows 10 IoT Enterprise / Windows 7 (configurable) |
| Display Output | DVI-I, DisplayPort |
| Interfaces | USB 3.0, USB 2.0, RS-232, RJ45 (2× GbE), PCIe expansion slots |
| Power Supply | 24 V DC / 100–240 V AC (configurable) |
| Operating Temperature | 5 °C to 45 °C |
| Protection Class | IP20 (front panel) |
| Certifications | CE, UL, cUL, FCC Class A |
| Dimensions (W×H×D) | Approx. 482 × 177 × 400 mm |
| Weight | Approx. 12 kg |
Compatible Replacement & Equivalent Models
When the 6BK1000-6AA00-0XX0 is unavailable or end-of-life, the following models offer functional equivalence or direct drop-in replacement capability:
| Model | Series | Key Difference | Compatibility |
|---|---|---|---|
| 6BK1000-6AA10-0XX0 | IPC627D | Updated firmware revision | Direct replacement |
| 6BK1000-6AB00-0XX0 | IPC627D | Extended temperature range | Drop-in with config check |
| 6AG4010-5CA10-0XX0 | IPC627E | Next-gen platform (7th Gen CPU) | Functional equivalent |
| 6AG4010-5DA10-0XX0 | IPC627E | Higher RAM capacity | Functional equivalent |
| 6BK1000-6AA00-0AA0 | IPC627D | Different OS pre-load | Direct replacement |
Note: Always verify BIOS version, driver compatibility, and software licensing before substituting units in a live system.
Why Choose the Original Model
- Proven reliability in 24/7 industrial environments with validated MTBF data
- Siemens SIMATIC ecosystem integration — native compatibility with TIA Portal, WinCC, and STEP 7
- Long-term spare parts availability through Siemens Industry Online Support
- Certified EMC performance for noise-sensitive process environments
- Standardized rack footprint simplifies cabinet design and maintenance
Typical Applications
- SCADA and HMI server platforms in process industries (oil & gas, chemical, water treatment)
- MES / MOM gateway computing in automotive and discrete manufacturing
- Vision system host PCs in quality inspection lines
- Data historian and OPC-UA server nodes in IIoT architectures
- Redundant control room computing in power generation and utilities
System Compatibility
- Siemens Software: TIA Portal V13–V19, WinCC V7.x / Unified, STEP 7 V5.x, PCS 7
- Communication Protocols: PROFINET, PROFIBUS (via CP card), OPC-UA, Modbus TCP
- Expansion: PCIe ×16 / ×4 / ×1 slots for CP cards, GPU, or additional I/O
- Networking: Dual GbE for separated automation and office network segments
Selection Guide
Use the criteria below to confirm the 6BK1000-6AA00-0XX0 is the right choice — or to identify the best alternative:
| Requirement | Recommended Model |
|---|---|
| Standard rack environment, Windows 10 IoT, i7 CPU | 6BK1000-6AA00-0XX0 ✓ |
| Need next-gen CPU (7th Gen+) or Windows 11 | IPC627E (6AG4010-5CA10-0XX0) |
| Extended temp range (0–55 °C) | 6BK1000-6AB00-0XX0 |
| Budget-sensitive, refurbished acceptable | Certified refurb 6BK1000-6AA00-0XX0 (contact us) |
| Panel-mount form factor required | SIMATIC IPC477E / IPC577E series |
Quality Assurance & Sourcing
- Genuine units sourced from authorized Siemens distribution channels
- Certified refurbished options available — fully tested, reset to factory spec
- Each unit undergoes functional burn-in testing before shipment
- Traceable serial numbers and authenticity documentation provided
- Export compliance verified — EAR / ECCN classification available on request
How to Order
- Add the 6BK1000-6AA00-0XX0 to your cart and proceed to checkout, or
- Contact us for volume pricing, lead time confirmation, or custom configuration:
📧 support@konmask.com
📞 +0086 19859288691 - Provide your project specs if you need a selection recommendation — our engineers will respond within 1 business day.
Replacement & Compatibility FAQ
Q: Is the 6BK1000-6AA00-0XX0 still in production?
A: This model may be at end-of-life or limited availability. Contact us to confirm current stock and lead times, or to discuss a supported successor model.
Q: Can I replace it with an IPC627E without software changes?
A: In most cases yes, but driver updates and a TIA Portal hardware reconfiguration step are required. We can provide a migration checklist.
Q: Do you supply only new units?
A: We supply both new and certified refurbished units. All refurbished units are fully tested and include a warranty.
Q: What warranty is included?
A: New units carry the standard Siemens warranty. Refurbished units include a Konmask 12-month warranty. Contact us for details.
Q: Can you ship internationally?
A: Yes. We ship worldwide with full export documentation. Lead times vary by destination — contact us for a shipping quote.
