Genuine MCGS TPC1062K 10.2″ HMI Touch Screen | Kunlun Series – Verified Source
The MCGS TPC1062K is a high-performance 10.2-inch Human-Machine Interface (HMI) from MCGS (Beijing Kunlun Tongtai Automation Technology Co., Ltd.), part of the trusted Kunlun Series. At Konmask.com, every unit is sourced directly from authorized channels and undergoes multi-point verification before dispatch — giving industrial buyers the confidence they need when specifying critical automation components.
Technical Specifications
- Model / SKU: TPC1062K
- Brand: MCGS (昆仑通态)
- Series: Kunlun (TPC Series)
- Display Size: 10.2 inch TFT LCD
- Resolution: 800 × 480 px
- Touch Type: Resistive touch screen
- CPU: ARM Cortex-A8, 600 MHz
- RAM: 128 MB DDR
- Flash Storage: 128 MB
- Operating System: Embedded Linux (MCGS Embedded)
- Communication Ports: RS-232, RS-485, USB Host, USB Device, Ethernet (RJ45)
- Power Supply: DC 24V (±15%)
- Power Consumption: ≤ 10W
- Operating Temperature: 0°C ~ 55°C
- Storage Temperature: -20°C ~ 70°C
- Protection Rating: IP65 (front panel)
- Dimensions (W×H×D): 280 × 210 × 48 mm
- Panel Cutout: 265 × 195 mm
- Weight: Approx. 1.0 kg
- Certifications: CE, RoHS
Our 4-Step Quality Verification Process
Every MCGS TPC1062K shipped from Konmask.com passes through our rigorous 4-step verification protocol:
- Step 1 — Source Authentication: Units are procured exclusively from MCGS-authorized distributors or direct factory channels. We verify supplier credentials before every purchase order.
- Step 2 — Physical Inspection: Each unit is inspected for correct labeling, serial number integrity, firmware version, and packaging condition upon receipt.
- Step 3 — Functional Power-On Test: The HMI is powered on to confirm display quality, touch response, communication port functionality, and correct MCGS firmware boot.
- Step 4 — Documentation Check: We verify that the unit’s serial number matches MCGS factory records and that all included accessories (manual, mounting hardware, USB cable) are present.
Key Features & Benefits
- ✅ Large 10.2″ Display — Clear, high-contrast TFT LCD for demanding industrial environments
- ✅ IP65 Front Panel — Dust-proof and water-resistant for harsh factory floors
- ✅ Multi-Protocol Communication — Native support for Modbus RTU/TCP, Siemens S7, Mitsubishi FX/Q, Omron, Delta, and 300+ PLC drivers via MCGS MCGSE software
- ✅ Embedded Linux OS — Stable, real-time performance with fast boot (<30 seconds)
- ✅ Rich I/O Connectivity — Dual RS-485, RS-232, Ethernet, and dual USB ports for flexible integration
- ✅ MCGS MCGSE Software Compatible — Free configuration software with drag-and-drop HMI design, recipe management, data logging, and alarm functions
- ✅ Genuine Factory Unit — Full manufacturer warranty honored; not refurbished or grey-market
Typical Applications
- PLC-based machine control panels (injection molding, CNC, packaging lines)
- Water treatment and HVAC monitoring systems
- Power distribution and energy management dashboards
- Food & beverage processing equipment
- Building automation and elevator control
- Chemical and pharmaceutical process visualization
- OEM machine builders requiring a cost-effective, reliable HMI solution
Compatible System Components
The TPC1062K integrates seamlessly with the following systems and brands:
- PLCs: Siemens S7-200/300/400/1200/1500, Mitsubishi FX/Q/L, Omron CP/CJ/CS, Delta DVP/AS, Schneider Modicon, Allen-Bradley (via Modbus), MCGS own PLC series
- Protocols: Modbus RTU, Modbus TCP/IP, PROFIBUS (via gateway), OPC UA (via gateway), BACnet (via gateway)
- Software: MCGS MCGSE (free download), supports Windows 7/10/11 for project development
- Accessories: MCGS TPC series mounting clips, USB programming cable, 24VDC power supplies
Global Sourcing & Shipping Capabilities
Konmask.com ships the MCGS TPC1062K worldwide from our warehouse in China. We support the following logistics options:
- Express (3–7 business days): DHL, FedEx, UPS — door-to-door with full tracking
- Economy Air (7–15 business days): ePacket, China Post Registered Air Mail
- Sea Freight (25–45 days): Available for bulk orders (5+ units) — contact us for a quote
- Export Documentation: Commercial invoice, packing list, and certificate of origin available upon request for customs clearance
- Bulk / OEM Orders: Volume pricing available for orders of 3+ units. Contact support@konmask.com for a formal quotation.
Certifications & Compliance Statement
- CE Marking: Compliant with EU Low Voltage Directive (LVD) and EMC Directive
- RoHS: Restriction of Hazardous Substances compliant — lead-free, mercury-free
- IP65: Front panel ingress protection certified per IEC 60529
- MCGS Factory Warranty: 12-month manufacturer warranty from date of production (serial number verified)
- Konmask Authenticity Guarantee: If your unit fails our authenticity check upon receipt, we offer a full refund or replacement — no questions asked.
How to Order
- Add to Cart — Click “Add to Cart” or “Buy Now” above.
- Checkout Securely — We accept major credit cards, PayPal, T/T bank transfer, and Western Union for bulk orders.
- Order Confirmation — You will receive an order confirmation email within 1 hour of payment.
- Dispatch — In-stock units are dispatched within 1–2 business days. Tracking number provided via email.
- Need a Proforma Invoice? — Email support@konmask.com with your order details and company information.
Authenticity & Trust FAQ
Q: Is this a genuine MCGS product or a clone?
A: 100% genuine. We source exclusively from MCGS-authorized distributors. Every unit carries a valid MCGS factory serial number traceable to the manufacturer.
Q: Do you offer a warranty?
A: Yes. All units carry the standard 12-month MCGS factory warranty. Konmask.com also provides a 30-day return guarantee for DOA (Dead on Arrival) units.
Q: Can I get a test report or inspection certificate?
A: Yes, upon request we can provide a pre-shipment inspection report for orders of 2+ units. Contact us before placing your order.
Q: What if I need a different MCGS model?
A: We stock a wide range of MCGS TPC series HMIs. Contact support@konmask.com with your required model number and quantity.
Q: Do you support OEM/ODM or custom branding?
A: We do not offer custom branding on MCGS products, but we can assist with bulk procurement and private-label packaging for qualified buyers.
