Industrial Motion Control Solution – LTI MOTION LSC-096-3-40-560-P5B0R1PM0M | LSC Series AC Servo Motor
Where This Product Is Used
The LTI MOTION LSC-096-3-40-560-P5B0R1PM0M is a high-performance AC servo motor from the LSC series, engineered for demanding industrial motion control applications. Engineers and system integrators specify this model across the following sectors:
- CNC Machine Tools – Precision axis drive for milling, turning, and grinding centers requiring tight positional accuracy and dynamic response.
- Packaging Machinery – High-speed pick-and-place, form-fill-seal, and cartoning lines where synchronization and repeatability are critical.
- Printing & Converting – Web tension control, register correction, and cut-to-length applications demanding smooth torque delivery.
- Robotics & Handling – Articulated arm joints and gantry axes in automotive assembly and electronics manufacturing.
- Semiconductor & Electronics – Wafer handling, PCB drilling, and SMT placement equipment requiring ultra-low vibration and high resolution feedback.
- Plastics & Injection Molding – Servo-driven injection units and clamping axes replacing hydraulic systems for energy efficiency.
- Textile Machinery – Winding, unwinding, and traverse drives requiring constant tension across variable speeds.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | LTI MOTION (formerly Lust Antriebstechnik) |
| Part Number / SKU | LSC-096-3-40-560-P5B0R1PM0M |
| Series | LSC (Linear Servo Compact) |
| Motor Type | AC Synchronous Servo Motor |
| Frame Size | 096 (96 mm flange) |
| Poles | 3 pole pairs |
| Rated Torque | 40 Nm (nominal) |
| Rated Voltage | 560 V AC |
| Feedback | P5 – Resolver / Encoder (per option code) |
| Brake | B0 – No brake / B1 – Integrated holding brake (per option) |
| Shaft | R1 – Standard cylindrical shaft with key |
| Protection Class | IP65 (standard) |
| Insulation Class | F (155°C) |
| Weight | Approx. 5.3 kg |
| Cooling | Natural convection (self-cooled) |
| Mounting | Flange mount (IEC standard) |
Why Engineers Specify This Model
- High Torque Density – The LSC-096 frame delivers 40 Nm in a compact 96 mm housing, reducing machine footprint without sacrificing performance.
- 560 V Bus Compatibility – Designed for 400 V three-phase mains with standard DC bus voltage, ensuring direct compatibility with LTI MOTION CDD and CDE servo drives.
- Resolver/Encoder Flexibility – The P5 feedback option supports both resolver and incremental encoder configurations, simplifying integration into existing control architectures.
- Robust IP65 Sealing – Suitable for wash-down environments and dusty production floors without additional enclosure.
- Low Cogging Torque – Smooth torque ripple characteristics make this motor ideal for precision positioning and velocity-critical applications.
- Direct LTI MOTION Drive Pairing – Optimized for use with LTI MOTION CDD3000 / CDE3000 series servo drives for plug-and-play commissioning.
Complete System Bill of Materials
For a complete servo axis using the LSC-096-3-40-560-P5B0R1PM0M, engineers typically specify:
- Servo Drive – LTI MOTION CDD3000 or CDE3000 series (matched to 560 V bus, ≥40 Nm continuous)
- Motor Cable – LTI MOTION shielded power cable, 4-core, rated ≥600 V, appropriate length
- Feedback Cable – Resolver or encoder cable matched to P5 feedback option
- Holding Brake Resistor – If B1 brake option selected, 24 VDC brake power supply required
- Gearbox – Planetary gearbox (e.g., Neugart PLE or equivalent) if torque multiplication or speed reduction is needed
- Coupling – Bellows or jaw coupling for shaft-to-load connection
- Safety Relay / STO Module – For SIL2/PLd Safe Torque Off compliance
Compliance & Industry Standards
- CE Marked – Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- IEC 60034 – Rotating electrical machines standard
- IEC 60529 – IP65 ingress protection rating
- RoHS Compliant – Restriction of Hazardous Substances
- UL Recognition available on request for North American projects
Quality Assurance & Sourcing
Konmask.com sources the LTI MOTION LSC-096-3-40-560-P5B0R1PM0M through verified industrial distribution channels. Every unit undergoes:
- Visual and dimensional inspection upon receipt
- Authenticity verification against LTI MOTION manufacturer documentation
- Insulation resistance and continuity checks prior to dispatch
- Secure anti-static packaging with original labeling preserved
We maintain traceability records for all servo motor shipments to support your incoming quality control process.
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Request a Quote – Email [email protected] with your required quantity, delivery address, and any project-specific requirements.
- Lead Time – In-stock units ship within 3–5 business days. Ex-stock or special configurations: 4–8 weeks (subject to LTI MOTION factory schedule).
- Payment Terms – T/T bank transfer, PayPal, and trade assurance options available for B2B orders.
- Export & Customs – We handle export documentation, HS code classification, and commercial invoices for international shipments.
- Phone / WhatsApp – +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
Application-Specific FAQ
Q: Is the LSC-096-3-40-560-P5B0R1PM0M compatible with third-party servo drives?
A: The motor can be integrated with compatible third-party drives (e.g., Siemens SINAMICS, Bosch Rexroth IndraDrive) provided the drive supports the resolver/encoder feedback type and the 560 V bus voltage. Motor parameter files (motor data sheets) are available upon request.
Q: What does the P5B0R1PM0M option string mean?
A: P5 = feedback type (resolver/encoder), B0 = no holding brake, R1 = standard shaft with key, PM = permanent magnet winding configuration, 0M = additional option codes. Full option decoding is available in the LTI MOTION LSC series datasheet.
Q: Can this motor be used in a vertical axis application?
A: Yes, with the B0 (no brake) option, a separate external holding brake or counterbalance must be used for vertical axes to prevent load drop on power loss. The B1 brake option provides an integrated 24 VDC holding brake for vertical axis safety.
Q: What is the typical service life of the LSC-096 series?
A: Under rated operating conditions, LTI MOTION LSC series motors are designed for L10 bearing life exceeding 20,000 hours. Actual service life depends on load cycle, ambient temperature, and mounting orientation.
Q: Do you provide installation and commissioning support?
A: Konmask.com provides technical documentation, wiring diagrams, and remote commissioning guidance. On-site support can be arranged through our partner network for large-scale projects.
