Metrix 5465E-103 Vibration Transmitter | Replacement, Equivalent & Selection Guide
The Metrix 5465E-103 is a high-performance vibration transmitter designed for continuous machinery health monitoring in industrial automation environments. This page provides a comprehensive selection guide, compatible replacement models, and equivalent alternatives to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 5465E-103 |
| Brand / Manufacturer | Metrix (Bently Nevada / Baker Hughes Group) |
| Product Series | 5465E Series |
| Product Type | Vibration Transmitter (Proximity / Eddy Current) |
| Output Signal | 4–20 mA (2-wire) |
| Measurement Type | Radial shaft vibration / displacement |
| Supply Voltage | 18–30 VDC |
| Frequency Range | 10–1000 Hz (typical) |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP67 |
| Certifications | CE, ATEX (Ex ia IIC T6), CSA |
| Mounting | Threaded / Flange mount |
| Weight | Approx. 100 g |
| Country of Origin | USA |
Compatible Replacement & Equivalent Models
The following models are commonly used as direct or functional replacements for the Metrix 5465E-103. Always verify electrical and mechanical compatibility before substitution.
| Brand | Model | Compatibility Level | Notes |
|---|---|---|---|
| Metrix | 5465E-101 | Direct (same series) | Different cable length / connector |
| Metrix | 5465E-105 | Direct (same series) | Extended temperature variant |
| Bently Nevada | 330180-X1-CN | Functional equivalent | Eddy current proximity system |
| Bently Nevada | 3300 XL Series | Functional equivalent | Higher accuracy, same 4-20mA output |
| Emerson | CSI 2130 | Partial (analyzer-based) | Requires signal conditioning module |
| Wilcoxon | 786A | Functional equivalent | Accelerometer-based, check application |
| PCB Piezotronics | 603C01 | Functional equivalent | ICP® type, verify power supply |
⚠ Disclaimer: Replacement compatibility is provided for reference only. Konmask.com recommends consulting your OEM documentation or contacting our technical team before substitution.
Why Choose the Original Metrix 5465E-103
- Factory-certified accuracy — calibrated to OEM specifications for reliable machinery protection
- Proven field reliability — widely deployed in rotating machinery, turbines, compressors, and pumps
- Seamless system integration — plug-and-play with Metrix and compatible vibration monitoring systems
- ATEX / CSA certified — suitable for hazardous area installations
- Long service life — robust construction for harsh industrial environments
Typical Applications
- Rotating machinery health monitoring (turbines, compressors, pumps, motors)
- Radial shaft vibration and displacement measurement
- Predictive maintenance (PdM) and condition monitoring systems
- Oil & gas, petrochemical, and power generation plants
- Marine and offshore installations
- Pulp & paper, mining, and heavy industry
System Compatibility
- Metrix MX2033 / MX2034 Vibration Monitoring Systems
- Bently Nevada 3500 Series Machinery Protection Systems
- Emerson AMS Suite / CSI Machinery Health Analyzers
- Generic 4–20 mA PLC/DCS input cards (Siemens, Rockwell, Honeywell, ABB, Yokogawa)
- SCADA and historian platforms via standard analog input modules
Selection Guide
Use the following criteria to confirm the Metrix 5465E-103 is the right choice for your application, or to identify the best alternative:
- Output type: Requires 4–20 mA? → 5465E-103 is ideal. Requires voltage output? → Consider 5465E-101 or Bently Nevada 3300 XL.
- Measurement range: Standard radial displacement → 5465E-103. Extended range → 5465E-105.
- Hazardous area: ATEX Zone 0/1 required → confirm ATEX variant; CSA required → standard 5465E-103 qualifies.
- Cable length / connector: Verify suffix code (-103 = specific cable/connector config). Contact us if a different suffix is needed.
- Budget-sensitive projects: Functional equivalents (Bently Nevada 330180, Wilcoxon 786A) may offer cost savings — contact our team for a comparison quote.
Quality Assurance & Sourcing
- ✅ Genuine OEM parts sourced from authorized distributors and verified supply chains
- ✅ Inspection & testing — all units inspected before shipment
- ✅ Traceability — batch records and certificates of conformance available on request
- ✅ Warranty — 12-month warranty against manufacturing defects
- ✅ Export compliance — experienced in cross-border shipping to Asia, Europe, and the Americas
How to Order
- Click Add to Cart or Request a Quote on this page
- Provide your required quantity, delivery address, and any special requirements
- Our team will confirm availability, lead time, and pricing within 24 hours
- Payment via T/T, PayPal, or credit card — secure checkout via Shopify
- Worldwide shipping available; DHL / FedEx / UPS express options
📧 Email: support@konmask.com | 📞 Phone/WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can the Metrix 5465E-103 replace a Bently Nevada 330180 series sensor?
A: Functionally, both are eddy-current proximity transmitters with 4–20 mA output. Mechanical mounting and cable connectors may differ — please verify before installation.
Q: Is the 5465E-103 compatible with Siemens or Rockwell PLC analog input cards?
A: Yes. The 4–20 mA output is industry-standard and compatible with any PLC/DCS analog input module rated for this signal range.
Q: What does the “-103” suffix mean?
A: The suffix typically denotes a specific cable length, connector type, or configuration option within the 5465E series. Contact us to confirm the exact specification for your application.
Q: Do you supply other models in the Metrix 5465E series?
A: Yes — we stock multiple variants. Contact us with your full part number for availability and pricing.
Q: Can I get a datasheet or certificate of conformance?
A: Yes, available upon request after order confirmation. Email support@konmask.com.
