KUKA 00-107-264 KCP2 Teach Pendant Controller | Replacement, Equivalent & Selection Guide
The KUKA 00-107-264 (also referenced as KCP2, cross-reference: 00-226-429) is the original teach pendant controller designed for KUKA KR C2 robot systems. At Konmask.com, we specialize in sourcing, verifying, and supplying genuine and compatible industrial automation components — helping engineers make confident selection decisions.
Technical Specifications
- Part Number: 00-107-264
- Cross Reference: 00-226-429
- Series: KCP2 (KUKA Control Panel 2)
- Compatible Controller: KUKA KR C2
- Interface: Proprietary KUKA pendant bus
- Display: Color LCD touchscreen
- Emergency Stop: Integrated hardware E-stop
- Enabling Device: 3-position enabling switch
- Cable Length: Standard 10 m (custom lengths available)
- Weight: Approx. 500 g
- Operating Temperature: 0 °C to +50 °C
- Protection Rating: IP54
- Manufacturer: KUKA Roboter GmbH
Compatible Replacement & Equivalent Models
The following models are confirmed compatible or functionally equivalent to the KUKA 00-107-264 KCP2 pendant. Always verify firmware version and cable connector type before substitution:
- KUKA 00-226-429 — Direct cross-reference / alternate part number for the same unit
- KUKA KCP2 (generic label) — OEM-labeled variant shipped with KR C2 systems
- KUKA 00-109-022 — Earlier revision; compatible with KR C2 but check firmware ≥ V5.x
- KUKA smartPAD — Next-generation pendant for KR C4; not directly compatible without controller upgrade
Note: Third-party aftermarket pendants may be electrically compatible but are not recommended for safety-critical applications without full validation.
Why Choose the Original Model
- ✅ Full KUKA firmware compatibility — no driver conflicts
- ✅ Certified E-stop and enabling device per ISO 10218-1
- ✅ Seamless integration with KUKA WorkVisual and OfficeLite
- ✅ Genuine KUKA warranty and traceability documentation
- ✅ Proven reliability in 24/7 production environments
Typical Applications
- Automotive body welding and assembly lines (KR 6, KR 16, KR 30 series robots)
- Material handling and palletizing cells
- Machine tending and CNC integration
- Spot and arc welding automation
- Replacement for damaged or end-of-life KCP2 pendants in existing KR C2 installations
System Compatibility
| Robot Controller | Compatible | Notes |
|---|---|---|
| KUKA KR C2 | ✅ Yes | Primary platform |
| KUKA KR C2 ed05 | ✅ Yes | Verify cable connector |
| KUKA KR C1 | ⚠️ Partial | Adapter may be required |
| KUKA KR C4 | ❌ No | Requires smartPAD |
| KUKA KR C5 | ❌ No | Requires smartPAD Pro |
Selection Guide
Use this guide to confirm the correct pendant for your application:
- Step 1 — Identify your controller: Check the controller cabinet label for model (KR C2 / KR C2 ed05).
- Step 2 — Check firmware version: Navigate to Help > Info on the existing pendant. Firmware V5.x or later is required for full KCP2 feature support.
- Step 3 — Verify cable connector: KCP2 uses a proprietary 15-pin D-sub connector. Confirm your cabinet port matches.
- Step 4 — Confirm part number: Both 00-107-264 and 00-226-429 are valid order numbers for the same unit.
- Step 5 — Contact us if unsure: Send your robot nameplate photo to support@konmask.com for free pre-purchase verification.
Quality Assurance & Sourcing
- All units sourced from authorized KUKA distributors or verified surplus channels
- Pre-shipment functional test: display, E-stop, enabling switch, and communication bus
- Serialized traceability records available on request
- Packaging: anti-static bag + foam-lined carton
- Lead time: in-stock units ship within 1–3 business days; sourced units 5–15 business days
How to Order
- Click Add to Cart or Contact Us for bulk/project pricing.
- Provide your robot serial number and controller firmware version for compatibility confirmation.
- We accept T/T bank transfer, PayPal, and major credit cards.
- Export documentation (CO, packing list, commercial invoice) available for international orders.
Replacement & Compatibility FAQ
Q: Can I use 00-226-429 instead of 00-107-264?
A: Yes. These are alternate part numbers for the same KCP2 pendant unit.
Q: Will this pendant work with KR C4 controllers?
A: No. KR C4 requires the KUKA smartPAD (part no. 00-168-334). Contact us for smartPAD availability.
Q: Is a used/refurbished unit available?
A: Yes. We offer tested refurbished units at reduced cost. Specify “refurbished” in your inquiry.
Q: Do you provide a warranty?
A: All units carry a 90-day functional warranty. Extended warranty available on request.
Q: Can you supply the cable separately?
A: Yes. KCP2 replacement cables (10 m standard) are available as a separate line item.
