LinMot E4000-MT – High-Precision Servo Drive for Linear Motors | MT Series Platform
Engineering Background
LinMot (Linear Motion Technology) is a Swiss engineering company specializing in direct-drive linear motor systems. Founded on the principle of eliminating mechanical transmission losses, LinMot’s servo drives are engineered for applications where precision, repeatability, and dynamic response are non-negotiable. The E4000-MT represents the current-generation drive platform optimized for the MT (Multi-Turn) series of linear motors, delivering closed-loop force and position control with sub-millimeter accuracy.
Product Positioning
The E4000-MT is designed for OEM machine builders and system integrators who require a compact, fieldbus-ready servo drive capable of controlling LinMot MT-series linear motors in demanding industrial environments. It bridges the gap between high-performance motion control and practical integration into existing PLC/DCS architectures via standard industrial protocols.
Complete Technical Specifications
| Part Number / SKU | E4000-MT |
| Manufacturer | LinMot (Switzerland) |
| Series / Platform | E4000 / MT Series |
| Device Type | Servo Drive / Linear Motor Controller |
| Compatible Motors | LinMot MT-Series Linear Motors |
| Control Mode | Position, Velocity, Force (closed-loop) |
| Fieldbus Interfaces | CANopen, EtherCAT (model-dependent) |
| Supply Voltage | 24–48 VDC (nominal) |
| Output Current | Refer to LinMot E4000-MT datasheet for peak/continuous ratings |
| Encoder Feedback | Integrated linear encoder via motor cable |
| Protection Class | IP20 (panel-mount) |
| Operating Temperature | 0 °C to +40 °C |
| Storage Temperature | -25 °C to +70 °C |
| Weight | 1,500 g (approx.) |
| Country of Origin | Switzerland |
| Certifications | CE, RoHS |
Proven Application Environments
- Packaging Machinery – High-speed pick-and-place, sealing, and cutting axes requiring precise stroke control
- Semiconductor & Electronics Assembly – Sub-millimeter positioning for die bonding, dispensing, and inspection stages
- Medical Device Manufacturing – Cleanroom-compatible linear actuation with force-controlled insertion and dosing
- Automotive Test Rigs – Dynamic load simulation and end-of-line functional testing
- Robotics & Collaborative Systems – Integrated linear axes in gantry and SCARA configurations
- Food & Beverage Processing – Hygienic-design linear motion with washdown-compatible motor pairing
Engineering Advantages
- Direct-Drive Architecture – Eliminates backlash, wear, and maintenance associated with ball screws or belt drives
- Closed-Loop Force Control – Real-time current-to-force mapping enables compliant assembly and press-fit operations
- Compact Drive Footprint – DIN-rail mountable form factor minimizes control cabinet space
- Plug-and-Play Motor Recognition – Auto-identification of connected LinMot MT motor parameters on power-up
- Multi-Protocol Fieldbus – Native CANopen and EtherCAT support simplifies integration with Beckhoff, Siemens, Omron, and Rockwell PLCs
- LinMot Talk Software – Free PC-based commissioning, oscilloscope, and diagnostics tool included
System Architecture & Signal Flow
The E4000-MT operates as a single-axis servo drive within a distributed motion control architecture. The host PLC or motion controller sends position/velocity setpoints via CANopen (DS402 profile) or EtherCAT (CoE). The drive’s internal DSP executes the current control loop at high bandwidth, commanding the MT-series linear motor’s primary coil. Integrated encoder feedback from the motor’s secondary (slider) is processed in real time, closing the position loop with typical resolutions in the micrometer range. I/O signals (enable, fault, home sensor) interface via the drive’s digital I/O connector, while analog inputs support external force or position references.
Sourcing & Quality Verification
- All LinMot E4000-MT units sourced by Konmask.com are procured through verified industrial supply channels
- Each unit undergoes incoming inspection: label verification, firmware version check, and connector integrity test
- Original manufacturer packaging and documentation preserved where available
- Traceability records maintained for B2B procurement compliance
- Surplus and refurbished units clearly identified with condition grading (New / Tested / Refurbished)
Procurement Process
- Confirm Part Number – Verify E4000-MT against your LinMot motor series and fieldbus requirement
- Request Quote – Contact support@konmask.com with quantity, delivery timeline, and destination
- Order Confirmation – Pro-forma invoice issued; payment via T/T, PayPal, or trade terms for qualified accounts
- Shipping – DHL / FedEx express worldwide; EXW Xiamen or CIF available; typical lead time 3–7 business days
- After-Sales – Technical support for commissioning queries; warranty claims handled directly
Technical FAQ
Q: Is the E4000-MT compatible with all LinMot linear motors?
A: The E4000-MT is specifically optimized for the MT (Multi-Turn) series. Compatibility with P01 or other series requires verification against LinMot’s drive-motor compatibility matrix.
Q: Which PLC brands are supported?
A: Via CANopen DS402 or EtherCAT CoE, the E4000-MT integrates with Beckhoff TwinCAT, Siemens S7 (with gateway), Omron Sysmac, Rockwell Studio 5000, and other standard fieldbus masters.
Q: Can the drive operate in standalone mode without a PLC?
A: Yes. The E4000-MT supports pre-programmed motion profiles stored in non-volatile memory, triggerable via digital I/O for simple point-to-point applications without a fieldbus master.
Q: What commissioning software is required?
A: LinMot Talk (free download from linmot.com) is the standard tool for parameter configuration, motion profile setup, and real-time diagnostics.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com and reference SKU E4000-MT to receive the full technical datasheet and wiring documentation.
