Industrial Motion Control Solution – LTI MOTION LSC-130-3-20-560-A5B2R1PM0M | LSC Series AC Servo Motor
Where This Product Is Used
The LTI MOTION LSC-130-3-20-560-A5B2R1PM0M is a high-performance AC servo motor from the LSC Series, engineered for demanding industrial motion control applications. Engineers and system integrators specify this model across a wide range of sectors:
- CNC Machining Centers – Precision axis drive for milling, turning, and grinding machines requiring tight positional accuracy and dynamic response.
- Packaging Machinery – High-speed pick-and-place, form-fill-seal, and labeling lines where synchronization and repeatability are critical.
- Robotics & Handling Systems – Joint actuation in articulated arms, SCARA robots, and gantry systems demanding smooth torque delivery.
- Printing & Converting Equipment – Web tension control and register alignment in offset, flexo, and digital printing lines.
- Semiconductor & Electronics Manufacturing – Wafer handling, PCB drilling, and SMT placement requiring micron-level positioning.
- Textile Machinery – Winding, unwinding, and traverse drives in yarn and fabric production.
- Material Handling & Conveyors – Servo-driven indexing tables, transfer systems, and automated storage/retrieval (AS/RS).
Technical Specifications
- Brand: LTI MOTION (Linear Technology Inc. Motion)
- Series: LSC (Linear Servo Compact)
- Part Number / SKU: LSC-130-3-20-560-A5B2R1PM0M
- Frame Size: 130 mm
- Rated Power: 3 kW
- Rated Current: 20 A
- Rated Voltage: 560 V DC Bus
- Encoder Option (A5): High-resolution absolute encoder, 23-bit multi-turn
- Brake Option (B2): Integrated holding brake
- Feedback (R1): Resolver / encoder feedback interface
- Shaft / Mounting (PM0M): Smooth shaft, standard flange mount
- Protection Class: IP65 (shaft seal dependent on configuration)
- Insulation Class: Class F (155°C)
- Weight: Approx. 5.3 kg
- Cooling: Natural convection (self-cooled)
- Compatible Drives: LTI MOTION POSIDRIVE / POSIDYN servo drive series
Why Engineers Specify This Model
- Compact 130 mm Frame with 3 kW Output – High power density reduces machine footprint without sacrificing torque or dynamic performance.
- 23-Bit Absolute Encoder (A5) – Eliminates homing routines on power-up; retains position data through power cycles — critical for safety-sensitive axes.
- Integrated Holding Brake (B2) – Prevents axis drift on vertical or inclined loads when servo power is removed; reduces external brake hardware costs.
- 560 V DC Bus Compatibility – Optimized for 400 V AC three-phase supply systems standard in European and Asian industrial installations.
- Low Cogging Torque – Smooth velocity control at low speeds, essential for precision contouring and surface finish quality in CNC applications.
- Wide Operating Temperature Range – Reliable performance from 0°C to 40°C ambient, suitable for factory floor environments.
Complete System Bill of Materials
For a fully operational servo axis using the LSC-130-3-20-560-A5B2R1PM0M, engineers typically specify:
- LTI MOTION POSIDRIVE FDS / MDS Servo Drive (matched to 20 A / 560 V)
- Motor power cable (shielded, 4-core, rated ≥ 600 V)
- Encoder/resolver feedback cable (shielded, twisted pair)
- Brake cable (if B2 brake option is used)
- Motor connector set (M23 or M17 per LTI MOTION specification)
- Line filter / EMC filter (per CE/EMC compliance requirements)
- 24 VDC brake power supply
- Safety relay or STO (Safe Torque Off) module
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and Low Voltage Directive
- EMC Directive – Designed for use with appropriate line filters per EN 61800-3
- IEC 60034 – Rotating electrical machines standard
- UL Recognition – Available on select configurations (verify with datasheet)
- RoHS Compliant – Restriction of Hazardous Substances
Quality Assurance & Sourcing
At Konmask.com, every LTI MOTION component is sourced through verified industrial supply channels. Our quality process includes:
- Visual and dimensional inspection upon receipt
- Serial number and label verification against manufacturer records
- Functional continuity checks prior to dispatch
- Secure anti-static packaging for all servo motors
- Full traceability documentation available on request
We specialize in hard-to-find, obsolete, and long-lead-time automation components — helping engineers keep production lines running without costly downtime.
How to Source This Part
Ready to order the LSC-130-3-20-560-A5B2R1PM0M? Here’s how to proceed:
- In Stock: Add to cart and check out directly — we ship worldwide via DHL, FedEx, and UPS Express.
- Lead Time Inquiry: Contact us at support@konmask.com for ETA on replenishment stock.
- Bulk / OEM Orders: Request a volume quote — we offer competitive pricing for quantities of 3+ units.
- Technical Pre-Sales: Our engineering team can confirm compatibility with your existing LTI MOTION drive system before purchase.
Application-Specific FAQ
Q: Is the LSC-130-3-20-560-A5B2R1PM0M compatible with third-party servo drives?
A: This motor is optimized for LTI MOTION POSIDRIVE/POSIDYN drives. Third-party compatibility depends on encoder interface support (absolute encoder, 23-bit). Consult your drive manufacturer’s motor compatibility list.
Q: What does the “B2” brake option mean?
A: B2 denotes an integrated electromagnetic holding brake. It is a spring-applied, power-released brake — meaning it engages (holds) when 24 VDC power is removed, providing fail-safe axis locking.
Q: Can this motor be used in a vertical axis application?
A: Yes. The integrated B2 holding brake makes this model well-suited for vertical axes, preventing load drop during E-stop or power loss events.
Q: What is the difference between the A5 encoder and standard incremental encoders?
A: The A5 absolute encoder retains position information without requiring a homing cycle after power-up. This reduces machine cycle time and is essential for safety-critical or high-throughput applications.
Q: Do you provide a warranty?
A: Yes. All units sold through Konmask.com carry a 90-day functional warranty. Extended warranty options are available — contact us for details.
