LTI MOTION LSC-096-2-30-560-P5B0H2MM0 – High-Torque AC Brushless Servo Motor | LSC Series Platform
Engineering Background
LTI Motion (formerly known as Lust Antriebstechnik) is a German-engineered motion control brand with decades of field-proven performance in precision servo drive systems. The LSC series represents their flagship line of compact, high-dynamic AC brushless servo motors, purpose-built for demanding industrial automation environments where accuracy, repeatability, and thermal stability are non-negotiable.
Product Positioning
The LSC-096-2-30-560-P5B0H2MM0 is a frame-size 096 (96 mm flange), 2-pole-pair, 3.0 Nm continuous torque servo motor rated at 560 V DC bus voltage. It is engineered for OEM machine builders, system integrators, and MRO procurement teams requiring a drop-in replacement or new-build drive unit with full encoder feedback and IP65 sealing. This unit ships from verified OEM-sourced inventory with full traceability documentation available on request.
Complete Technical Specifications
| Model / SKU | LSC-096-2-30-560-P5B0H2MM0 |
| Brand | LTI Motion (LTI) |
| Series | LSC (Linear Servo Compact) |
| Motor Type | AC Brushless Synchronous Servo Motor |
| Frame Size | 096 mm (IEC flange) |
| Pole Pairs | 2 |
| Continuous Stall Torque | 3.0 Nm |
| DC Bus Voltage | 560 V |
| Feedback / Encoder | P5 – Hiperface DSL / SinCos absolute encoder (single-cable) |
| Brake Option | B0 – No holding brake |
| Shaft Configuration | H2 – Smooth shaft with keyway |
| Connector Type | MM0 – M23 power + M17 feedback connectors |
| Protection Rating | IP65 (standard) |
| Insulation Class | F (155 °C) |
| Cooling Method | Natural convection (self-cooled) |
| Weight | 5.3 kg |
| Country of Origin | Germany |
| Certifications | CE, UL (verify with datasheet) |
Proven Application Environments
- CNC Machining Centers – Axis feed drives requiring sub-micron positioning repeatability
- Robotics & Articulated Arms – Joint actuators demanding high torque density in compact envelopes
- Packaging Machinery – High-cycle pick-and-place and form-fill-seal lines
- Printing & Converting Equipment – Register control and web tension management
- Semiconductor & Electronics Assembly – Clean-room compatible motion axes
- Textile & Winding Machines – Tension-controlled winding with dynamic torque response
Engineering Advantages
- Single-Cable Hiperface DSL Feedback – Combines power and encoder signals in one cable, reducing wiring complexity and cabinet footprint by up to 40%
- High Pole-Pair Count Efficiency – 2-pole-pair design delivers smooth low-speed torque with minimal cogging, critical for precision contouring
- 560 V DC Bus Compatibility – Optimized for standard 400 V AC three-phase supply via LTI servo drives (CDA, SDS series), enabling direct integration without additional transformers
- IP65 Sealed Housing – Resists coolant splash, dust ingress, and wash-down cycles in harsh machining environments
- Class F Insulation – Supports sustained high-duty-cycle operation without thermal derating in ambient temperatures up to 40 °C
- Compact 096 mm Frame – High power-to-weight ratio enables machine designs with tighter axis spacing
System Architecture & Signal Flow
The LSC-096-2-30-560-P5B0H2MM0 is designed to operate within the LTI Motion closed-loop servo ecosystem:
- Motion Controller (CNC/PLC) → EtherCAT / PROFINET / analog ±10 V command signal
- LTI Servo Drive (CDA3000 / SDS5000) → 560 V DC bus, current loop at ≥8 kHz switching frequency
- LSC-096 Motor → Torque generation via 3-phase PWM excitation
- Hiperface DSL Encoder → Absolute position feedback (single-cable) back to drive
- Drive → Controller → Actual position/velocity closed-loop correction at fieldbus cycle time
Compatible drives include the LTI CDA3000 and SDS5000 series. Confirm motor-drive pairing via LTI’s motor selection tool or contact Konmask technical support for a validated BOM.
Sourcing & Quality Verification
- ✅ OEM-Sourced Inventory – Units sourced directly from authorized LTI Motion distribution channels
- ✅ Serial Number Traceability – Each unit carries manufacturer serial number; documentation available on request
- ✅ Pre-Shipment Inspection – Visual, dimensional, and electrical continuity checks performed before dispatch
- ✅ Secure Packaging – Anti-static foam-lined export carton with moisture desiccant for international freight
- ✅ Warranty – 12-month limited warranty against manufacturing defects (see Konmask warranty policy)
Procurement Process
- Confirm Compatibility – Verify motor-drive pairing and mechanical interface (shaft, flange, connector orientation) against your machine BOM
- Request Quote – Contact support@konmask.com for volume pricing, lead time, and export documentation (CO, packing list, commercial invoice)
- Place Order – Secure checkout via Konmask.com; T/T wire transfer and major credit cards accepted
- Shipping – DHL Express / FedEx International Priority standard; sea freight available for bulk orders; typical lead time 3–7 business days from stock
- Incoming Inspection – Konmask recommends verifying serial number and running a no-load spin test before installation
Technical FAQ
Q: Is this motor compatible with non-LTI drives?
A: The LSC series uses Hiperface DSL single-cable feedback, which is proprietary to LTI/Stegmann protocol. Third-party drives with Hiperface DSL support (e.g., some Bosch Rexroth, Siemens S120 with option modules) may be compatible — consult your drive manufacturer’s motor compatibility list.
Q: What is the difference between B0 and B1 brake options?
A: B0 = no holding brake (this unit). B1 = integrated 24 V DC spring-applied holding brake for vertical axis or safety-stop applications. If your application requires a brake, order the B1 variant.
Q: Can I use this motor in a vertical axis without a brake?
A: Not recommended for safety-critical vertical loads. The B0 variant has no holding torque when de-energized. Use B1 or add an external axis brake module.
Q: What encoder resolution does the P5 feedback option provide?
A: The P5 Hiperface DSL encoder typically provides 23-bit single-turn absolute resolution (8,388,608 counts/rev) with multi-turn capability depending on drive configuration.
Q: Is stock available for immediate shipment?
A: Contact support@konmask.com or call +0086 19859288691 to confirm real-time stock status before placing your order.
