Robot Safety System Solution – KUKA 00-117-344 KSD1-4800-117-344 | KSD1 Series
Where This Product Is Used
The KUKA Safety Board 00-117-344 (KSD1-4800-117-344 / 6FC5403-0AA10-0AA0 / 00-138-379) is a critical safety control module deployed across high-demand industrial automation environments. Typical application sites include:
- Automotive Body-in-White (BIW) Lines — Integrated into KUKA KR C4 robot controllers managing spot-welding and press-tending cells where SIL 2 / PLd safety monitoring is mandatory.
- Collaborative Robot Safety Zones — Enforces safe-speed, safe-stop (SS1/SS2), and safe-torque-off (STO) functions in human-robot collaboration (HRC) workcells.
- Palletizing & Material Handling — Monitors axis positions and velocity limits in high-throughput logistics and end-of-line packaging systems.
- Foundry & Heavy Press Automation — Provides redundant safety monitoring in harsh environments with high vibration and thermal cycling.
- Aerospace Component Machining — Used in precision multi-axis robot cells requiring certified functional safety per ISO 10218-1.
- Electronics Assembly & Semiconductor Fabs — Deployed in cleanroom-compatible KUKA robot systems requiring low-EMI safety signaling.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | KUKA Robotics |
| Part Number (Primary) | 00-117-344 |
| Cross-Reference SKUs | KSD1-4800-117-344 | 6FC5403-0AA10-0AA0 | 00-138-379 |
| Module Type | Safety Board (KSD1 Series) |
| Compatible Controller | KUKA KR C4, KR C4 compact, KR C4 smallsize |
| Safety Functions | STO, SS1, SS2, SLS, SLP, SOS (IEC 62061 / ISO 13849-1) |
| Safety Integrity Level | SIL 2 / Performance Level d (PLd) |
| Communication Interface | EtherCAT (internal backplane) |
| Operating Voltage | 24 V DC (via KR C4 power supply) |
| Operating Temperature | 0 °C to +55 °C |
| Weight | 600 g (approx.) |
| Form Factor | PCB module, plug-in card |
| Firmware | Compatible with KUKA System Software (KSS) 8.x |
Why Engineers Specify This Model
- Certified Functional Safety — Factory-validated to SIL 2 / PLd, eliminating the need for third-party safety re-certification after replacement.
- Drop-in Compatibility — Direct OEM replacement for KR C4 platforms; no firmware re-flashing or hardware modification required in most configurations.
- Multi-SKU Cross-Reference — Sourced under four interchangeable part numbers (00-117-344, KSD1-4800-117-344, 6FC5403-0AA10-0AA0, 00-138-379), simplifying procurement across global MRO databases.
- Minimizes Downtime — A failed safety board triggers an immediate E-Stop lockout. Having a verified spare on-hand reduces unplanned downtime from days to minutes.
- Broad Robot Compatibility — Supports the full KR C4 family including KR AGILUS, KR CYBERTECH, KR QUANTEC, and KR FORTEC series robots.
Complete System Bill of Materials
For a fully operational KUKA KR C4 safety system, engineers typically source the following alongside this Safety Board:
- KUKA KR C4 Cabinet Controller (00-168-334 or equivalent)
- KUKA Power Supply Unit (KPS 600 / 00-130-293)
- KUKA Servo Drive Module (KSD 48-06 / 00-117-340)
- KUKA SmartPAD Teach Pendant (00-168-353)
- KUKA RDC (Resolver Digital Converter) Board (00-130-629)
- EtherCAT Safety I/O Module (compatible third-party or KUKA OEM)
- 24 V DC DIN Rail Power Supply (Siemens SITOP or equivalent)
Contact [email protected] for bundle pricing on complete KR C4 spare-parts kits.
Compliance & Industry Standards
- IEC 62061 — Functional Safety of Machinery
- ISO 13849-1 — Safety-Related Parts of Control Systems (PLd)
- ISO 10218-1 — Robots and Robotic Devices: Safety Requirements for Industrial Robots
- IEC 61800-5-2 — Adjustable Speed Electrical Power Drive Systems (STO/SS1/SS2)
- CE Marked (original OEM certification)
- RoHS Compliant
Quality Assurance & Sourcing
Every unit shipped by Konmask.com undergoes the following quality process:
- Visual Inspection — PCB, connectors, and component integrity checked against OEM reference standards.
- Functional Bench Test — Power-on verification and communication handshake test with KR C4 controller emulator where applicable.
- Anti-Static Packaging — Shipped in ESD-safe bags with foam cushioning and moisture barrier.
- Traceability — Each unit is logged with serial number, inspection date, and technician ID for full audit trail.
- Sourcing Transparency — Units sourced from decommissioned OEM systems, authorized distributors, or certified refurbishers. Condition clearly stated at time of order confirmation.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly.
- Request a Quote — Email [email protected] with your required quantity, delivery timeline, and destination country for a formal quotation.
- Verify Compatibility — Share your KR C4 cabinet serial number or KSS software version and our engineers will confirm fitment before shipment.
- Global Shipping — We ship worldwide via DHL Express, FedEx International, and UPS. Export documentation (commercial invoice, packing list, HS code 8537.10) provided for customs clearance.
- Lead Time — In-stock units ship within 1–3 business days. Contact us for urgent same-day dispatch options.
Application-Specific FAQ
Q: Is this Safety Board compatible with KUKA KR C4 compact controllers?
A: Yes. The KSD1 Safety Board (00-117-344) is compatible with the full KR C4 family including the standard, compact, and smallsize variants, provided the KSS version is 8.2 or higher.
Q: Can I replace this board without re-certifying the robot cell?
A: In most jurisdictions, replacing a like-for-like OEM safety board does not require full re-certification, but a functional safety validation test (proof test) is recommended per IEC 62061 §7.4. Consult your local safety integrator.
Q: What error codes indicate a failed Safety Board?
A: Common KUKA fault codes associated with KSD1 failure include KSS 00500, KSS 00501, KSS 01280, and safety-channel mismatch errors. A persistent E-Stop with no external trigger is a primary symptom.
Q: Do you offer a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available — contact us for details.
Q: What is the difference between part numbers 00-117-344 and 00-138-379?
A: These are cross-reference numbers used across different KUKA documentation revisions and regional catalogs. They refer to the same physical KSD1 Safety Board assembly. The 6FC5403-0AA10-0AA0 number is the Siemens OEM cross-reference used in some KUKA-Siemens co-branded documentation.
