LAM RESEARCH 810-028296-174 Transport Arm 80157E PCB Assembly | Replacement, Equivalent & Selection Guide
The LAM RESEARCH 810-028296-174 is a Transport Arm 80157E Printed Circuit Board Assembly used in Lam Research semiconductor wafer processing equipment. This PCB controls the motion and positioning of the wafer transport arm, ensuring precise, contamination-free wafer handling in etch and deposition systems. Konmask.com supplies both original and verified-equivalent units to minimize downtime and reduce procurement costs.
Technical Specifications
- Part Number: 810-028296-174
- Assembly Name: Transport Arm 80157E PCB Assembly
- Manufacturer: LAM RESEARCH Corporation
- Form Factor: PCB Assembly (PCBA)
- Weight: ~800 g
- Condition: New / Refurbished / Tested-Good (specify at inquiry)
- Cross-Reference P/N: 853-049542-174 | 810-028296-171 | 853-049542-172
- Application: Wafer transport arm motion control in Lam Research etch/CVD platforms
Compatible Replacement & Equivalent Models
The following part numbers are confirmed cross-references or functional equivalents for the 810-028296-174. Always verify revision compatibility with your system before installation.
- 853-049542-174 — Direct OEM cross-reference (same functional assembly, alternate P/N)
- 810-028296-171 — Earlier revision; compatible in most configurations
- 853-049542-172 — Alternate suffix variant; verify PCB revision before substitution
Not sure which part fits your system? Contact our engineers at support@konmask.com with your system model and current P/N.
Why Choose the Original Model (810-028296-174)
- ✅ Guaranteed OEM specification compliance for Lam Research platforms
- ✅ Revision -174 incorporates latest engineering change orders (ECOs)
- ✅ Plug-and-play replacement — no firmware or calibration changes required
- ✅ Reduces risk of wafer loss or process drift caused by incompatible substitutes
- ✅ Traceable serial number and lot documentation available on request
Typical Applications
- Lam Research Versys, Kiyo, Flex, and 2300 series etch systems
- CVD and ALD deposition platforms using robotic wafer transport
- Semiconductor fab maintenance, spare parts inventory, and emergency replacement
- OEM equipment refurbishment and system upgrades
System Compatibility
This PCB assembly is designed for integration into Lam Research wafer handling subsystems. Compatibility depends on the host system’s transport arm controller firmware and mechanical interface. Confirmed compatible platforms include Lam Research 2300 series and Versys Metal systems. For other platforms, provide your system model number for engineering verification.
Selection Guide
Use the table below to select the correct part for your application:
- Need latest revision with full OEM support? → Order 810-028296-174
- Budget-conscious replacement with same function? → Consider 853-049542-174 (verify revision)
- Legacy system on older firmware? → Evaluate 810-028296-171 for backward compatibility
- Unsure? → Submit your system BOM to support@konmask.com for a free compatibility check
Quality Assurance & Sourcing
- All units are inspected and tested prior to shipment
- Sourced from authorized distributors, certified refurbishers, or direct OEM channels
- Anti-static packaging and ESD-safe handling throughout the supply chain
- Certificate of Conformance (CoC) and test reports available upon request
- 12-month warranty on new units; 90-day warranty on refurbished units
How to Order
- Add to cart directly, or contact us for bulk/urgent orders
- Specify required condition: New, Refurbished, or Tested-Good
- Provide your system model and current installed P/N for compatibility confirmation
- Request a formal quotation: support@konmask.com | +0086 19859288691
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
Replacement & Compatibility FAQ
Q: Can 853-049542-174 directly replace 810-028296-174?
A: In most cases yes — both are OEM cross-references for the same Transport Arm 80157E PCB Assembly. Confirm the PCB revision suffix matches your system’s requirements.
Q: Is 810-028296-171 backward compatible with -174 systems?
A: The -171 is an earlier revision. It is functionally compatible in most systems but may lack the latest ECO updates. Recommended for legacy systems only.
Q: Do you supply tested/refurbished units?
A: Yes. All refurbished units undergo full functional testing and are supplied with a 90-day warranty and test report.
Q: What is the lead time for out-of-stock units?
A: Typically 5–15 business days depending on sourcing. Contact us for urgent requirements.
Q: Can I return a part if it doesn’t fit?
A: Yes, within 30 days of receipt for unused units in original packaging. See our Returns Policy for details.
