LTI MOTION LSC-070-3-30-560-P5B0H2MM0 – High-Torque AC Servo Motor | LSC Series Platform
Engineering Background: LTI MOTION (formerly known as Lust Antriebstechnik) is a German precision drive technology manufacturer with decades of expertise in servo systems for demanding industrial environments. The LSC series represents their flagship line of synchronous AC servo motors, engineered for high dynamic response, compact frame design, and seamless integration with modern motion controllers.
Product Positioning: The LSC-070-3-30-560-P5B0H2MM0 is a frame-size 070 synchronous servo motor rated for 560 V DC bus voltage, delivering 3 Nm continuous torque with a 30 A peak current capability. It is purpose-built for procurement engineers specifying precision axis drives in CNC machining, robotics, packaging automation, and semiconductor handling equipment where positional accuracy and thermal stability are non-negotiable.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | LTI MOTION (Germany) |
| Part Number / SKU | LSC-070-3-30-560-P5B0H2MM0 |
| Series | LSC (Linear Synchronous Compact) |
| Frame Size | 070 mm |
| Motor Type | Synchronous AC Servo Motor (Permanent Magnet) |
| Continuous Torque | 3 Nm |
| Peak Current | 30 A |
| DC Bus Voltage | 560 V |
| Encoder Interface | P5 (Hiperface / EnDat compatible – confirm with datasheet) |
| Shaft Configuration | B0 (smooth shaft, no keyway) |
| Flange / Mounting | H2 (standard IEC flange) |
| Feedback Type | Multi-turn absolute encoder (P5 option) |
| Protection Class | IP65 (shaft seal standard) |
| Insulation Class | F (155°C) |
| Country of Origin | Germany |
| Weight (approx.) | 5.3 kg |
Proven Application Environments
- CNC Machine Tools – Feed axis and spindle positioning requiring sub-micron repeatability
- Industrial Robotics – Joint actuators in 6-axis articulated arms and SCARA robots
- Packaging Machinery – High-speed pick-and-place and form-fill-seal lines
- Semiconductor & Electronics Assembly – Wafer handling, PCB drilling, and SMT placement
- Printing & Converting – Register control and tension management on web-fed lines
- Medical & Laboratory Automation – Precision dispensing and sample handling systems
Engineering Advantages
- High Power Density: Compact 070 frame delivers 3 Nm continuous in a minimal footprint, reducing machine envelope.
- Absolute Multi-Turn Encoder (P5): Eliminates homing cycles on power-up, critical for safety-critical and 24/7 production lines.
- 560 V DC Bus Compatibility: Optimized for standard European 400 VAC three-phase servo drives, minimizing derating and cable losses.
- IP65 Sealing: Suitable for wash-down and coolant-splash environments without additional enclosure.
- Low Cogging Torque: LSC series skewed stator design ensures smooth velocity control at low speeds.
- Wide Drive Compatibility: Natively supported by LTI MOTION ECODRIVE and compatible with Siemens SINAMICS, Bosch Rexroth IndraDrive, and Beckhoff AX5000 via parameter adaptation.
System Architecture & Signal Flow
The LSC-070-3-30-560-P5B0H2MM0 integrates into a closed-loop servo architecture as follows:
- Motion Controller (PLC / CNC) → EtherCAT / PROFINET position command
- Servo Drive (LTI ECODRIVE or compatible) → 560 V DC bus, current regulation loop
- Motor Power Cables → U/V/W three-phase + PE, shielded, max 50 m
- LSC-070-3-30-560-P5B0H2MM0 → Torque generation, absolute position feedback via P5 encoder
- Encoder Feedback Cable → Hiperface/EnDat signal back to drive, closing position loop
Brake option (MM0 = no brake in this configuration) should be confirmed against the application’s vertical axis safety requirements.
Sourcing & Quality Verification
- ✅ Authorized Distribution Channel: All units sourced through verified LTI MOTION distribution networks.
- ✅ Traceability: Each unit ships with manufacturer serial number and production batch documentation.
- ✅ Inspection: Pre-shipment electrical continuity, insulation resistance (IR), and encoder communication verification.
- ✅ Packaging: Original OEM packaging with anti-static protection and humidity indicator cards.
- ✅ Warranty: 12-month warranty against manufacturing defects from invoice date.
Procurement Process
- Submit RFQ – Contact support@konmask.com with quantity, required delivery date, and destination port.
- Quotation & Lead Time Confirmation – Response within 24 business hours with firm pricing and ETA.
- Purchase Order – Issue PO against confirmed quotation; T/T, L/C, and PayPal accepted.
- Inspection & Dispatch – Pre-shipment inspection report provided; DHL / FedEx / sea freight options available.
- After-Sales Support – Technical commissioning assistance and warranty claim processing via dedicated engineer team.
Technical FAQ
Q: Is the LSC-070-3-30-560-P5B0H2MM0 compatible with Siemens SINAMICS S120?
A: Yes, with motor data set configuration in STARTER/SCOUT. Encoder adaptation may require a Hiperface-to-EnDat gateway depending on drive firmware version.
Q: What does “MM0” in the part number indicate?
A: MM0 denotes no holding brake. If your application involves vertical axes or gravity loads, specify the brake variant (MM1 or MM2) when requesting a quote.
Q: Can this motor operate at 480 V AC (North American supply)?
A: The 560 V DC bus rating corresponds to a 400 VAC three-phase input to the drive. Operation on 480 VAC supply is possible with appropriate drive derating — consult our engineers for application review.
Q: What is the encoder resolution of the P5 option?
A: The P5 encoder typically provides 23-bit single-turn resolution with multi-turn capability. Confirm exact specification against the LTI MOTION LSC series datasheet for your firmware revision.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 5 units or more.
