M2I XTOP07TW-UD Touch Panel HMI | Replacement, Equivalent & Selection Guide
The M2I XTOP07TW-UD is a 7-inch widescreen TFT LCD HMI (Human-Machine Interface) operator panel from M2I Corporation’s XTOP series. Designed for industrial automation environments, it delivers reliable real-time visualization and control for PLC-based systems. This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | XTOP07TW-UD |
| Brand / Manufacturer | M2I Corporation |
| Series | XTOP |
| Display Size | 7.0″ Widescreen TFT LCD |
| Resolution | 800 × 480 pixels |
| Touch Type | Resistive Touch Screen |
| CPU | 32-bit RISC Processor |
| Memory (Flash) | 128 MB |
| Memory (RAM) | 64 MB |
| Communication Ports | RS-232, RS-422/485, USB Host, USB Device, Ethernet |
| Power Supply | DC 24V (±15%) |
| Power Consumption | ≤ 10W |
| Operating Temperature | 0°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C |
| Protection Rating | IP65 (Front Panel) |
| Weight | Approx. 2,380 g |
| Mounting | Panel Mount (cutout required) |
| Software | XDesignerPlus (M2I proprietary) |
Compatible Replacement & Equivalent Models
If the XTOP07TW-UD is discontinued, long lead-time, or outside budget, the following models offer functional equivalence or drop-in compatibility. Always verify communication protocol and power requirements before substitution.
| Brand | Model | Display | Notes |
|---|---|---|---|
| M2I | XTOP07TW-UD-E | 7″ Widescreen | Enhanced version, same form factor |
| M2I | XTOP10TS-UD | 10.1″ Widescreen | Larger display, same XTOP series |
| Weintek | MT8071iE | 7″ Widescreen | Ethernet + serial, EasyBuilder Pro software |
| Weintek | MT8102iE | 10.1″ Widescreen | Higher resolution alternative |
| Kinco | MT4414TE | 7″ Widescreen | Cost-effective, multi-protocol support |
| Siemens | KTP700 Basic PN | 7″ Widescreen | PROFINET native, TIA Portal integration |
| Schneider | HMIGTO2310 | 5.7″ Standard | Smaller form factor, Vijeo Designer |
Note: Cross-brand replacements require driver configuration and may need software migration. Contact support@konmask.com for compatibility assessment.
Why Choose the Original M2I XTOP07TW-UD
- Proven XTOP Series Reliability – Field-tested in Korean and Asian industrial markets with strong OEM adoption.
- Rich Communication Options – Native support for Mitsubishi, Siemens, Omron, LS, and other major PLC protocols via XDesignerPlus drivers.
- IP65 Front Panel – Suitable for dusty and splash-prone environments without additional enclosure modification.
- Widescreen 7″ Display – Optimal for dashboard-style SCADA screens with multi-zone layouts.
- Compact & Panel-Mount Ready – Standard cutout dimensions simplify retrofit installations.
Typical Applications
- Machine tool control panels and CNC operator stations
- Packaging line HMI visualization
- Water treatment and HVAC monitoring systems
- Conveyor and material handling control
- Injection molding machine interfaces
- Building automation and energy management
- Food & beverage processing equipment
System Compatibility
The XTOP07TW-UD is compatible with a wide range of PLC brands via XDesignerPlus communication drivers:
- Mitsubishi Electric – FX, Q, iQ-R, iQ-F series
- Siemens – S7-200, S7-300, S7-400, S7-1200, S7-1500
- Omron – CP, CJ, CS, NX/NJ series
- LS Electric (LG) – XGB, XGI, XGR series
- Allen-Bradley – MicroLogix, CompactLogix (via Ethernet/IP)
- Modbus RTU / TCP – Universal protocol for third-party devices
Selection Guide
Use the criteria below to confirm the XTOP07TW-UD is the right choice, or to identify a suitable alternative:
| Requirement | Recommended Model |
|---|---|
| 7″ widescreen + M2I ecosystem | XTOP07TW-UD ✓ |
| 7″ + Ethernet only + lower cost | Weintek MT8071iE |
| 7″ + Siemens TIA Portal native | Siemens KTP700 Basic PN |
| 10″ upgrade, same XTOP series | M2I XTOP10TS-UD |
| Budget 7″ with multi-protocol | Kinco MT4414TE |
| Capacitive touch required | Weintek MT8102iE or Siemens KTP700 |
Quality Assurance & Sourcing
- Authentic Parts Only – All units sourced from authorized distributors or verified surplus channels with full traceability.
- Pre-shipment Inspection – Each unit undergoes power-on and communication port verification before dispatch.
- Warranty – 12-month warranty against manufacturing defects.
- Packaging – Anti-static ESD packaging with foam protection for safe international shipping.
- Lead Time – In-stock units ship within 1–3 business days; special orders within 7–15 business days.
How to Order
- Confirm the exact model number: XTOP07TW-UD
- Specify quantity and required delivery timeline.
- Add to cart directly, or contact us for bulk pricing and OEM discounts.
- For replacement projects, share your existing HMI model and PLC type — we will recommend the best-fit solution.
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Can the XTOP07TW-UD replace a Weintek MT8071iE directly?
A: Physically similar in size, but software migration from EasyBuilder Pro to XDesignerPlus is required. Communication drivers must be reconfigured.
Q: Is the XTOP07TW-UD still in production?
A: M2I continues to support the XTOP series. Contact us to confirm current production status and lead time.
Q: What software is needed to program this HMI?
A: XDesignerPlus, available free from M2I Corporation. We can assist with driver setup and project templates.
Q: Does it support Modbus TCP?
A: Yes, via the built-in Ethernet port with Modbus TCP driver in XDesignerPlus.
Q: Can I get a datasheet or wiring diagram?
A: Yes — email support@konmask.com with your model number and we will send the documentation.
