JDS UNIPHASE 2214-30SLQTC He-Ne Laser Module 632.8nm | Replacement, Equivalent & Selection Guide
The JDS UNIPHASE 2214-30SLQTC is a compact, single-mode helium-neon (He-Ne) laser module operating at 632.8 nm, designed for precision measurement, interferometry, alignment, and OEM instrumentation applications. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams source the right laser module with confidence.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 2214-30SLQTC |
| Brand | JDS Uniphase (JDSU) |
| Series | 2214 |
| Laser Type | Helium-Neon (He-Ne) |
| Wavelength | 632.8 nm (Red) |
| Output Power | ~0.5 mW (typical, verify datasheet) |
| Mode | Single-Mode (TEM₀₀) |
| Polarization | Linear, >500:1 |
| Beam Diameter | ~0.7 mm (1/e²) |
| Beam Divergence | <1.2 mrad (full angle) |
| Operating Voltage | ~1,200–1,500 V (ballast required) |
| Warm-Up Time | <5 minutes to rated power |
| Operating Temperature | 10°C – 40°C |
| Weight | ~3,700 g (with power supply) |
| Connector / Interface | Standard He-Ne tube interface |
| Compliance | Class IIIa / Class 3R Laser Product |
Note: Always verify specifications against the official JDSU/Viavi datasheet before final design-in. Contact us if you need the original datasheet.
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents for the JDS UNIPHASE 2214-30SLQTC. Compatibility depends on your specific application requirements — consult the selection guide below before substituting.
| Manufacturer | Model | Wavelength | Power | Notes |
|---|---|---|---|---|
| JDS Uniphase | 2214-30SLQTC (OEM) | 632.8 nm | ~0.5 mW | Original model — direct match |
| JDS Uniphase | 1107P | 632.8 nm | 0.5 mW | Compact replacement, same series family |
| Melles Griot | 05-LHP-151 | 632.8 nm | 0.5 mW | Industry-standard equivalent, widely available |
| Melles Griot | 05-LHP-171 | 632.8 nm | 1.0 mW | Higher power alternative |
| Thorlabs | HNL050L | 632.8 nm | 0.5 mW | Drop-in equivalent for most bench setups |
| Coherent | 31-2082-000 | 632.8 nm | 0.5 mW | OEM-grade equivalent |
| REO / II-VI | LHRP-0501 | 632.8 nm | 0.5 mW | Long-life replacement option |
⚠ Disclaimer: Replacement compatibility must be verified by the end-user engineer. Konmask.com provides sourcing assistance only and does not guarantee interchangeability without application validation.
Why Choose the Original Model
- Proven OEM Pedigree: The 2214-30SLQTC is a JDSU factory-calibrated module used in precision OEM instruments worldwide.
- Guaranteed Wavelength Stability: Factory-tested at 632.8 nm with tight tolerances — critical for interferometry and metrology.
- Single-Mode Beam Quality: TEM₀₀ output ensures minimal divergence and maximum coherence length for demanding optical setups.
- Long Service Life: He-Ne tubes from JDSU are rated for >20,000 hours MTBF under normal operating conditions.
- Traceable Documentation: Original units come with factory test data and compliance certificates.
Typical Applications
- Laser interferometry and displacement measurement
- Optical alignment and beam steering systems
- Holography and coherent imaging
- Barcode scanning and pattern recognition (legacy OEM)
- Spectroscopy reference beam
- Educational and laboratory instrumentation
- Semiconductor wafer inspection systems
System Compatibility
The 2214-30SLQTC is compatible with standard He-Ne laser power supplies providing 1,200–1,500 V starting voltage and regulated ballast current. Verified compatible power supply families include:
- JDSU / Viavi OEM power supply modules (2200 series)
- Melles Griot 05-LPM series power supplies
- Thorlabs LPS-HV-15 and equivalent regulated HV supplies
- Custom OEM ballast circuits designed to IEC 60825-1 requirements
Ensure your enclosure and interlock circuits comply with Class IIIa / 3R laser safety requirements before installation.
Selection Guide
Use the following criteria to determine whether the 2214-30SLQTC is the right module for your application, or to select an appropriate replacement:
| Requirement | Recommended Choice |
|---|---|
| Exact OEM replacement (same form factor) | JDS UNIPHASE 2214-30SLQTC (original) |
| Budget replacement, same power class | Melles Griot 05-LHP-151 or Thorlabs HNL050L |
| Higher output power needed (>0.5 mW) | Melles Griot 05-LHP-171 (1.0 mW) |
| Extended lifetime priority | REO / II-VI LHRP-0501 |
| Compact form factor required | JDSU 1107P |
| Immediate stock availability | Contact Konmask.com — we source globally |
Quality Assurance & Sourcing
At Konmask.com, all laser modules and industrial components are sourced through verified supply channels. Our quality process includes:
- ✅ Visual and functional inspection upon receipt
- ✅ Cross-reference against manufacturer part numbers and date codes
- ✅ Anti-counterfeit verification for critical optical components
- ✅ Secure ESD-safe packaging for all laser modules
- ✅ Documentation provided: test reports, certificates of conformance on request
We specialize in sourcing obsolete, long-lead, and hard-to-find industrial laser modules for MRO, OEM, and system integrator customers globally.
How to Order
- Confirm your required quantity and delivery timeline.
- Add to cart directly, or contact us for bulk pricing and lead time.
- For custom sourcing or equivalent substitution advice, email support@konmask.com.
- We accept T/T bank transfer, PayPal, and major credit cards.
- Global shipping available — DHL, FedEx, UPS with full tracking.
Replacement & Compatibility FAQ
Q: Can I replace the 2214-30SLQTC with a Melles Griot 05-LHP-151?
A: In most bench and laboratory setups, yes — both are 632.8 nm, 0.5 mW, single-mode He-Ne modules. Verify mechanical mounting and power supply compatibility before substitution.
Q: Is the 2214-30SLQTC still in production?
A: JDSU (now Viavi Solutions) has discontinued many legacy He-Ne laser lines. Konmask.com sources new-old-stock (NOS) and refurbished units. Contact us for current availability.
Q: What power supply does the 2214-30SLQTC require?
A: A regulated He-Ne power supply providing ~1,200–1,500 V starting voltage and ~3.5–5 mA ballast current. Do not operate without a proper ballast — this will damage the tube.
Q: Do you provide a warranty?
A: Yes. We offer a 90-day functional warranty on all units shipped. Extended warranty and service contracts available on request.
Q: Can you source multiple units for a production run?
A: Yes. Contact us with your BOM quantity and schedule. We can consolidate sourcing across multiple equivalent models if needed.
