Motion Control Solution — KOLLMORGEN S3030-1-NA-SB | SERVOSTAR 343 | CS-220L
Where This Product Is Used
The KOLLMORGEN S3030-1-NA-SB (SERVOSTAR 343, also referenced as CS-220L, P/N 34048 / 6567453) is a compact, high-performance digital servo drive engineered for precision motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers — Axis feed drives for milling, turning, and grinding machines requiring tight velocity and position loop performance.
- Industrial Robotics — Joint actuator control in articulated and SCARA robots where smooth torque delivery and fast dynamic response are critical.
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and labeling lines demanding synchronised multi-axis coordination.
- Semiconductor & Electronics Assembly — Wafer handling, PCB drilling, and SMT placement equipment requiring sub-micron repeatability.
- Medical & Laboratory Automation — Diagnostic imaging gantries, liquid-handling robots, and surgical positioning systems.
- Printing & Converting — Web-tension control and register correction on offset, flexo, and digital presses.
- Material Handling & Conveyors — Servo-driven sortation, palletising, and AGV drive systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | KOLLMORGEN |
| Series | SERVOSTAR 300 (Model 343) |
| Part Number | S3030-1-NA-SB |
| Cross-Reference P/N | CS-220L | 34048 | 6567453 |
| Continuous Output Current | 3 A |
| Peak Output Current | 9 A (3× continuous, typical) |
| AC Supply Voltage | 230 VAC, single- or three-phase |
| DC Bus Voltage | ~325 VDC |
| Feedback Supported | Resolver, Encoder (incremental/absolute), Hall-effect |
| Communication Interface | RS-232 / RS-485; optional CANopen / PROFIBUS |
| Control Modes | Torque, Velocity, Position |
| Protection Class | IP20 |
| Operating Temperature | 0 °C to +45 °C (ambient) |
| Weight (unit) | 2.6 kg |
| Approvals | CE, UL |
Why Engineers Specify This Model
- Proven SERVOSTAR 300 Platform — Field-validated across millions of installed axes globally; extensive OEM and end-user support ecosystem.
- Compact 3 A Frame — Optimised for small-to-medium servo motors (typically 50 W – 750 W), minimising panel footprint without sacrificing performance.
- Multi-Feedback Compatibility — Native resolver and encoder support eliminates the need for external interface cards in mixed-motor fleets.
- Flexible Communication — RS-232/485 standard; CANopen and PROFIBUS options enable seamless integration into existing PLC/DCS architectures.
- Auto-Tuning & BODE Analysis — Integrated commissioning tools reduce start-up time and optimise loop gains without external instruments.
- Regenerative Braking Ready — Internal regen resistor connection simplifies energy management in high-duty-cycle applications.
Complete System Bill of Materials
For a fully operational servo axis based on the S3030-1-NA-SB, engineers typically specify:
- KOLLMORGEN AKM or Goldline servo motor (matched to 3 A drive rating)
- Feedback cable assembly (resolver or encoder, shielded, drag-chain rated)
- Power cable assembly (motor phase + brake, UL/CE rated)
- 24 VDC control power supply (min. 2 A)
- Line filter / EMC filter (per CE Directive requirements)
- External regenerative resistor (application-dependent)
- SERVOSTAR commissioning software (DRIVEGUI.EXE, free download)
- RS-232 PC interface cable or USB-to-serial adapter
Compliance & Industry Standards
- CE Marking — Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- UL Listed — UL 508C (Power Conversion Equipment)
- RoHS Compliant — Directive 2011/65/EU
- IEC 61800-5-1 — Adjustable speed electrical power drive systems — Safety requirements
- IEC 61800-3 — EMC requirements for drive systems
Quality Assurance & Sourcing
Every unit offered by Konmask.com undergoes a structured inspection protocol before dispatch:
- Visual inspection: housing integrity, connector condition, label legibility
- Functional power-on test: DC bus charge, status LED verification
- Firmware version check and documentation
- Anti-static packaging with humidity indicator card
- Traceable lot documentation retained for 5 years
Units are sourced from authorised distributors, certified surplus channels, and decommissioned OEM lines. Counterfeit-risk screening is applied to all inbound stock.
How to Source This Part
- Add to Cart — Click Add to Cart above; checkout supports T/T wire transfer, PayPal, and major credit cards.
- Request a Quote — For volume orders (>3 units) or urgent requirements, email [email protected] for a dedicated quotation within 4 business hours.
- Lead Time — In-stock units ship within 1–2 business days (DHL Express / FedEx IP). Ex-stock lead time for out-of-stock: 5–15 business days depending on sourcing channel.
- Export Compliance — This product may be subject to export control regulations (EAR/ECCN). Buyers are responsible for compliance with applicable import/export laws.
Application-Specific FAQ
Q: Is the S3030-1-NA-SB compatible with KOLLMORGEN AKM servo motors?
A: Yes. The SERVOSTAR 343 is fully compatible with the AKM series when the motor’s continuous current rating is ≤3 A. Use DRIVEGUI to auto-configure motor parameters via the built-in motor database.
Q: Can this drive operate on single-phase 230 VAC?
A: Yes, single-phase 230 VAC input is supported, though continuous output power will be derated. Consult the SERVOSTAR 300 hardware manual (Section 3) for derating curves.
Q: What is the difference between S3030-1-NA-SB and CS-220L / 34048 / 6567453?
A: These are cross-reference part numbers used by different OEMs and distributors for the same SERVOSTAR 343 drive assembly. The S3030-1-NA-SB is the KOLLMORGEN catalogue number; CS-220L, 34048, and 6567453 are OEM/distributor aliases.
Q: Is a warranty provided?
A: Konmask.com offers a 90-day functional warranty on all tested surplus units. New/sealed units carry the original manufacturer warranty where applicable.
Q: Do you provide technical support for commissioning?
A: Basic commissioning guidance is available via email. For on-site support, we can refer you to certified KOLLMORGEN service partners in your region.
