Industrial Motion Control Solution — LTI MOTION LSC-070-2-50-560-P5B0R1PM0 | LSC Series AC Servo Motor
Where This Product Is Used
The LTI MOTION LSC-070-2-50-560-P5B0R1PM0 is an AC brushless servo motor from the LSC Series, engineered for high-dynamic, precision motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers — Axis feed drives requiring high torque density and low cogging for surface finish accuracy
- Industrial Robotics — Joint actuators in 6-axis articulated arms and SCARA robots where compact frame size and high peak torque are critical
- Automated Assembly Lines — Pick-and-place gantries, conveyor indexing, and press-fit stations demanding repeatable positioning
- Packaging Machinery — High-speed cam-profile motion on form-fill-seal and cartoning equipment
- Printing & Converting Equipment — Register control and tension management on web-fed presses
- Semiconductor & Electronics Manufacturing — Wafer handling, PCB drilling, and SMT placement requiring micron-level repeatability
- Injection Molding Machines — Clamp and injection axis servo retrofit applications
Technical Specifications
| Part Number | LSC-070-2-50-560-P5B0R1PM0 |
| Brand | LTI MOTION |
| Series | LSC Series |
| Motor Type | AC Brushless Servo Motor |
| Frame Size | 070 (70 mm flange) |
| Pole Pairs | 2 |
| Rated Torque | 50 Nm |
| Rated Voltage | 560 V AC |
| Feedback / Encoder | P5B0R1PM0 (High-resolution absolute encoder) |
| Protection Class | IP65 (shaft end IP54) |
| Insulation Class | Class F (155 °C) |
| Weight | 5.3 kg |
| Mounting | IEC B5 flange |
| Cooling | Natural convection (IC410) |
Why Engineers Specify This Model
- High Torque-to-Inertia Ratio — The LSC-070 frame delivers 50 Nm in a compact 70 mm housing, enabling fast acceleration without oversized mechanical structure
- 560 V Bus Compatibility — Direct compatibility with standard European 400 V AC three-phase supplies via matched LTI MOTION servo drives, eliminating step-down transformer costs
- Absolute Encoder (P5B0R1PM0) — Single-turn or multi-turn absolute feedback eliminates homing cycles on machine restart, reducing downtime and improving safety
- Low Cogging Torque — Skewed stator design minimizes velocity ripple, critical for surface-quality-sensitive machining and printing applications
- Robust IP65 Sealing — Suitable for coolant-splash environments in machine tool installations without additional enclosure
- Drop-in LSC Series Ecosystem — Fully compatible with LTI MOTION ECODRIVE and POSIDRIVE servo amplifier families for simplified commissioning
Complete System Bill of Materials
For a fully operational servo axis using this motor, engineers typically specify the following complementary components:
- Servo Drive / Amplifier — LTI MOTION POSIDRIVE FDS / MDS series matched to 560 V bus and motor current rating
- Feedback Cable — LTI MOTION pre-assembled encoder cable (shielded, drag-chain rated) for P5B0R1PM0 connector
- Power Cable — Servo-rated motor power cable, 4-core shielded, rated ≥ 600 V, drag-chain flex grade
- Holding Brake Option — Specify brake suffix variant if vertical axis or gravity-load retention is required
- Gearbox — Planetary inline or right-angle gearhead (e.g., Neugart, Apex) for torque multiplication or speed reduction
- Shaft Coupling — Zero-backlash bellows or disc coupling for direct-drive connection to load
- Line Filter / EMC Filter — Mains-side EMC filter per EN 61800-3 Category C2 for CE compliance
Compliance & Industry Standards
- CE Marked — Machinery Directive 2006/42/EC & Low Voltage Directive 2014/35/EU
- EMC Directive 2014/30/EU — EN 61800-3 compliance
- IEC 60034 — Rotating electrical machines standard
- IEC 60529 — IP65 ingress protection rating
- RoHS 2 Compliant — Directive 2011/65/EU
- UL Recognition available upon request for North American installations
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for B2B buyers globally. Every unit of the LSC-070-2-50-560-P5B0R1PM0 offered through our platform is:
- Sourced from authorized distributors or verified OEM supply channels
- Inspected for original packaging integrity, label authenticity, and date code traceability
- Supported by documentation including datasheet, CE declaration, and test records upon request
- Backed by our 12-month warranty against manufacturing defects
- Available for expedited global shipping with DDP (Delivered Duty Paid) options for EU, US, and Southeast Asia
How to Source This Part
- Confirm your application requirements — Verify bus voltage (560 V), torque (50 Nm), frame size (070), and encoder type (P5B0R1PM0) match your drive system
- Request a quote — Contact us via email or WhatsApp with your required quantity and delivery timeline
- Receive datasheet & lead time confirmation — We provide full technical documentation and stock status within 24 hours
- Place order & arrange shipping — Flexible payment terms for verified B2B buyers; DHL / FedEx / sea freight available
- Incoming inspection support — We can provide test reports and traceability documents to support your goods-in QC process
Application-Specific FAQ
Q: Is the LSC-070-2-50-560-P5B0R1PM0 compatible with third-party servo drives?
A: The motor uses a standard IEC B5 flange and three-phase power connection. However, the P5B0R1PM0 encoder protocol is proprietary to LTI MOTION. Third-party drives require an encoder emulation module or gateway. We recommend pairing with LTI MOTION POSIDRIVE or ECODRIVE amplifiers for native plug-and-play commissioning.
Q: Can this motor be used in vertical axis applications?
A: Yes, but a holding brake variant should be specified to prevent load drop on E-stop or power loss. Contact us to confirm the brake-equipped part number within the LSC-070 family.
Q: What is the typical lead time for this part?
A: Stock availability varies. In-stock units ship within 3–5 business days. For non-stock orders, typical lead time is 4–8 weeks from LTI MOTION. Contact us for current availability.
Q: Do you supply the matching servo drive and cables as a complete kit?
A: Yes. Konmask.com can source and supply the complete servo axis kit including drive, cables, and accessories. Please provide your application details for a bundled quotation.
Q: Is this motor suitable for ATEX / hazardous area installations?
A: The standard LSC-070-2-50-560-P5B0R1PM0 is not ATEX rated. For hazardous area requirements, please contact us for alternative LTI MOTION variants or third-party equivalents.
